Summary of Contents for Samsung GT-B5702
-
Page 1: Table Of Contents
GSM TELEPHONE GT-B5702 GSM TELEPHONE CONTENTS 1. Safety Precautions 2. Specification 3. Product Function 4. Array course control 5. Exploded View and Parts list 6. MAIN Electrical Parts List 7. Disassembly and Assembly Instructions 8. Block Diagrams 9. PCB Diagrams 10. -
Page 2: Safety Precautions
● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 3 ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 4: Specification
2. Specification 2-1. GSM General Specification GSM900 DCS1800 PCS1900 GSM850 F req. 880~915 824.2~848.8 1710~ 1785 1850~ 1910 Band[ MHz] 925~960 869.2~893.8 1805~ 1880 1930~ 1990 Uplink/Downlink 0~124 & ARFCN r ange 128~251 512~ 885 512~ 810 975~1023 Tx/Rx spa cing 45MHz 45MHz 95MHz... -
Page 5: Gsm Tx Power Class
Speclflcation 2-2. GSM Tx Power Class TX Power TX Power TX Power GSM850 DCS1800 PCS1900 GSM900 control level control level control level 30±3 dBm 33±3 dBm 30±3 dBm 31±3 dBm 28±3 dBm 28±3 dBm 29±3 dBm 26±3 dBm 26±3 dBm 27±3 dBm 24±3 dBm 24±3 dBm... - Page 6 Speclflcation 2-3. GSM EDGE TX power class Only in Master TX Power TX Power TX Power GSM900 DCS1800 PCS1900 GSM850 control level control level control level 27±3 dBm 26±3 dBm 26±3 dBm 25±3 dBm 24±3 dBm 24±3 dBm 23±3 dBm 22±3 dBm 22±3 dBm 21±3 dBm...
-
Page 7: Product Function
- Stereo Bluetooth Headset - Music player - MP3, AAC, MP4, 3GPP Decoding - SMS/MMS/E-Mail - FM Radio & Recording - Wap 2.0 - Java Games SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 8: Array Course Control
4. Array course control 4-1. Software Downloading Test Cable (GH39-01160A) Test Jig (GH99-36900A) RF Test Cable (GH39-00985A) Adapter (GH99-38251A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 9 4. Select the file(s) what you want to download -if you select MASTER, select the file "B5712_Master.ooo" -if you select SLAVE, select the file "B5712_Slave.ooo" SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 10: Exploded View And Parts List
QCR03 QSH02 QME01 QMP01 QKP02 QMI01 QSH01 QLC01 QMO01 QCA01 QSP01 QAN02 QAN03 QME16 QCR72 QVO01 QRE01 QCK02 QCK01 QFL01 QHI01 QIF01 QCR60 QCR72 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 11: Cellular Phone Parts List
QIF01 PMO COVER-IF GH72-50133A QCK02 PMO KEY-SWITCH GH72-50137A QCK01 PMO KEY-CAMERA GH72-50138A QVO01 ASSY KEY-VOLUME GH98-11273A QAN03 INTENNA-GT-B5702_SLAVE GH42-01836A QAN02 INTENNA-GT-B5702_MASTER GH42-01837A QCR72 SCREW-MACHINE 6001-002051 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 12: Main Electrical Parts List
U301 1106-001588 UME400 IC-SRAM 1108-000256 UME300 MEMORY PAM100 1201-002742 1201-002742 PAM600 U800 1203-005235 1203-005512 U303 1203-005728 U300 1204-003020 U102 1205-003082 UCP700 1205-003283 U600 1205-003419 U103 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 13 R-CHIP 2007-000148 R403 R-CHIP 2007-000148 R504 R-CHIP 2007-000148 R604 R-CHIP 2007-000148 R700 R-CHIP 2007-000148 R702 R-CHIP 2007-000149 R217 R-CHIP 2007-000152 R506 R-CHIP 2007-000159 R318 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 14 R-CHIP 2007-007193 R512 R-CHIP R303 R-CHIP 2007-007573 2007-007589 R221 R-CHIP 2007-007875 R315 R-CHIP R314 R-CHIP 2007-007981 2007-008354 R222 R-CHIP 2007-008354 R304 R-CHIP