CS 2000 Wireless Handheld Gun Type Scanner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axon CS 2000

Summary of Contents for Axon CS 2000

  • Page 1 CS 2000 Wireless Handheld Gun Type Scanner...

  • Page 3: Revision History

    ’ ANUAL Revision History Changes to the original manual are listed below: Version Date Description of Version Dec. 20, 2011 Axon Initial release CS 2000 Wireless Handheld Gun Type Scanner...

  • Page 4: General Handling Precautions

    This manual is in A5 size. Please double check your printer setting before printing it out. When the barcodes are to be printed out for programming, the use of a high-resolution laser printer is strongly suggested for the best scan result. Copyright © 2011. All rights reserved. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 5: Laser Safety

    7mm aperture and averaged over 10 seconds. Do not attempt to remove the protective housing of the scanner, as unscanned laser light with a peak output up to 0.8mW would be accessible inside. CS 2000 Wireless Handheld Gun Type Scanner...

  • Page 6: For Ce-Countries

    Remove the battery if the scanner is not going to be used for a long time. If the battery is left unused for more than 3 months, you need to charge the battery before use. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 7: Table Of Contents

    USB Online Mode ....................20 Cradle Host Mode ....................21 Wireless Mode ....................22 Data Transnit Method ..................27 System Function Settings ...................30 Data Editing......................75 Appendix 1: USB Virtual COM Driver Installation ..........83 Appendix 2: Barcode Length Setting ..............84 CS 2000 Wireless Handheld Gun Type Scanner...

  • Page 9: Introduction

    This scanner would be your trusted tool scanning partner. Key Features:  Superb scanning ability  Proprietary hardware decoding technology  100M long-range wireless connection  Rugged and ergonomic form factor  Flexible communications CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 10: Product Overview

    ’ ANUAL Product Overview Scanner LED Indicator Exit Window Buzzer Trigger Strap Hole Metal Charging Contacts Cable Connector Cradle Charging Contacts Function Trigger/LED indicator Host Connector DC Power Connector Bluetooth Address Label CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 11: Scanner And Accessories

    Mini USB B to mini USB A cable 5V USB Power adapter CD-ROM or handbook (Containing manual and programming guide) If any contents are damaged or missing, please contact your dealer immediately. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 12: Battery Installation

    Make sure the red tag on the battery is tugged in and not blocking the cable connector and close the cap. Tighten the screw on the cap to secure the battery. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 13: Connecting The Cradle

    The mini USB port on the bottom of the cradle should only be connected using the USB power adaptor. If connect to PC host will drain host power, and may affect the performance of the PC host. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 14: Charging The Battery

    You can also connect the USB cable to an outlet using the power adapter to charge the battery. The battery begins charging when the scanner LED indicator starts flashing green. LED turns steady green when charging is complete. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 15: Power On The Scanner

    Ensure the battery is fully charged. Please refer to the previous section to charge the battery. Press and hold the trigger for 1 second until a long beep sound is heard to turn on the scanner. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 16: How To Scan

    Presentation Scanning Put the scanner into the cradle for presentation scanning. Move the barcode label approach the scanner scanning zone. When decoding is successful, the scanner beeps and the LED indicates blue. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 17: Radio Communication Host Type

    The scanner communicates with the host through wireless connection. Please see Wireless Mode for detail operation information. HID Mode The scanner communicates with the smart phone through wireless HID connection. Please see BT HID mode for detail operation information CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 18: Paging The Scanner

    The scanner connects directly to a USB host to recharge and transmit data. Visible Indicators Scanner There are 2 groups of LED indicators on top of the scanner. These indicate the operational status of the scanner. Group 2 Group 1 CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 19: Cradle

    Cradle is radio connected. But lost DC power from the Steady red and blue adaptor. Red and blue USB Interface communication failed. interchange Steady blue Cradle is radio connected. Blue flashing Cradle is radio disconnected. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 20: Sound Indicators

