  • Page 1 *Anti-vandal *metal surface *pickproof *waterproof *Mode: DH16A-09DL DH16A-10DT Fashion DH16A-09DT DH16A-11DT Unique Technology Security Access control instruction manual We will remain the right of modification without prior information...

  • Page 2: Front Panel Description

    installation front panel description ② ① Before installing ,position the location where the controller unit is to be mounted , operation according to the following steps: DH16A-10DT 1.open the controller by loosening and removing the ③ back case screw at the bottom using the spline tool . Description 3.use the provided drilling template accurately locate ①...

  • Page 3: Operation

    Operation B. Add the user card and code 1. 2 zones relays can be programmed for opening the lock , up to Enter the setting mode(ZONE 1). 1000 user cards and correlative codes can be stored into ZONE 1, Press one number from 000 to 999,(mode indicator will flash 10 user cards or code can be stored into ZONE 2.
  • Page 4 H. Turn on/off the pickproof alarm E. Set the unlocked time for ZONE 2 Enter the setting mode. Enter the setting mode: Press the button , the mode indicator will flash a.) Turn off the pickproof alarm: yellow, follow the number (from 00 to 99), the mode indicator will Press the button , (mode indicator will flash yellow) turn yellow in the mean time a long beep will be heard, it indicates...

  • Page 5: Wring Diagram

    Wring diagram J. Add the master card Red -power + DC12-15V Enter the setting mode: Black -power GND Press the button ,the mode indicator will flash green, Brown -door status detecting it indicates there is no master card stored ,(if the indicator is turned Orange- unlocking button 1 green ,it indicates there is already data existed, press the button twice to clean out the data, and then the indicator will flash...
