Summary of Contents for Vu+ Solo 2

  • Page 1 English...

  • Page 2: What's Included

    What's included ? Power Adapter RCU Battery Easy Setup Guide HDMI cable Power cord SATA cable...

  • Page 3: Front Panel

    Front Panel Display Standby Displays the current menu and program information. Vu+ Solo2 Door open CI Module slot USB Host Connects to the USB memory stick or external HDD. Smartcard reader slot Two Smartcard slots are provided.

  • Page 4: Rear Panel

    Rear Panel LNB INPUT 1/2 Ethernet Video /Audio Output On/O Switch RS232 TV SCART Power Adaptor Input SCART connector for TV HDMI Connects to TV using a HDMI cable for both audio and video signals. S/PDIF Connects to a digital audio system using S/PDIF cable. NOTE If using one signal cable, use LNB2 input.

  • Page 5: Remote Control

    Remote Control STB Power TV Power Subtitle This button is used Displays the subtitle of when selecting video source of TV. the current channel Mute if the channel provides subtitle. Numeric Keys Teletext Displays the teletext information of the current channel if the channel provides subtitles.

  • Page 6: Connecting Cable

    Connecting Cable 1. Connect Satellite Signal Cable to SOLO2 Vu+ SOLO2 is DVB-S2 Twin Tuner PVR. For the best use of SOLO2, connect two separate satellite cables to LNB 1 & 2. NOTE If using one signal cable, use LNB2 input. 2.
  • Page 7 Connecting Cable 3. Power Up A power cord and an adapter are provided in the accessory box. Plug the round end of the adapter power cord into the power input of SOLO2. NOTE AC input condition • Nominal Voltage Range: 100 – 250 VAC •...
  • Page 8 Run First Time Installation Step 1. Language Selection Please use the UP and DOWN keys to select your language. Afterwards press the OK button. English German Catalan Croatian Step 2. Con guring Satellite Connection Welcome. This start wizard will guide you through the basic setup of your STB. Press the OK button on your remote control to move to the next step.
  • Page 9 Run First Time Installation Use the up/down keys on your remote control to select an option. After that, press OK. Use wizard to set up basic features Exit wizard Use the left and right buttons to change an option. Configuration Mode not configured Using LEFT/RIGHT key, you can choose one of the following Configuration Modes: •...
  • Page 10 Run First Time Installation If you choose Simple configuration mode, the following picture will appear. Use the left and right buttons to change an option. Please set up tuner A. Configuration Mode Simple Mode Single Satellite Astra(19.2E) Send DiSEqC The five modes are available for the satellite cable connection between LNB and your Vu+ as below : •...
  • Page 11 Run First Time Installation Step 3. Channel Scan • Selecting Scan Mode - Automatic Scan / Manual Scan Channel scanning is possible either in Automatic Scan mode or Manual Scan mode. Do you want to do a service scan? Yes, do an automatic scan now Yes, do a manual scan now No, scan later manually •...
  • Page 12 Run First Time Installation Press OK to initiate the channel scan. Service Scan scan done! 2 services found! ANIXE HD ASTRA HD+ • Channel Scanning The scanned channels will be displayed if the previous configurations have been done correctly.

  • Page 13: Service Searching

    Run First Time Installation Step 4. Install Default Service List Here you will be asked whether you want to install the default satellite lists. Press OK and the following image appears: Service Searching Tuner con guration Default services lists Automatic Scan Manual Scan Please choose the default services lists you want to install.
  • Page 14 Step 5. Parental Control Option Here you can choose whether to enable the parental control option. If you press OK, you will be asked to enter PIN number Parental control setup Enable parental control Protect setup Protect services Change pin code New PIN **** Reenter new PIN...
  • Page 15 For more information about SOLO2 1. Go to "Plugins" from Main Menu 2. Click "Opera Web Browser" 3. Go to "Tools" - "Bookmark" 4. Click "User Manual" Easy way to consult the manual: By long pressing 'Help' button, you can also access to On-Screen Manual page.