    ACK/NAK Protocol or Frame Packing When scanner is in SPP Master/Slave mode, and add in the data protocol or packing could confirm the data reliability. Refer to below for different setting options: CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 21 BT Scanner device b) ACK/NAK only data Remote BT BT scanner Resend device Get a good beep c) Frame packing: Data format of Remote BT BT scanner Acknowledge device Get a good beep CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 22: Scanner To Remote Application

    55H (end of byte) 1 byte 1 byte 1 byte Example: If scanner sends out: EAH , 0AH , FEH , 01H , "ABCD ", 011H, AEH , EEH Remote acknowledges: 55H +01H + 55H CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 23 ’ ANUAL Barcode Type Table Code Value Code39 0x11 Codabar 0x01 Code128 0x03 Interleaved 2/5 0x02 Code93 0x06 UPC-E 0x14 UPC-A 0x24 EAN-8 0x34 EAN-13 0x44 Chinese Post Code 0x05 0x07 CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 24: Programming Guide

    Scan the “Start of Configuration” barcode Scan barcode of the desired feature Scan the “End of Scan the “Abort” barcode Power off the scanner Configuration” barcode Discard the configuration Finish the configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 25: Default Parameters

    Terminator Enter(Alpha numeric) USB Communication Terminator Enter Code mode Scan code Keyboard IT keyboard Wand Emulation Wand emulation speed Normal Data output Black=high Pair contact on cradle Enable Scanner Decoder Selection Default CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 26 ITF 2 of 5 identifier code Chinese post code identifier code UPC-A identifier code UPC-E identifier code EAN-13 identifier code EAN-8 identifier code Codabar identifier code Code 128 identifier code Code 93 identifier code CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 27 (default 3~62) EAN128 C1 D1-Dx (default 3~62) CODE39 D1-Dx (default 3~62) CODABAR D1-Dx (default 6~32) INTERLEAVED 2/5 D1-Dx (default 6~32) CHINESE POST CODE D1-Dx (default 8~32) CODE93 D1-Dx (default 3~32) D1-Dx (default 6~32) CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 28: Connecting To A Host

    Set USB as the primary connection USB connection as the primary communication option to the host when it is available. Wireless mode is set USB online scan, Ignore as the secondary option. radio communication End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 29: Cradle Host Mode

    Return to wand emulation default Return to RS232 cradle communication. (Communication cradle link required) Return to RS232 default Cradle IBM PC/AT/PS/2 Keyboard emulation. (Communication cradle link required) IBM PC/AT/PS/2 Keyboard emulation End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 30: Wireless Mode

    Select “Let me choose my own passkey” and enter the pin code. The default pin code is “12345678. Click “Next” to connect the scanner to the host. A short beep should be heard upon connection. End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 31 In SPP Master mode, you can print out a Code39 label of the wireless address in “BxxxxxxxxxxxxT” format and scan it with the scanner instead of using the ASCII table. End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 32 “ZBBT” and input the pin code that appears on your mobile device to connect scanner to the phone. Scan the Enter barcode to confirm. A short beep should be heard upon connection. Enter Full ASCII ---CR Function key-----“Enetr(num.)” End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 33 Reset Name To change the scanner name back to the default name “ZBBT” use the “Default device name” setting. Change device name back to default “ZBBT”. Default device name End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 34 Use the following settings to show or hide the device from wireless discovery. Make scanner visible to wireless device. Discover enable Make scanner invisible to wireless device. Discover disable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 35: Data Transnit Method

    Enable out of range mode. Out of range buffer enable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 36 Clear batch data by scanning “Delete batch data” label Same as previous setting but with alert sound. Delete batch data Confirm Setting (for address and pin code setting required) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 37 Send Batch Data without beep Beep sound when sending data. Good-read LED will light up until the transfer is done. Send Batch Data with Beep End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 38: System Function Settings

