- Page 1 INSTALLATION AND USER MANUAL FREE STANDING WOODSTOVE TYPE: RETRO...
-
Page 2: Foreword
Foreword Congratulations on the purchase of your new RENY stove. Your choice proves that you care about qual- ity and a functional design. RENY was founded in 1975 and spent the first years specializing in the classic fireplaces. Since 1981 fireplace inserts and freestanding stoves have been manufactured. -
Page 3: Table Of Contents
Table of Contents FOREWORD TABLE OF CONTENTS DESCRIPTION Construction SGI-System Heat transfer The RETRO soapstone Attention to the environment INSTALLATION Dimensions Chimney Converting from top to rear connection Installation Fuel Ventilation First time stoking Lighting Stoking Optimal stoking Fuel consumption... -
Page 4: Description
1.4 The Retro Soapstone edition is a luxury variant to the basic Retro. While the basic Retro can only be supplied with a Soap- stone top, the Retro soapstone is coated with Soapstone entirely. The soapstone coating has the capabil- ity to accumulate heat. -
Page 5: Installation
Installation Have your stove installed by a recognized installer only. He is able to assess your specific situation and provide you with an appropriate advice. 2.1 Dimensions Top connection Rear connection Ø150 2.2 Chimney One of the main components of the stove is the chimney. Together with the chimney, the stove is one unit. The stove can only perform properly if the stove and the chimney have been aligned correctly. -
Page 6: Installation
Remove the lid of the outer sheath a. Unscrew four M6 hexagon socket head cap screws b. Remove the lid Remove the seal plate in the incineration compartment a. Unscrew seven M6 hexagon socket head cap screws b. Remove the seal plate and the reinforcement plate Remove the smoke channel in the incineration compartment a. -
Page 7: Use
• When placing the stove, a distance of at least 1 meter should be observed at the front. The walls next to and behind the stove cannot be made of inflammable material. In addition they also cannot be covered with such materials, unless the distance is more than 30 centimeters on the side and more than 20 centimeters at the rear. -
Page 8: Stoking
3.5 Stoking As soon as the stove has warmed up (after about 15 minutes) the incineration can be controlled. The following points are important: • The primary aeration can be closed. This additional full air supply is only required during the lighting of the stove. -
Page 9: Fuel Consumption
= 7,0 / 3,14 = 2,2 kg. 3.8 Safety With a RENY wood stove, you have purchased a comfortable and safe heat source. The fire safety starts with a proper installation and a correctly working chimney. In addition the following points are important when it comes to to safe heating: •... -
Page 10: Maintenance
Maintenance 4.1 Seals The applied seals consist of ceramic fiberglass tape and cord. Aggressive detergents may corrode these materials. Depending on the frequency of use, these components will wear out. The fiber seals can burn away and / or come loose which may lead to the stove priming ‘false air’. Take care of a timely replace- ment of these seals to allow the stove to remain functioning optimally. -
Page 11: Attachment 1: Cross-Section Stove
Attachment 1: Cross-section stove REAR CONNECTION Lid cover Seal plate of the smoke channel Smoke channel Ø150mm Heat shield Tertiary aeration Vermiculite panel TOP CONNECTION Convection air Smoke channel Ø150mm Secondary aeration control SGI-Spoiler Heat shield Cover of outer sheath Incineration chamber Wood collector Bottom grid... -
Page 12: Attachment 2: Technical Details
Attachment 2: Technical details Technical details Thermal output 7,1 kW Flue system Ø150 mm Content incineration compartment 0,04 m³ Surface bottom incineration compartment 0,11m² Weight 110 kg / 180 kg Firewood (beech wood) Filling 1,5 kg Primary air Secondary air 100% Tertiary air 100%... -
Page 14: Attachment 3: Warranty Certificate
Attachment 3: Warranty Certificate Stove / hearth Type: ……………………………………………………………………………………………………………………………… Serial number: ……………………………………………………………………………………………………………………………… Date of purchase: …………………………………………………………………………………………………………………………… Dealer Name: ……………………………………………………………………………………………………………………………… Street/No.: ……………………………………………………………………………………………………………………………… ZIP code: ……………………………………………………………………………………………………………………………… City: ……………………………………………………………………………………………………………………………… Country: ……………………………………………………………………………………………………………………………… Telephone: ……………………………………………………………………………………………………………………………… Fax: ……………………………………………………………………………………………………………………………… E-mail: ……………………………………………………………………………………………………………………………… Signature: ……………………………………………………………………………………………………………………………… User Name: ……………………………………………………………………………………………………………………………… Street/No.: ………………………………………………………………………………………………………………………………... -
Page 15: Warranty Provisions
Complaints can only be processed when they have been submitted through the dealer to RENY, together with the fully completed warranty certificate and the purchase receipt. We will handle your damage case with care and we will determine whether a warranty claim can be made. -
Page 16: Attachment 4: Eco Label
Attachment 4: ECO label Woodstove Output Capacity and CO-emission Reny Manufacturer: Retro Model: 7,1 KW Nominal capacity: Output classes High output ≥75% 70 - 75% 65 - 70% 60 - 65% 50 - 60% <50% Low output CO-emission Low emission...