C101 C-CERAMIC,CHIP 2203-000233 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 15 C-CERAMIC,CHIP 2203-000438 C133 C-CERAMIC,CHIP 2203-000438 C134 C-CERAMIC,CHIP 2203-000438 C205 C-CERAMIC,CHIP 2203-000438 C628 C-CERAMIC,CHIP 2203-000466 C103 C-CERAMIC,CHIP 2203-000466 C615 C-CERAMIC,CHIP 2203-000466 C618 C-CERAMIC,CHIP 2203-000585 C137 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 16 C-CERAMIC,CHIP 2203-002709 C815 C-CERAMIC,CHIP 2203-005050 C106 C-CERAMIC,CHIP 2203-005050 C109 C-CERAMIC,CHIP 2203-005050 C610 C-CERAMIC,CHIP 2203-005050 C612 C-CERAMIC,CHIP 2203-005053 L600 C-CERAMIC,CHIP 2203-005055 C206 C-CERAMIC,CHIP 2203-005055 C209 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 17 C-CERAMIC,CHIP 2203-005482 C710 C-CERAMIC,CHIP 2203-005482 C712 C-CERAMIC,CHIP 2203-005482 C714 C-CERAMIC,CHIP 2203-005482 C808 C-CERAMIC,CHIP 2203-005483 C218 C-CERAMIC,CHIP 2203-005483 C715 C-CERAMIC,CHIP 2203-005552 C141 C-CERAMIC,CHIP 2203-006048 C129 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 18 C-CERAMIC,CHIP 2203-006208 C805 C-CERAMIC,CHIP 2203-006208 C811 C-CERAMIC,CHIP 2203-006257 C124 C-CERAMIC,CHIP 2203-006257 C127 C-CERAMIC,CHIP 2203-006257 C800 C-CERAMIC,CHIP 2203-006257 C801 C-CERAMIC,CHIP 2203-006257 C804 C-CERAMIC,CHIP 2203-006257 C810 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 19 C-CERAMIC,CHIP 2203-006399 C314 C-CERAMIC,CHIP 2203-006399 C315 C-CERAMIC,CHIP 2203-006399 C317 C-CERAMIC,CHIP 2203-006399 C321 C-CERAMIC,CHIP 2203-006399 C328 C-CERAMIC,CHIP 2203-006399 C353 C-CERAMIC,CHIP 2203-006399 C355 C-CERAMIC,CHIP 2203-006399 C423 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 20 C-CERAMIC,CHIP 2203-006890 C343 C-CERAMIC,CHIP 2203-006890 C803 C-CERAMIC,CHIP 2203-006901 C512 C-CERAMIC,CHIP 2203-007195 C335 C-CERAMIC,CHIP 2203-007195 C354 C-CERAMIC,CHIP 2203-007240 C817 C-CERAMIC,CHIP 2203-007279 C215 C-CERAMIC,CHIP 2203-007279 C516 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 21 2703-003297 L800 INDUCTOR-SMD 2801-004373 OSC300 CRYSTAL-UNIT 2801-004787 OSC100 CRYSTAL-UNIT 2801-004787 OSC600 CRYSTAL-UNIT 2901-001408 F500 FILTER-EMI 2901-001423 F501 FILTER-EMI 2901-001423 F502 FILTER-EMI 2901-001423 F503 FILTER-EMI 6-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 22 3710-002683 IFC500 CONNECTOR-SOCKET 3711-006010 HDC500 CONNECTOR-HEADER 3711-006228 BTC500 CONNECTOR-HEADER 4202-001463 ANT102 ODBTP3015 GH70-03349A SC801 ONBOARD-CLIP-6 GH70-03349A SC802 ONBOARD-CLIP-6 GH70-03349A SC803 ONBOARD-CLIP-6 GH70-03349A SC808 ONBOARD-CLIP-6 6-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 23 NPR-CONTACT GH71-08426A ANT101 NPR-CONTACT GH71-08426A ANT601 NPR-CONTACT Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. 6-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 24: Disassembly And Assembly Instructions
