- Page 1 Hikvision Technical Manual DS-2CD702PF(NF)(-E) IP Camera Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or...
- Page 3 Hikvision Technical Manual Contents 1. Key Features 2. Specifications 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 4: Key Features
Support TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE, etc. Support IE for Network Preview Support HIKVISION Watermark Support Sensor Alarm Input and Relay Output Support Network Intercom Function Compatible with Current HIKVISION DVR / DVS SDK and Client Software ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 5: Specifications
Adjustment Range 90° Tilt Interface Audio Input 1channel (2.0 ~ 2.4Vp-p, 1kΩ) Audio Output 1 channel (Line level, 600Ω) Communication 1 RJ45 10M / 100M self-adapted Ethernet port and 1 RS-485 interface ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 1 channel relay output Others -10℃ ~ 60℃ Working Temperature Power Supply 12VDC, ±10%, (-E) series support PoE (Power over Ethernet) Power Consumption 4W MAX Dimensions (mm) φ145 × 132.8 Weight 900g ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 7 Hikvision Technical Manual 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
