Summary of Contents for NextBase Plug & Sing Microphone
- Page 1 Portable K@raoke Plug & Sing Portable favorite songs Save your here K@raoke functions are within this swivel ring Insert the Memory Card...
-
Page 2: Table Of Contents
CONTENTS CHAPTER 1: GENERAL INSTRUCTION CONTENTS... IMPORTANT SAFETY INSTRUCTIONS... PACKAGE CONTENTS... CHAPTER 2: BASIC OPERATION CONNECT TO A TV ... CONNECT TO A TV AND A AUDIO AMPLIFIER... TERMINAL CONNECTION... HOW TO PLUG IN AVP CABLE... HOW TO REMOVE AVP CABLE... POWER ON/ OFF ... -
Page 3: Important Safety Instructions
Avoid storing in direct sunlight, in places with high temperature, or in moist areas. If your K@raoke head is covered by hand or your K@raoke is approached to the speaker, a howling sound may be generated. The microphone picking up the sound out from the speaker causes this phenomenon of howling. -
Page 4: Package Contents
PACKAGE CONTENTS Package Contents Package include: K@raoke AC-DC Adapter AVP Cable Operating Manual Memory Card File Conversion Software RCA to 3.5mm Convertor Duet K@raoke Handcarry Bag (Optional Device) (Optional Device) NOTE: Actual products appearance might vary slightly from the pictures shown. General Introduction... -
Page 5: Chapter 2: Basic Operation
BASIC OPERATION Connect to a TV Compostie Inpu t Video Audio E NG Basic Operation Video cable (Yellow) Audio R Audio L White 12V DC adapter 5.5m (length) -
Page 6: Connect To A Tv And A Audio Amplifier
Connect to a TV and a Audio Amplifier Video In Video Audio NOTE: The accessory RCA to 3.5mm convertor that its audio and video ports are not 3.5mm ports. White Video cable (Yellow) Audio In is offered to connect your K@raoke with the device Yellow Basic Operation 5.5m (length) -
Page 7: Terminal Connection
1. Store your favorite songs (MV) in the memory card first 2. Connect your K@raoke with TV and audio device by the AVP cable. 3. Sing together with your family or friends. 1. Insert the memory card 3. Duet microphone (not concluded) NOTE: 1. Your K@raoke can only support Xvid 2. -
Page 8: How To Remove Avp Cable
How to remove AVP cable You only can remove the AVP cable by holding here (The ion terminal) with your fingers. Power ON/ OFF Follow steps1&2 to complete the power connection, and vise versa when disconnection. Your K@raoke can be powered by: Option 1: 12V DC Adapter Option 2: 3xAA Battery (Not included). -
Page 9: Battery Operation
Battery Operation Put batteries inside the battery compartment according to the polarity indicated. batteries from here Note: 1. Ni-MH battery is recommended for using and its playtime (3xAA 2000mAh Ni-MH battery) can be up to 150 minutes. Alkaline batteries also can used but duration varies with quality of alkaline batteries. -
Page 10: Chapter 3: Button Definition
BUTTON DEFINITION 1. Swivel ring Volume control (when playing songs)& direction control (in menu mode). Rotate the swivel ring to do it. 2. Power indicator Blue light: power on. Red light: standby. Red light flashes: low battery power. 3. ON/ OFF switch Turn on or turn off your K@raoke. -
Page 11: Chapter 4: Menu Operation
MENU OPERATION Main menu operation Press MENU button to display main menu screen. It contains 4 item: 、 、 Play List Song List Setting System. Rotate the swivel ring to go to the item you prefer and press ENTER menu. Pla y List E NG Menu Operation... -
Page 12: Song List Operation
Song List Operation Song Selection Select song in the Song List menu. After turning on the power the song list will appear on the screen (You also can access to the song list menu in the main menu), rotate the swivel ring to go to the item you prefer and press ENTER to confirm. -
Page 13: Enter Sleep Mode
4. If finish playing all the selected songs, it will return to the Song List menu automatically. Enter Sleep Mode 1. If the microphone is idle for more than 8 minutes, it will enter sleep mode. 2. Press any button to reactivate it. -
Page 14: Play List Operation
Play List Operation It contains all the selected songs. 0004 Ho tel Califom ia 000 1 big big world 000 2 Say You Say Me 000 3 the weddin g 000 4 Hotel Califom ia 000 5 eyes on me 000 6 hey jud e 000 7 Yesterd ay 000 8 Car eless w his per... -
Page 15: Setting Operation
Rotate the swivel ring to go to the item you prefer and press Then rotate the swivel ring to adjust the value. Press ENTER button again to confirm. 1. Microphone Adjust the microphone's volume. 2. Echo Adjust the echo's volume. 3. Key (Pitch control) Adjust music's key or pitch. 4. Effect... -
Page 16: System Operation
System Operation NTSC 1. Key sound Turn on or turn off the key sound. 2. OSD language There are 8 optional languages: English, German, French, Italy, Spanish, Korean, Japanese and Thai. 3. TV system Choose AUTO, NTSC Syste m Key Soun d Languag e English Francais... -
Page 17: Chapter 5: Others
Others Possible causes The adaptor is not connected well Out of battery(If not connect with the adapter) The value of microphone or the connected device isn t turned on The audio cable is disconnected The connected device is not turned on... - Page 18 -ENG -NB-B0...