PBA FPCB and will separate the PCB - MAIN FPCB carefully the separation of the damage is so CONNECTOR. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 25 FPCB Connector 1) Separate attention to the Hook 1) Unscrew 4 points in the Lower case. 2) Lower PCB connector to carefully separate damage SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 26 1) Remove the Main FPCB Tape tape. 2) Main/Camera FPCB separation after the Connector Open 1) Separate Subkey pad after Separate 1) Complete separation LCD. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 27 Exploded View and Parts List 1) Unscrew 3 points in the Lower case. 1) Top Shield Can Separation 2) Separator the motor note Tape SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 28 1)Top Shield can be assembled in the PBA 2) should be attached to the motor Clip 1) Sub KeyPAD assemble in the PBA 1)LCD is assembled in the Upper. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 29 2) Tape should be attached to LCD Conn. 2) Lower Assembly to pay attention to Lower hook. 1) Insert the FPCB Connector attention to 1) Screw the Lower 4 point damage. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 30 2) Main KEYpad assembly.. -Sure FPCB & PBA Connector assembly! 1) PBA signed a Screw hole and landed 1)Assembly Upper Assy & Rear in the attenntion. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 31 Exploded View and Parts List 1)Screw 4 point in the Rear. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 32: Block Diagrams
Block Diagrams 8-1. Block Diagram SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 33: Pcb Diagrams
C206 C422 R300 R212 C208 C423 R211 UME300 R210 C202 C205 TP304 SC812 F502 F503 F501 F504 F505 ZD500 TP_CS_NAND BH405 BH404 R419 BH403 STAR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 34 C138 R512 U103 C330 REF_ON_PMU C143 C148 C146 R113 R101 L103 R102 L104 C40 0 C40 5 C411 L40 0 L402 ZD400 ZD401 MIC400 C141 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 35: Chart Of Troubleshooting
Check the clock signal at OSC of MAX8699 Check the clock Check the clock generation circuit Freq = 32.768kHz (related to OSC300, C331, C334) Check the initial operation 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 36 R307 OSC300 C321 C334 C331 L301 C338 C343 C313 C311 C315 C317 C322 C300 C355 C323 C332 C333 C326 C327 C335 R303 C342 C319 10-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 37 The voltage is "High" at the Check the U300 C314, C303 LCD display is O.K Check the part Sound is O.K Check the AUDIO part 10-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 38 R307 OSC300 C321 C334 C331 L301 C338 C343 C313 C311 C315 C317 C322 C300 C355 C323 C332 C333 C326 C327 C335 R303 C342 C319 10-4 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 39: Sim Part
C200 SIMIO_M SIM_IO_1 +SIMVCC_S COMD SIMIO_S +SIM_VCC_1 SIM_SEL A-B_IN +SIMVCC_M SIM200 C-D_IN SIMCLK_M SIM_CLK_1 SIMRST_S COMB SIM_RST_1 SIMCLK_S SIMRST_M U200 SIM SELECT [MASTER] C214 10-5 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 40 R205 C217 SIMIO_S SIM_IO_2 +SIMVCC_M SIM800 COMD SIMIO_M +SIM_VCC_2 SIM_SEL +SIMVCC_S A-B_IN C-D_IN SIMCLK_S SIM_CLK_2 SIMRST_M COMB U201 SIM_RST_2 SIMCLK_M SIMRST_S SIM SELECT [SLAVE] 10-6 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 41: Microphone Part
