USER MANUAL

KT-LL84ULFX-PD, KT-LL84ULFX-PD-NS, LL84ULFX-PD,
LL84ULFX-PD1, LL84ULFX-PD2, LL84ULFX-PD3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sm-u841 and is the answer not in the manual?

Questions and answers

Summary of Contents for Idis sm-u841

  • Page 1: User Manual

    USER MANUAL KT-LL84ULFX-PD, KT-LL84ULFX-PD-NS, LL84ULFX-PD, LL84ULFX-PD1, LL84ULFX-PD2, LL84ULFX-PD3...
  • Page 2 NOTICES COPYRIGHT AND TRADEMARKS Copyright © 2015 IDIS Corporation. All rights reserved. All brand names and product names are trademarks, registered trademarks or trade names of their respective holders. General Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected in this document.
  • Page 3: Table Of Contents

    Table of Contents BEFORE USING THE PRODUCT ...................... 4 SAFETY PRECAUTIONS ........................4 PREPARATIONS ..........................11 PARTS LIST ............................11 CONTROL PRODUCT ........................12 INPUT/OUTPUT CONNECTION ....................14 REMOTE CONTROLLER BUTTON DESCRIPTION ............... 16 INSTALLATION GUIDE ........................17 CAUTION BEFORE INSTALLATION ....................17 PRODUCT SPECIFICATIONS ......................
  • Page 4: Before Using The Product

    Before using the product Before installing or using the product, to avoid damaging the product, read and follow as the  guidelines of the user manual for your safety. The color, design and specification may change without notice to enhance the function. ...
  • Page 5 Do not pull or bend the power cable forcibly. Avoid placing heavy objects on the cables. - If the cable is damaged, it may result in electric shock or a fire. Do not use the power cable near heating appliances and products. - This may cause a fire or electric shock.
  • Page 6 Avoid exposure to direct sunlight and do not place near hot objects such as a fire or heater heat. - This may cause a fire or shortening the product life. Do not install in the low place where a child can touch. - A child may be injured while playing and touching the product.
  • Page 7 When lightning occurs, turn off the power switch and disconnect the power cable. - This may cause a fire or electric shock. Do not drop the product or throw something to the product. - This may cause a fire or electric shock. Do not give a shock or scratch to the screen with sharp objects.
  • Page 8 Caution Do not unplug the power cable while using the product. - This may cause a fire or electric shock. Use only the power cable qualified for the standard. - This may cause a fire or electric shock. Connect the power cable to the nearest outlet. - If having a problem with the product, unplug the power cable completely.
  • Page 9 Turing on the product in the condition of the fixed screen or 4:3 screen for a long time may also cause an afterimage or stain on the screen. - When using the product for a long time, set a screen saver of the connected computer or signaling equipment products or set it in sleep mode.
  • Page 10 Do not place heavy objects on the product. - This may result in a malfunction or an injury. Please put obstacles away from the space between the remote controller and the product. - The product may not be operated by remote controller. The remote control may not be good in this operation under the sun or strong light.
  • Page 11: Preparations

    Preparations Parts List If these items are missing, contact your dealer or service center. The following images may differ from the image shown. Other parts not packed in contents may cause performance degradation or problem during use. HDMI Cable Power Cable Remote AAA 1.5V (Option)
  • Page 12: Control Product

    Control product The following images may differ from the image shown. You can control the product by using the control buttons on the rear side of the • product. ① Control buttons - ① Power on/off button To move to the upper menu or select / ▲...
  • Page 13 Installation of an external remote controller receiver 1. The included external remote sensor should be fixed to external remote sensor on the product by using two screws on the bottom of the left of the front panel. Connect the cable of the external remote controller receiver to IR In connector. Remote Sensor / Power indicator Power on Green...
  • Page 14: Input/Output Connection

    Input/Output connection The items may differ from the image shown. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ Connector name and description Connector Description ① RS-232C In To connect RS232 input cable with control device (3.5Φ) ② Audio Out To connect audio stereo output (3.5Φ) ③...
  • Page 15 Caution When you connect the signal cables to the input / output terminals, check the above • picture of the input / output terminal, and connect in the right direction. If connected incorrectly, it may cause damage or breakdown of the input / output terminals. he power is supplied, check if the power •...
  • Page 16: Remote Controller Button Description