    Return to RS232 default (Communication cradle link required) IBM PC/AT/PS/2 keyboard emulation (Communication cradle link required) Return as USB-virtual COM port default Return to stand-alone keyboard default Return as OPOS port default End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 39 Also called auto trigger mode. The scanner is inactive but will automatically detect barcodes presented in the scan zone and become active. Idle mode enable Idle mode disable Disable Idle mode. End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 40 Disable beep sound alert when scanner is placed on cradle. On Cradle Auto-Scan mode enable Enable Auto-Scan when scanner is placed on cradle. On Cradle Auto-Scan mode disable Disable Auto-Scan when scanner is placed on cradle. End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 41 Scanner SPP Master enable SPP Master (Connect wireless address “BxxxxxxxxxxxxT” in CODE39 format) Scanner SPP Slave enable Setting wireless address (SPP Master only) Set PIN code (SPP Master only) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 42 Required Pair with slave (SPP Master) Discover enable Discover disable Encryption enable Encryption disable Data communication without protocol Data communication with ACK/NAK protocol Data communication with Packing protocol End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 43 Send Batch data on cradle Out of range resend data with beeper sound Out of range resend data without beeper sound Send Batch Data without Beep Send Batch Data with Beep End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 44 Radio protocol timeout= 5 sec Radio protocol timeout =8 sec Radio protocol timeout= 10 sec Radio protocol timeout =13 sec Radio protocol timeout =16 sec Radio protocol timeout= 20 sec End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 45 Power off timeout=30 min Power off timeout=1 hr Power Off timeout : 2 hr Power Off timeout : 4 hr Power Off timeout : 6 hr Power Off timeout : 8 hr End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 46 Power off by scanning this label Link beeper enable Link beeper disable Power-up beeper enable Power-up beeper disable Same Code Delay 50 msec 100 msec 200 msec 300 msec End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 47 ’ ANUAL Start Of Configuration 400 msec 500 msec 600 msec 700 msec 800 msec 1000 msec Infinite End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 48 ’ ANUAL Start Of Configuration Operation Function Setting Good Read Beeper Tone Selection Medium beeper tone High beeper tone Low beeper tone Speaker disable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 49 ’ ANUAL Start Of Configuration Beeper duration Selection Long Medium Short Ultra Short Ultra Long End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 50 Good read beeper and vibrator enable Vibration duration=100msec Vibration duration=200msec Vibration duration=300msec Vibration duration=400msec Vibration duration=500msec Vibration duration=1 second Vibration duration=2 second Vibration duration=3 second Vibration duration=4 second Vibration duration=5 second End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 51 Start Of Configuration Inter Character Delay 0 ms 2 ms 5 ms 10 ms 20 ms 50 ms Inter Message Delay 0 ms 100 ms 500 ms 1000 ms End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 52 1200 Parity Bit Even parity Odd parity Mark parity Space parity None parity Stop Bit 1 stop bit 2 stop bit Data Bit 7 data bit 8 data bit End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 53 ACK/NAK response time 2 sec ACK/NAK response time 500 ms ACK/NAK response time 3 sec ACK/NAK response time 1 sec ACK/NAK response time 5 sec ACK/NAK response time infinity End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 54 ’ ANUAL Start Of Configuration Message Terminator RS-232 message terminator—none RS-232 message terminator—CR/LF RS-232 message terminator—CR RS-232 message terminator—LF RS-232 message terminator—H tab RS-232 message terminator—STX/ETX RS-232 message terminator—EOT End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 55 Keyboard language support---Belgium send scan code Keyboard language support---Japanese Capital lock on Capital lock off Function key emulation enable Function key emulation disable Send number as normal data Send number as keypad data End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 56 ’ ANUAL Start Of Configuration Message Terminator Keyboard terminator---none Keyboard terminator---Enter Keyboard terminator---H-TAB End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 57 Keyboard language support---GERMANY Keyboard language support---FRENCH send scan code Keyboard language support---SPANISH send scan code Keyboard language support---Japanese Keyboard language support---ITALIAN Message Terminator Keyboard terminator---none Keyboard terminator---Enter Keyboard terminator---H-TAB End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 58  Wand Emulation signal when not in use Idle = low Idle state refers to the TTL logic level of the  Wand Emulation signal when not in use End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 59 This option allows the transmission of wand emulation at 300us narrow element width Wand emulation speed-----higher This option allows the transmission of wand  emulation at 100 us narrow element width End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 60 Codabar start/stop character transmission－ a/t,b/n,c/*,d/e CB09 Codabar