Check the reference voltage on mic path Resolder or replace Check the connection MIC MIC400 MIC_BIAS = 2.15V? Check U300 Check mic-path connection Resolder C400,C405,C411 10-7 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 42 ZD400ZD401 R406 R424 R404 C403 C412 C408 C406 MIC400 C413 R401 UCP700 C209 TA400 R702 C213 R212 R211 Slave MIC path Master MIC path 10-8 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 43 Check U300(Audio AMP) of U300 Check UCP200 (Master RCV) Is there any signals at the UCP700 (Slave RCV) J7,H8(SPK), J5,H6(RCV) of U300 UCP (SPK) 10-9 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 44 REFBP ONKEY_N ONKEYB TEST1 RESETB RSTON TEST2 L301 +VDD_GSM_CORE_1.2V OSC300 R314 C340 C341 C342 C339 C334 C343 C333 R315 PMU + DCDC + CHARGER 10-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 45 R307 OSC300 C321 C334 C331 L301 C338 C343 C313 C311 C315 C317 C322 C300 C355 C323 C332 C333 C326 C327 C335 R303 C342 C319 10-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 46: Charging Part
V_EXT_CHARGE ≒ 5V ? Check U300 Is the C342 Voltage = H ? F10, F12 of U300 = H ? Check U300 Check The Battery 10-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 47 PMU + DCDC + CHARGER C334 C331 L301 C338 C343 C313 C311 C315 C317 C322 C300 C355 C323 C332 C333 C326 C327 C335 R303 C342 C319 10-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 48 Resolder or change U102 of UCP200 ? Check U102 Is there any signals at the D6, E6 of UCP200 ? (or Resolder C124, C127) 10-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 49 AGND 32KHz_DIGIT FREF DGND INTX RFGND FM_ANT FM RADIO BH406 C515 L500 C349 D300 C509 R502 R223 C354 R307 OSC300 C321 C334 C331 L301 10-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 50 Pin#1, #3 : 26MHz C129,C103 U101 resolder or change 2.8V ? GSM RX path components GSM900 Receiver is OK? resolder or change 10-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 51 Pin#1, #3 : 26MHz C623,C619 CHECK U600 Pin#VDD1~4 resolder or change 2.8V ? GSM RX path components GSM900 Receiver is OK? resolder or change 10-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 52 Pin#1, #3 : 26MHz C129,C103 U101 resolder or change 2.8V ? GSM1800 Receiver is DCS RX path components resolder or change 10-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 53 Pin#1, #3 : 26MHz C623,C619 CHECK U616 Pin#VDD1~4 resolder or change 2.8V ? GSM1800 Receiver is DCS RX path components resolder or change 10-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 54 Pin#1, #3 : 26MHz C129,C103 U101 resolder or change 2.8V ? GSM1900 Receiver is PCS RX path components resolder or change 10-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 55 Pin#1, #3 : 26MHz C623,C619 CHECK U616 Pin#VDD1~4 resolder or change 2.8V ? GSM1900 Receiver is PCS RX path components resolder or change 10-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 56 UCP200 PAM100 MODE Pin #2="HIGH" Check and Change PAM100 VRAMP U101 Pin #5 = H ? Check and Change Check PAM100 Pin #7=-5dBm U101 10-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 57 UCP700 PAM600 MODE Pin #2="HIGH" Check and Change PAM600 VRAMP U600 Pin #5 = H ? Check and Change Check PAM600 Pin #7=-5dBm U600 10-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 58 UCP200 PAM100 MODE Pin #2="HIGH" Check and Change PAM100 VRAMP U101 Pin #5 = H ? Check and Change PAM100 U104 Pin #6=-5dBm U101 10-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 59 UCP700 PAM600 MODE Pin #2="HIGH" Check and Change PAM600 VRAMP U600 Pin #5 = H ? Check and Change Check PAM600 Pin #7=-5dBm U600 10-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 60 