Summary of Contents for Sunroad SR204
- Page 1 Digital Fishing Barometer User Manual...
- Page 2 Digital Fishing barometer Thank you for your purchase of Sunroad SR204 Digital Fishing Barometer. Design Strategy: It has been known that barometric pressure is one of the most important factor to influence fishing. When barometric pressure is higher, DO in the water will be higher, Fish will be active and has a good appetite.
- Page 3 Specifications: Barometer： Range from 300hpa to 1100hpa Hpa and Inhg unit switch available Resolution of 0.1hpa Thermometer： Range from -10℃ to +60℃ ℃ and ℉ unit switch available Resolution of 0.1 degree Data records：6 sets data for fishing places including pressure, time, water depth countdown timer : Range from 0 to 59:59:59.
- Page 4 1. Start Installing the Battery Rotate the back cover counter clockwise, gripping the unit with both hands, using your index fingers and thumbs. Rotate until it stops, then gently pry off the back cover with your fingers, exposing the battery compartment. Note: you may have to squeeze on the outer ring (not the display) and apply force in the clockwise and counterclockwise direction repeatedly (work back and forth) to free the back cover after extended use, due to sweat and other debris.
- Page 5 2. Operating instructions 2.1 Default mode - time mode ● LCD display：weather forecast, temperature, time, date, local air pressure, pressure trend arrow, pressure trend chart, fish icon(if pressure is not fit for fishing, this icon will not display on screen ) etc. Please refer figure 2. ●...
- Page 6 2.2 Setting mode ● Under time mode, long press SET 5 second to enter setting mode, weather icon will be flashed. Press MODE to switch setting items; Press SET to detail item. Long press SET again to save and exit setting mode. In setting mode, if there is no operation in 30 seconds, it will save and exit setting mode automatically.
- Page 7 2.3 Suitable fishing pressure setting ● The default suitable fishing pressure of this unit is 1002hpa. When current air pressure is higher than it, fishing icon will display on screen. ● Different region, different sea level altitude, the fishing pressure will be different also.
- Page 8 2.4 Countdown timer mode ● Under time mode, press button MODE to enter countdown timer mode. ● LCD display weather forecast, temperature， countdown timer, suitable fishing icon. Please refer figure 3. ● Turn on/off countdown : press SET button to turn on/off countdown.
- Page 9 2.5 Altimeter mode ● Under time mode, press MODE two times to enter altitude mode. Sea level ● LCD display: weather forecast, altitude temperature, sea level altitude, Climb climb altitude.Please refer figure 5. altitude ● Climb altitude: Long press MODE to clear climb altitude to zero and start to measure.
- Page 10 2.6 3days history record mode ● Under countdown timer mode, press MODE three seconds to enter 3days history record mode “HISTORY” will display on screen. ● LCD display: weather forecast, highest (lowest) temperature, date, highest (lowest) air pressure, pressure trend chart. Please refer figure 7. ●...
- Page 11 2.7 Pressure of fishing places ● Under time mode, press SET to enter pressure of fishing places mode. ● LCD display: fishing water depth, time, initial record air pressure, fishing place code, fishing icon. Please refer figure 6. ● Press MODE to switch among different fishing places code Figure 8...
- Page 12 2.7.1 Record initial air pressure for fishing place Before tracking air pressure for fishing places, at first time when arriving the fishing place (such as one lake, one river etc.), we should record an initial air pressure. There are two methods to record initial air pressure as below, 1.
- Page 13 2. 7.2 Pressure tracking for fishing place ● Step 1 Link fishing place At fishing place, recording the initial air pressure base on method of item 2.6.1. When coming back usual staying place (such as home or company), please long press MODE to link fishing place under time mode.
- Page 14 2.8 Low Battery Indicator Unit will be alarm every 5 seconds when battery is low power. Remark: Please change battery when low power supply. Otherwise it can not measure pressure accuracy or bring other problems. 2.9 How to know fishing time is coming? 1) Checking fish icon whether display on screen or not.