maximum length setting CB10 Codabar minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 61 Validate modulo 16,but don’t transmit CB15 Validate modulo 16 and transmit DC50 Codabar data redundant check=off DC51 Codabar data redundant check=1 DC52 Codabar data redundant check=2 DC53 Codabar data redundant check=3 End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 62 Code 39 data redundant check=2 DC03 Code 39 data redundant check=3 3901 Standard code 39 3902 Full ASCII code 39 3903 Code 39 start/stop character transmission 3904 Code 39 start/stop character without transmission End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 63 Confirm to save this setting (required for reading full ASCII table and length setting) 3912 Code 32 (Italian pharmacy) transmit “A” character 3913 Code 32 (Italian pharmacy) without transmit ”A” character End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 64 ASCII table and length setting) 9303 Code 93 check digit calculate but without transmit 9304 Code 93 check digit not calculate and without transmit 9305 Code 93 check digit calculate and transmit End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 65 Calculate and transmit 1806 Code 128 maximum length setting 1807 Code 128 minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 66 Chinese post code data redundant check=3 SZ01 Chinese post code maximum length setting SZ02 Chinese post code minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 67 MSI/Plessy double check digit calculate but only first digit transmit MS06 MSI/Plessy double check digit calculate and both transmit MS07 MSI/Plessy single check digit calculate but without transmit MS08 MSI/Plessy single check digit calculate and transmit End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 68 Two Check for Code 11 check digit if code length is longer than 10 characters 1106 Disable verification 1107 Code 11 check digit transmitted 1108 Code 11 check digit not transmitted End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 69 IT03 ITF 2 of 5 no check character IT04 ITF 2 of 5 check digit calculate and transmit IT05 ITF 2 of 5 check digit calculate but without transmit End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 70 ITF 2 of 5 two fixed length setting Confirm to save this setting (required for reading full ASCII table and length setting) IT08 ITF 2 of 5 length variable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 71 Standard 2 of 5 code no check character D054 Standard 2 of 5 code check digit calculate and transmit D055 Standard 2 of 5 code check digit calculate but without transmit End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 72 Industrial 2 of 5 code no check character D254 Industrial 2 of 5 code check digit calculate and transmit D255 Industrial 2 of 5 code check digit calculate but without transmission End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 73 EAN-8 or EAN-13 enable UE03 UPC-A and EAN-13 enable UE04 UPC-A and UPC-E enable UE05 UPC-A enable UE06 UPC-E enable UE07 EAN-13 enable UE08 EAN-8 enable UE09 UPC/EAN Addendum disable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 74 Transmit UPC-A check digit disable UE19 Transmit UPC-E leading character enable UE20 Transmit UPC-E leading character disable UE21 Transmit UPC-E check digit enable UE22 Transmit UPC-E check digit disable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 75 EAN-13 with first 0 ID code same as “UPC-A” UE67 EAN-13 with first 0 ID code same as “EAN-13” DC10 UPC-A data redundant check=off DC11 UPC-A data redundant check=1 End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 76 DC24 EAN-8 data redundant check=off DC25 EAN-8 data redundant check=1 DC26 EAN-8 data redundant check=2 DC27 EAN-8 data redundant check=3 UE32 EAN/UPC +add-on (none mandatory) UE33 EAN/UPC +add-on (mandatory) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 77 (Supplement requirement, optional for other) UE42 EAN/UPC +addon mandatory for 491 Japanese bookland (Supplement requirement, not sent for other) UE43 EAN/UPC +addon mandatory 491 Japanese bookland (Supplement requirement, optional for other) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 78 ’ ANUAL Start Of Configuration Telepen Parameter Setting Barcode Barcode Label Description Value RC25 Telepen enable RD25 Telepen disable TE03 Telepen numeric mode enable TE04 AIM Telepen enable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 79 D153 Matrix 2 of 5 no check character D154 Matrix 2 of 5 check digit calculate and transmit D155 Matrix 2 of 5 check digit calculate but without transmission End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 80 Transmit GS1 DataBar Omnidirectional application ID (01) SS03 Do not transmit GS1 DataBar Omnidirectional application ID (01) SS05 GS1 DataBar Omnidirectional /EAN-128 emulation enable SS04 GS1 DataBar Omnidirectional /EAN-128 emulation disable End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 81 Transmit GS1 DataBar Limited check digit SS11 Don’t transmit GS1 DataBar Limited check digit SS12 Transmit GS1 DataBar limited application ID (01) SS13 Do not transmit GS1 DataBar limited application ID End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 82 GS1 DataBar Expanded check digital enable SS09 GS1 DataBar Expanded check digital disable SS16 Transmit GS1 DataBar Expanded application ID (01) SS17 Do not transmit GS1 DataBar Expanded application End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 83: Data Editing