    Remote Controller Button Description Button Description images may differ from the actual items. The following Button not described does not work. POWER Power on/off button SOURCE Select input signal ▲ Move to the upper menu ▼ Move to the lower menu Select to change menu ◀...
  • Page 17: Installation Guide

    Installation Guide Caution before installation Caution Installation must be performed by a qualified custom video installation specialist under the conditional installation environment as below. Ambient Lighting When the sun or strong light shines on the front screen of the product, image contrast •...
  • Page 18: Unpacking Process

    Unpacking Process The following mages may differ from the actual items. Before unpacking the box, refer to the diagram below. Remove the outer packing box. Remove the top foam. Lower down or remove the wrapping. Three or more people, remove the packing from the product.
  • Page 19: Handling Guide

    Handling Guide The following mages may differ from the actual items. Holding a product 1. Right way At least two persons are required to handle the product during transportation. Two persons should hold the each left and right handle of the backside of the product with one hand of the each person and with the other hand, grip the bottom portion of the rear side of the product to move.
  • Page 20 Putting a product 1. Right Way Before putting the product on the floor, prepare flat and soft cushions. Place the product horizontally and slowly on the floor. If firstly laying the edge of the bezel of the product, the screen panel of the product may be fragile or damaged. Cushions 2.
  • Page 21: Product Installation

    Product Installation When installing the product with wall mount, make the product installed by a well- trained technician. Please refer to the User Guide of Wall Mounting. The product has VESA standard of 600 X 600 MM for wall mounting, and of M8 (maximum length of 35mm) of the screws by size.
  • Page 22: Remote Controller

    Remote Controller Inserting batteries in the remote controller Press the tab on the battery case and open it. • • Insert the battery (1.5V AAA) into the battery case. • Insert the battery case until clack sounds. Notice on battery When loading the battery, check if the polarity of the batteries is correct.
  • Page 23: Setup

    Setup Turning on the power 1. Connect the power cable of the product into outlet with AC 100-220V 50 / 60Hz. 2. Turn on the main AC power switch. 3. If the power indicator is green, the screen turns on automatically. 4.
  • Page 24: Remote Control

    Remote Control RS-232C connection Communication conditions Interface RS-232C Txd, Rxd, Gnd Bit rate 19200 bps Data bits 8 bit Parity None Stop bits 1 bit Communication codes ASCII RS-232C Cable Pin Description Stereo D-SUB 9P 3.5Φ (female) Cable connection Connect the RS-232C in port of the product to the PC or the control system. V0.12...
  • Page 25: Communication Command

    Communication Command Direct command It is to send a command to the product to perform the action corresponding to the command. Statement form: [HEAD][SET ID][COMMAND][END] Ex) Power On: [K:][ALL][PON][.] → K: ALLPON. • [HEAD]: Represents the beginning of a statement. Put 'K:' always. •...
  • Page 26 • [COMMAND]: It always consists of 3Bytes. As for command, refer to page 28. • [END]: Represents the end of a statement. Put a '?' always. Reply about the status confirmation command It is to receive a reply from the product about the status command. Statement form: [SET ID][:][COMMAND][=][REPLY] Ex) Power on: [ALL][:][PWR][=][001] →...
  • Page 27: Communication Command List

    Communication Command list Type Command Value Reply Power off Power on Power status Off : 000, On : 001 Mute off Mute on Mute status Off : 000, On : 001 Adjusting volume 000 ~ 100 000 ~ 100 VGA : 000, DVI:001, HDMI1:005, Inputting image HDMI2, 009, DisplayPort: 006 VGA input selection...
  • Page 28: Connect The External Device

    Connect the external device DP (Display Port) Connection If connecting the product to the PC, it supports the VESA Display Data Channel (DDC) • standard. This standard supports "plug and play" function which helps the PC recognize the product automatically to output the optimal resolution. In order to operate the 'plug and play' after connecting the product, connect the video cable of the PC to the product before turning on your PC, and turn on the power of this product first and then turn on the power of the PC.
  • Page 29: Hdmi Connection

    HDMI Connection HDMI input is recommended because it receives a digital signal input from an external • device with HDMI output to ensure high quality of digital signal. , no image may be shown on the screen * Use the cable provided with the product. Otherwise or normal display may not be shown.
  • Page 30: Dvi-D Connection

