- Page 1 Operation Manual NEWCON OPTIK ™ 2007 Printed in Canada LONG RANGE LASER RANGE FINDER LRB 20000 In USA: 2331 Superior Ave. Cleveland, OH 44114 In Canada: 105 Sparks Ave., Toronto, ON M2H 2S5...
-
Page 2: Acceptance Certificate
NOTES: 19. ACCEPTANCE CERTIFICATE LASER RANGEFINDER LRB20000 Serial Number___________corresponds to all technical specifications and has passed the quality inspection. Date of production: _____________ Quality Inspector signature: __________________________ Quality assurance seal... -
Page 3: Important Information
• Caution - use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure • Caution - the use of optical instruments such as binoculars, loupes, mirrors, etc. with this product increases eye hazard... -
Page 4: Warranty
Authorized Service. Postage, insurance, or shipping costs incurred in presenting your NEWCON product for warranty service are your responsibility. Please include a cheque or money order made out to NEWCON OPTIK for the amount of $15.00 to cover shipping and handling within North America. -
Page 5: Table Of Contents
If you use Windows 95, 98 or ME: Turn computer on and enter the BIOS SETUP in accordance with the computer documentation. Set the address of LPT port as 378h, and port type as EPP. Register the new settings. After OS on your computer has been loaded, insert the supplied diskette into the floppy disk drive. -
Page 6: Perform Measurements As Described In The Manual. The Results Will Be Shown In The Communicator Program Window
Laser Rangefinder system that provides instant distance measurements consistently and accurately. The stereoscopic device provides convenient observation with both eyes. Therefore, the LRB 20000 eliminates a need for two separate devices (binocular and rangefinder) combining both requirements in a single device. It is designated for industrial- technical purposes, ground surveillance, observation of individual targets and measurement. - Page 7 16. DATA OUTPUT TO EXTERNAL EQUIPMENT The measured data can be exported to a remote computer through the connector X2. To export the output data, you must to apply the voltage of 3 to 8 V from the connected computer to the pin 9 of the connector X2. The amplitude of the output signals will depend on the value of the supplied voltage.
- Page 8 To secure trouble-free operation of the rangefinder: - be prompt in replacing the rechargeable battery by freshly charged when the red LED in the left-hand eyepiece of the range finder starts to illuminate; - keep the range finder dry at all times especially in the cold season of the year;...
- Page 9 15. RECHARGEABLE BATTERY HANDLING 15.1. The rechargeable battery is supplied in discharged condition. 15.2. While handling the battery, be certain to: avoid contact with any bare circuit components while charging the battery; strictly comply with the prescribed charging/discharging procedures. NEVER: dismantle the battery;...
-
Page 10: Technical Characteristics
3. TECHNICAL CHARACTERISTICS Parameter Optics Binocular magnification Binocular angle of vision Eye relief, mm Rangefinder Range measurement limits, m Measurement error, m, max Time of preparation for range measurement after depressing of MEASURE button, s Range information memory storage time, s Emitter Wavelength, nm Output energy, mJ... -
Page 11: Long Term Storage
11.3.5. The individual SPTA set is packed in the case 4 (Fig. 7). The case contains the spare rechargeable battery, pencil, eraser, cloth and coordinate converter. 12. LONG TERM STORAGE To preserve the rangefinder, proceed as follows: cap the rangefinder connectors by paper and tie a cord round; coat the range finder bright work with grease GОI-54P;... -
Page 12: Supplied Accessories
4. SUPPLIED ACCESSORIES Description Designation Rangefinder AEP 41.46.712 Tripod (optional) G 42.14.067 Angular mount G 42.21.812 (optional) Rechargeable 10D-0,55С-1 battery Fuse link VP1-1 1,0 A 250 V Sealing ring G 68.79.193- Framed lens Membrane G 44.21.885 Eye shield AEP 75.48.092 Diaphragm G 47.92.131 Pencil TM, M, CT, T... - Page 13 11.3. To correct problems by using the individual SPTA set proceed as follows (see Fig. 6). 11.3.1. To replace the fuse link 2 in the protection device: Unscrew the threaded cover from the housing of the protection device; Remove the defective fuse link; Insert the spare fuse link from the SPTA set;...
- Page 14 5. PRINCIPLES OF WORK 5.1. The LRB 20000 assembly (Fig.1) consists of rangefinder 1 mounted on the angular mount 2. The latter is mounted on the tripod 3. 5.2. Rangefinder (Fig.2) is designed for terrain observation and measuring the distance to the closest or next-in range target caught in the beam.