U101 VDD2 VDD3 VDD4 VDD_BAL C130 C131 +VDD_RX_TX_2.8V +VDD_IO_LOW_1.8V REF_ON_PMU C133 BT_CLK C134 D_REF_CLK RFIC_EN R107 RAMP REF_ON_PMU C137 RFIC_RST RF_EN RF_DATA RF_CLK OSC100 10-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 61 C147 PAM100 C126 OSC100 C102 C115 C114 C105 C108 C106 C109 C110 C111 C134 C118 C133 C122 L100 C101 RFS100 R101 L103 R102 L104 10-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 62 GSM850|900_IN GSM_TX_LB_S GSM850|900_OUT 6 TX_EN PON_PA_S MODE_SELECT_S MODE_SEL BAND_SEL 3 BAND_SEL_S 4 VBATT BYPASS_CAP 9 VBAT BYPASS_CAP 13 PA_RAMP_S VRAMP C611 C629 C613 C614 10-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 63 Flow Chart of Troubleshooting F600 C601 C604 L601 R603 L605 L60 2 L60 3 L604 C621 C623 C620 C611 C622 C619 C625 C629 C614 C627 C628 10-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 64: Reference Data
― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream 11-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 65: Schematic Diagram
U ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ V ● ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ● 12-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 66 U ● ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ● V ● ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ● ● W ● ● ● ● ● ● 12-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 67 Schematic Diagram UME300 Pin Configuration 12-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 68 32KHz_DIGIT VREG2 LPOIN VREG_CTL TST1 C145 BT_POWER_ON VCTRIFP SAMSUNG PROPRIETARY C146 R113 THIS DOCUMENT CONTAINS CONFIDENTIAL Tx(GSM900) PROPRIETARY INFORMATION THAT IS Tx(DCS1800/1900) SAMSUNG ELECTRONICS COS PROPERTY. BLUETOOTH DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 69 RXD1_J_A A_TXD DD_M TXD1_J_A 30 30 DU_M SAMSUNG PROPRIETARY 32 32 34 A_ANT NC2 17 THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 70 R316 SD_CMD SD_DATA(3) SAMSUNG PROPRIETARY SD_DATA(2) THIS DOCUMENT CONTAINS CONFIDENTIAL C351 C357 C358 C359 C360 C361 C350 PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. T- FLASH DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 71 MASTER(HFR) KEY_COL(3) C421 SLAVE(HFR) KEY_COL(4) HFR_P HFR_P_S ZD402 3 X 4 KEY MAIN_KEYLED SAMSUNG PROPRIETARY THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 72 DCS/PCS_TX FM_RADIO MAIN MIC LCD_CAMERA CONNECTOR [60PIN] EAR SPK SAMSUNG PROPRIETARY EAR MIC THIS DOCUMENT CONTAINS CONFIDENTIAL POWER ON PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 73 RF_DATA_S RF_CLK_S EAR MIC POWER ON RFIC_RESET_S C628 CLK26M_REF_S RX_TX_IP_S RX_TX_IN_S RX_TX_QP_S RX_TX_QN_S SAMSUNG PROPRIETARY THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 74 FM_RADIO HA_S(16) IO30 HA_S(17) IO31 MAIN MIC EAR SPK EAR MIC POWER ON SAMSUNG PROPRIETARY THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 75 2.6V AVDD_HFA_2.6V 2.6V SAMSUNG PROPRIETARY VDD_RX_TX_2.8V 2.8V VCC_SYN_2.8V 2.8V THIS DOCUMENT CONTAINS CONFIDENTIAL VDD_GSM_CORE_1.2V 1.2V VDD_PLL_1.2V 1.2V PROPRIETARY INFORMATION THAT IS SIM_VCC_3.0V 3.0V SAMSUNG ELECTRONICS COS PROPERTY. DO NOT DISCROSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG.
- Page 76 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2009. 04. Rev.1.0...