    DVI-D Connection To see video, connect the product to a PC or an external equipment which outputs • DVI video. If connecting the product to the PC, it supports the VESA Display Data Channel (DDC) • standard. This standard supports "plug and play" function which helps the PC recognize the product automatically to output the optimal resolution.
  • Page 31: Vga Connection

    VGA Connection To see the video, connect D-Sub 15P cable of the PC to the VGA In port of the • product. If connecting the product to the PC, it supports the VESA Display Data Channel (DDC) • standard. This standard supports "plug and play" function which helps the PC recognize the product automatically to output the optimal resolution.
  • Page 32: Menu Control

    Menu Control Input selection Press the Input button and then select ▲ or ▼, or the input you want to select, and then press the ▶ (+) button. Input Description VGA input DVI input HDMI1 HDMI1 input HDMI2 HDMI2 input DISPLAY PORT Display Port input Picture Adjustment...
  • Page 33 The screen menu can be adjusted only in VGA input mode. Menu Sub-menu Description Standard / User To select a picture mode. / Dynamic Brightness To adjust the brightness of the backlight. Contrast To adjust the contrast of white and black. Picture Black level To adjust the brightness of the screen.
  • Page 34: Sound Adjustment

    Sound Adjustment Press the MENU button, and then press the ▲ or the ▼ button to go to the SOUND menu. Press ▶ button to go to the SOUND SETTING menu, and after moving to the menu, and after moving to the menu which you want to move and setup menu sound by pressing ▶(+) or ◀(-) button, then press the MENU button to exit.
  • Page 35: Osd Adjusting

    OSD Adjusting Press the MENU button, then press the ▲ or ▼ button to go to the OSD menu. And press the ▶ button to go to the OSD SETTING menu and press the ▲ or ▼ button to move to a menu which you want to go to and set value by pressing the ▶ (+) or ◀ (-) button and then press the MENU button to exit.
  • Page 36: Adjusting Setting

    Adjusting Setting Press the MENU button, then press the ▲ or ▼ button to go to the Setting menu. And press the ▶ button to go to the Setting menu and press the ▲ or ▼ button to move to a menu which you want to go to and set value by pressing the ▶ (+) or ◀ (-) button and then press the MENU button to exit.
  • Page 37: Information

    Information Press the MENU button, and then press the ▲ or the ▼ button to move to the ABOUT menu. Or press the INFO button on the remote control. Then you can check model name, ID, current input resolution and software version etc. of the product. V0.12...
  • Page 38: Trouble Shooting

    Trouble Shooting The table below provides some general guidelines for trouble shooting problems you may encounter with your product. If the suggested solutions fail to resolve the problem or if you encounter an issue not described here, please contact your dealer or service center.
  • Page 39 Symptoms Checklist Images is not displayed correctly • Ensure the cables are connected in and video or noise is shown on the screen. signal is active. • Change the cable. • Check if a signal with other resolution which the product does not support is input to the product and refer to the details in the page 42.
  • Page 40 Symptoms Checklist The color of VGA screen is • Check to see if the cable connections are loose strange. or missing out. • Try changing the cable. • Connect another product to check if there is no problem, considering the possibility of problem in outer video signal equipment.
  • Page 41: Product Specification

    Product Specification Product specifications are subject to change without notice. Signal Input/Output Analog: 31.5 ~ 67.5 KHz / 50 ~ 71 Hz Horizontal / vertical frequency Digital: 31.5 ~ 91.1 KHz / 50 ~ 71 Hz 1920 x 1080 @ 60 Hz (Analog / DVI) / Input Resolution 3840 x 2160 @ 30 Hz (HDMI / DP) DP(DisplayPort) / HDMIx2 / DVI / VGA / PC In /...
  • Page 42: Supported Resolutions

    Supported Resolutions Resolution Remark 720 x 400 31.5 70.156 26.25 640 x 480 31.469 59.95 25.175 800 x 600 37.879 60.317 48.363 60.004 1024 x 768 56.476 70.069 VESA 1280 x 768 47.396 59.995 68.25 1360 x 768 47.712 60.015 85.5 63.981 60.02...
  • Page 43: Required Information

    Required information 10.1 Prevent image sticking The fixed image (title, menu image, picture, motionless movie etc.) on the screen is maintained for a long time, image sticking may occur. Image sticking may be subject to operating time of still picture. Since the image sticking is not defect but a characteristic of the product, it is restricted from the product warranty.
  • Page 44 V0.12...