-
Page 15: Troubleshooting
- remove the moist silica gel from the case and fill the case with the fresh one. Moist silica gel may be subjected to multiple dehydrations at (120±3) °C without any deterioration of its properties. Using a microwave oven is allowed. To dehydrate the silica gel, proceed as follows: - place the silica gel in a clean metal vessel;... - Page 16 5.3. Angular Mount (Fig. 4) is intended for mounting rangefinder on a tripod, aim the rangefinder to the target and measure the azimuth and elevation values. The main part of the Angular Mount (AI) is body 15, which incorporates the elevation and azimuth worm-gear drives.
-
Page 17: Safety Precautions
AI on a log, a stump, or any similar piece of wood suitable for the job. 6. SAFETY PRECAUTIONS Rangefinder LRB 20000 is an optical-electronic device emitting high-density pulses of invisible light at wavelength of 1.06 µm, characterized by the following dangerous factors: direct laser radiation;... - Page 18 6.2. According IEC 825 standard the rangefinder belongs to the third class device of laser radiation hazard. NEVER: Turn on the rangefinder aiming on people or animals; Measure distance through window and door glasses; Measure distance to mirror-reflecting surfaces (mirrors, car and building windows, optical components, grinded and polished surfaces), which are nearer than 1700 m to the rangefinder;...
-
Page 19: Rechargeable Battery
Operations Procedure Materials, tools and as per accessories 1. Cleaning external Article. Lens Brush No. 7 (made optical surfaces 10.6.2 of synthetic fibre) (when required) Absorbent optical cotton Alcohol 2.Charging of Section 15 rechargeable battery (when required) 10.4. Daily Servicing. 10.4.1. -
Page 20: Preparing For Use Equipment
7. PREPARING FOR USE 7.1. Choose an observation post. 7.2. Rotate the objective frame to bring the reticle to sharp focus. 7.3. Check the battery voltage and the rangefinder before operation. 7.3.1. To analyze the battery voltage, set the ON-OFF selector switch to the ON position and check if the Low Battery indicator glows red in the left-hand eyepiece. -
Page 21: Maintenance
Items to check, test procedure Technical requirement Sensitivity, indexing uniformity and Send the unit for repair if even a balance of the magnetic needle. single requirement of 8.6.2. is not Proceed as directed under 7.6.2. satisfied. AI azimuth and elevation adjustment If necessary, tighten bushings on knobs must not be loose. -
Page 22: Serviceability Test
Rotate the azimuth dial to align the base reference value with the zero wheel. Now the rangefinder is aligned with the base line within 30.00 mils; Turn the clamping handle to lock the azimuth dial in the determined position. 7.5.2. To orient the rangefinder by using the reference directional angle, proceed as follows: Aim the range finder to the reference point, which directional angle is known;... - Page 23 Plot the target on the map using the obtained rectangular coordinates. 8.9. When using the rangefinder under the conditions of insufficient light, set the ILLUM. selector switch to ON. 8.10. If a target is located against an intense background (bright sky, sunlit snow or sand, etc.), the range display may indicate as if more than one target is caught in the beam, and the range indications may differ every time that MEASURE L button is...
- Page 24 The A1 and A2 values are entered with their respective signs. If the ER "0" value is other than zero, the respective correction is to be taken into account while operating the range finder. The error value is subtracted from the elevation measurement, if the latter is positive, and added, if it is negative.
-
Page 25: Operating Procedure
Vertical angles up to 0.80 mils and elevation angles falling within ± 0.40 mils may be read off the reticle with a maximum accuracy of 0.05 mils. 8.7. To determine the polar coordinates, proceed as follows: Use the compass to orient the Angular Mount as directed under 7.5.3;... - Page 26 Determine the measured angle by subtracting the second value from the first one. Binoculars rangefinder unit LRB 20000 in packing case 1 - Angular mount; 2 - Cover; 3- Rechargeable battery 10D- 0,55С-1; 4 - SPTA package; 5 - Cover; 6 - Cable; 7 - Protection device;...
- Page 27 Individual SPTA set 1 - Rechargeable battery 10D-0,55С-1; 2 - Fuse link VP1-1 1,0А 250 V; 3 - Pencil; 4 - Sealing ring; 5 - Eye shield; 6 - Framed lens; 7 - Cloth; 8 - Eraser; 9 - Wrench; 10 - Coordinate converter;...
- Page 28 Laser rangefinder binoculars LRB 20000 Tripod mount 1 - Mounting head; 2 - Base; 3 - Legs; 4 – Nut 1 - Rangefinder; 2 - Angular Mount; 3 - Tripod Fig. 5 Fig. 1...
- Page 29 Angular Mount Rangefinder rear view 1 - Adjustment knob; 2 - Lever; 3 - Bracket; 4 - Retainer; 5 - 1 - Housing; 2 -MEASURE 1 and MEASURE L buttons; 3 - Scale; 6 - Framed lens; 7- Adjustment knob; 8 - Compass; 9 - Belt;...
- Page 30 Fig. 3. Schematic diagram...
