Installation
HL-Series
Tankless Heater Models
HL05
Voltage options:
HL06
208V Single and Three Phase
HL10 & L10
240V Single and Three Phase
HL12
277V Single Phase
HL15 & L15
380V Single and Three Phase
HL18 & L18
415V Single and Three Phase
480V Single and Three Phase

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Storage Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Mounting Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Plumbing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Electric Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Start Up Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Digital Controller Operation . . . . . . . . . . . . . . . . . . . . . . . 10-11
Operational Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Product Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
729 S. Grove St., Delton, MI 49046
TEL: 269-623-6395 • 800-999-4320 FAX: 269-623-6398
sales@keltech-inc.com • www.keltech-inc.com