    CI05 UPC-A identifier code setting CI06 EAN-13 identifier code setting CI07 EAN-8 identifier code setting Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 84 Standard 2 of 5 identifier code setting CI18 Matrix 2 of 5 identifier code setting Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 85 CP12 Header (Preamble) HT01 Trailer (Postamble) HT02 Truncate header character HT03 Truncate trailer character HT04 Confirm to save this setting (required for reading full ASCII table and length setting) End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 86: Full Ascii Code 39 Table

    Full ASCII ---FF Full ASCII ---ESC Function key-----“PgUp” Function key-----“F11” Full ASCII ---CR Full ASCII ---FS Function key----- Function key-----“F12” “Enetr(num.)” Full ASCII ---SO Full ASCII ---GS Function key-----“PgDn” Function key-----“ESC” End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 87 Full ASCII --- ( Full ASCII ---7 Full ASCII ---) Full ASCII ---8 Full ASCII ---* Full ASCII ---9 Full ASCII ---+ Full ASCII ---: Full ASCII ---, Full ASCII ---; End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 88 Full ASCII ---F Full ASCII ---U Full ASCII ---G Full ASCII ---V Full ASCII ---H Full ASCII ---W Full ASCII ---I Full ASCII ---X Full ASCII ---J Full ASCII ---Y End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 89 Full ASCII ---d Full ASCII ---s Full ASCII ---e Full ASCII ---t Full ASCII ---f Full ASCII ---u Full ASCII ---g Full ASCII ---v Full ASCII ---h Full ASCII ---w End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...
  • Page 90 Code 39 ASCII code code Full ASCII ---x Full ASCII ---| Full ASCII ---y Full ASCII ---} Full ASCII ---z Full ASCII ---~ Full ASCII ---{ Full ASCII ---DEL End Of Configuration CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 91: Appendix 1: Usb Virtual Com Driver Installation

    Enable USB virtual COM port with programming barcode on page 29. After the programming, the host would request driver installation. Browse your files to locate the driver and start installation. The USB virtual COM port is ready for use after driver installation. CS 2000 BT Wireless Handheld Gun Type Scanner...

  • Page 92: Appendix 2: Barcode Length Setting

    Use the ASCII table (Appendix 4) to set up barcode length. Be sure to enable the full ASCII code 39 option before you start and read the “Set” label to set your choice into memory. CS 2000 BT Wireless Handheld Gun Type Scanner...
