Summary of Contents for AstroStart RST-2
- Page 1 TIMER FOR REMOTE STARTER U S E R ' S M A N U A L Model RST-2 Designed for remote starters with negative trigger input Consult Safety Rules before using this product. Manufactured in Canada by : Litho'd in Canada Oct.
-
Page 2: Features And Functions
RST-2 FEATURES AND FUNCTIONS FEATURES Display ..............LCD (lighted) Trigger output maximum capacity........100 mA Maximum power consumption ...........20 mA Dimensions ............2¼" x 2¼" x " ............5.72 cm x 5.72 cm x 1.67 cm Output signal......Negative pulse (1 to 2 seconds) Temperature range .... -
Page 3: Safety Rules
RST-2 SAFETY RULES Before using this product, carefully read the following safety rules. • Immediately report any product malfunction to the Astroflex dealer where that performed installation. • Under no circumstance can this product or its use be modified. • Always turn off remote starter's main switch when vehicle is parked in an enclosed, unventilated area or is in for servicing. -
Page 4: Operation Mode
RST-2 DISPLAY The LCD-type display shows current time of day as well as each scheduled start-up settings. It lights up when a button is pressed and will remain lit for 30 seconds thereafter. OPERATION MODE In Operation Mode, the display shows current time and day of the week, as !)"#... -
Page 5: Clock Setting
RST-2 SETTINGS CLOCK SETTING Press and hold the "CLOCK" button, then press the "DAY" button to select the day of the week, "HOUR" to set the hour, and "MINUTE" to set the minutes. Each selection will increment by one unit every time the corresponding button is pressed. - Page 6 RST-2 The "DAYS" can be grouped in one of the following modes: &) $ &) $ Daily: every day (individually) etc. &) $ MO TU WE TH FR &) $ SA SU &) $ MO TU WE TH FR SA SU Press the "SET"...
- Page 7 RST-2 Now let's suppose you wish to deactivate scheduled start-up nº 2 (10:30 a.m. on weekends) for a certain period of time. Press "SET" button as many times as necessary to reach the scheduled start-up you wish to deactivate, then press the "ON/OFF"...
-
Page 8: Lifetime Limited Warranty
RST-2 LIFETIME LIMITED WARRANTY ASTROFLEX warrants the manufactured product against any defect in workmanship or material for the period specified below. This Warranty excludes any other legal warranty, with the exception of the provisions pertaining to public order. This Warranty only applies in favor of the original purchaser;... - Page 9 RST-2 If the purchaser cannot provide proof of purchase, the Warranty is limited to two years from the manufacturing date as confirmed by the product’s serial number. The purchaser of this ASTROFLEX product shall return the product for warranty service, freight prepaid, to the appropriate address indicated at the end of this document.
- Page 10 8]R 4 ; 4 2 C A > = 8 2 2 > A ? ...
