2-WAY REMOTE CONTROL
RF KIT
U S E R M A N U A L
MODEL AF-RFK5225
2-WAY E-XRT 5-button remote
with LCD display
(FRANÇAIS AU VERSO)
PATENT N
OS
CAN 1.130.426
USA 4.345.554 - 5.614.883
- 5.617.819 - 5.673.017
AND OTHER PATENTS PENDING
All rights reserved ® Directed Electronics Canada Inc. 2011
March 2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AstroStart AF-RFK5225
Summary of Contents for AstroStart AF-RFK5225
- Page 1 2-WAY REMOTE CONTROL RF KIT U S E R M A N U A L MODEL AF-RFK5225 2-WAY E-XRT 5-button remote with LCD display (FRANÇAIS AU VERSO) PATENT N CAN 1.130.426 USA 4.345.554 - 5.614.883 - 5.617.819 - 5.673.017 AND OTHER PATENTS PENDING All rights reserved ®...
-
Page 2: Government Regulations
Consult the dealer or an experienced radio / TV technician for help. Warning: Changes or modifications not expressly approved by Directed Electronics Canada Inc. could void the user's authority to operate the equipment. Directed Electronics Canada Inc. 2750, Alphonse-Gariepy ave. Lachine, QC, H8T 3M2, Canada WWW.ASTROSTART.COM... -
Page 3: Table Of Contents
SER GUIDE FOR REMOTE SYSTEM Models AF-RFK5225 & AF-RFK623 are remote controls that offer basic start functions including all the features required to achieve safe remote starting. They also offer central locking features that allow you to control the door locks as well as releasing the trunk. -
Page 4: Safety Precautions
• Do not allow any person or animal to remain inside the vehicle when the engine is running remotely (continuous mode). • Immediately report any malfunction to the AstroStart dealer that performed the installation. • Under no circumstance can this product or its use be modified. -
Page 5: The 2-Way 5-Button Remote Control With Lcd Display
THE 2-WAY 5-BUTTON REMOTE CONTROL WITH LCD DISPLAY This remote control can control three separate vehicles. A maximum of four remote controls can be assigned to a vehicle. See your dealer for additional remote controls. 5225 Front view Antenna LCD screen Side buttons Lock button Unlock button... -
Page 6: The Battery
THE BATTERY Your remote is powered by an internal rechargeable battery that can only be serviced by an authorized Directed dealer. Due to transit and storage time prior to your purchase, the battery charge may have depleted. To ensure proper operation, check the battery level and connect the 8602T battery charger if not fully charged. - Page 7 BATTERY DISPOSAL Directed Electronics cares about the environment. If you need to dispose of the battery, please do so in accordance with your municipal requirements for battery disposal or send it back to us at: Directed Electronics Canada Inc. 2750, Alphonse-Gariepy ave. Lachine, QC, H8T 3M2, Canada (Shipping and/or handling costs are the sole responsibility of the...
-
Page 8: 5225 - Confirmations Emitted By The Remote
5225 – CONFIRMATIONS EMITTED BY THE REMOTE AN AUDIBLE AND A VISUAL CONFIRMATION ARE EMITTED EACH TIME A COMMAND IS TRANSMITTED The LCD displays the vehicle status at all time. It is refreshed on every transmission or when the status of the vehicle changes, unless the “Status confirmation” function is disabled. -
Page 9: Lock/Unlock Commands And Alarm System Arming/Disarming
Two types of confirmations are displayed on the remote: Command confirmation: These confirmations are command acknowledgements. The icon corresponding to the command is displayed to confirm the reception of the command. Status confirmations: These confirmations are displayed when the status of a monitored zone changes: door opening, alarm state, etc. -
Page 10: Start Commands (For Remote-Start Capable Systems Only)
If you are not sure you have received confirmation, repeat the command. The system will repeat the confirmation as often as you wish. PANIC Panic mode is used to attract attention in a situation of emergency. Press and hold for at least 4 seconds to trigger the panic mode of your vehicle. Refer to your vehicle’s owner’s manual for your available options. -
Page 11: Advanced Features
STOP When the engine is running remotely, you can turn it off by performing a stop command. ADVANCED FEATURES STATUS When this command is sent, the vehicle checks the status for the engine, the protection zones and for the locks, then retransmits this information to the remote control. The results show up on the LCD display through a combination of pictograms and text in the text field. -
Page 12: Setting The Remote Control
SETTING THE REMOTE CONTROL Certain functions on the remote may be set to your convenience. To access the remote control programming mode, press the button located on the side of the remote and hold it for four (4) seconds. The remote will emit one long tone. Release the button. The text field will change to the remote settings menu. - Page 13 REMOTE TRANSMITTER PROGRAMMING TABLE Setup Settings Comment ON (Locked) Keypad Keypad Lock/Unlock OFF (Unlocked) To receive vehicle page Page information. Upon "Status" command Light Upon any command Turn backlight on or off Never Button Button sounds Hour Clock To adjust clock time Minute To choose the desired backlight Colour...
-
Page 14: Table Of Commands
TABLE OF COMMANDS Check all that apply Confirmations Commands Button Remote Start small Stop Stop Lock / Arming Locked Panic (Button held for > 4 sec.) Panic Unlock / Disarming Unlock Trunk (Button held for > 4 sec.) Trunk Activate / Cancel Utility 1 Status Activate / Cancel Utility 2 On remote only: 1 beep for car 1... -
Page 15: Glossary
SAFETY CHECKS In order to maintain a high safety standard, proceed with the following checks every month. HOOD SWITCH • Remote start your vehicle. • Open the hood. The engine should stop as soon as the hood is opened. If the engine does not stop immediately, turn the main switch to the OFF position and leave it off until the situation is rectified. -
Page 16: Warranty
ASTROSTART® RECEIVER & TRANSMITTERS -- (COMPONENT) Directed Electronics Canada, Inc. warrants to the original end-user purchaser that any AstroStart Receiver or Transmitter (Component) part provided contempora- neously with the main Product (Module) shall be free of defects in materials and/or workmanship for a period of two (2) years from the date of purchase, provided the original end-user purchaser owns the vehicle that the main Product (Module) the Component was provided for, remains continually installed in the vehicle.
