Summary of Contents for Kleenmaid MW4510

  • Page 4 Dear Customer, We would like to thank you and congratulate you on your choice. This new product has been carefully designed and built using top quality materials, and meticulously tested to ensure that it meets all your culinary requirements. Please read and observe these simple instructions, which will enable you to achieve excellent results from the very first time you use it.

  • Page 5: Warnings For Microwave Ovens

    THIS PRODUCT IS DESIGNED FOR DOMESTIC USE. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE DERIVING FROM INCORRECT INSTALLATION OR IMPROPER, ERRONEOUS OR UNSUITABLE USE. THE APPLIANCE MUST NOT BE USED BY PEOPLE (INCLUDING CHILDREN) WITH PHYSICAL, SENSORIAL OR MENTAL IMPAIRMENTS, OR BY PEOPLE WITHOUT THE NECESSARY EXPERIENCE OR KNOWLEDGE, UNLESS THEY ARE SUPERVISED OR INSTRUCTED IN THE USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
  • Page 6 Pots and pans Danger of injury! Porcelain and ceramic crockery can have small holes in the handles and cover. There can be cavities hidden behind these holes. If water gets into these cavities, the crockery could break. Do not use crockery that is unsuitable for microwave ovens. Danger of burns! The heat of the food can heat the dish.

  • Page 7: Causes Of Damage

    Foods with skin or peel Danger of burns! Never cook eggs in the shell. Never heat hard-boiled eggs because they could explode even after the microwave is turned off. This also goes for molluscs and crustaceans. In the case of fried eggs, first pierce the yolk. In the case of foods with a hard peel or skin like apples, tomatoes, potatoes or sausage, the peel or skin could explode.

  • Page 8: Assembling And Disassembling The Flat Grill

    IMPORTANT The oven’s identification plate is even accessible when the appliance is installed. This identification plate, which is visible when you open the door, shows all the information you will need when requesting replacement parts for the appliance. FIRST USE The oven should be thoroughly cleaned with soap and water and carefully rinsed.
  • Page 9 Important: As a safety precaution, before cleaning the oven, always disconnect the plug from the outlet or remove the appliance’s power cord. In addition, avoid using acid or alkaline substances such as lemon, vinegar, salt, tomatoes, etc.). Avoid using products containing chlorine, acids or abrasives, especially for cleaning the painted walls.
  • Page 10 MICROWAVE OVEN M45 Command Overview STANDARD COOKING FUNCTION: from 1 to 5; TEMPERATURE SETTING, COOKING TIME: 19 and 20; ON/OFF + KEY (CHILD LOCK): 27; FUNCTIONS WITH MICROWAVES: from 6 to 12; FUNCTIONS for RECIPES: 11 a 12; POWER AND MENU SCROLL FUNCTIONS: 13 and 14; TIMER FUNCTIONS: 24;...
  • Page 11 INTRODUCTION TO THE OVEN Dear Customer, your new oven is controlled by an electronic board that constantly monitors its operation to improve its performance. The touch controls are state-of-the-art, precise and reliable. The interface is elegant, orderly and discrete, more intuitive than ever! A few buttons, many functions and no combination or sequence is difficult to enter, so you can concentrate on following the recipe and the oven is ready in two clicks! Installation and hook-up...
  • Page 12 Setting the clock The oven will signal that it is connected to the power mains with a double beep. To set the system time, press the “TIMER FUNCTIONS” button for at least 3 seconds Each command activated is confirmed by a beep. Set the clock with the + and - buttons: during setting the separator dots flash, the time has been set when the dots remain steady on.

  • Page 13: Turning On The Oven

    - Setting the “minute-counter” timer function See the appropriate section on page 48. TURNING ON THE OVEN Turn the oven on by pressing the symbol shown in figure. to activate the oven functions, always press except for the light and timer functions, which are independent The command activates all the icons by lighting up their backgrounds.

  • Page 14: Main Functions

    MAIN FUNCTIONS Overview of the command panel Cooking functions Special functions Programming the oven Oven ON/OFF Lock oven ON/OFF Temperature/Power Lock Clock The cooking functions The provides eleven specific cooking functions! To activate a function, just touch the corresponding symbol Each function has a temperature setting selected on the basis of cooking tests of the recipes that are typically used, which can be easily changed based on your own experience.
  • Page 15 Oven functions The oven light is always on during operation in microwave mode and, to save energy, is managed by the system in the other modes. In this type of cooking, a fan located in the rear part circulates warm air inside the oven, distributing it uniformly.
  • Page 16 Simple cooking commands Thanks to state-of-the-art controls, only two touches are required to set a cooking mode: turn on the oven and select the most suitable function for the dish you are about to cook… you choose it and you touch it! The control suggests a temperature for each function, which you can change at any time, but if you consider it suitable, you don’t need to do anything else, the oven will start by itself in just a few seconds! Setting the temperature...

  • Page 17: Programming The Oven

    Use this characteristic to keep foods warm or to complete their cooking gently! Oven light control The oven light control is active in all cooking functions and is independent of them, i.e., it can be turned on or off depending on the need, whenever you want! The oven light is normally kept on during heating and, then, for three minutes after the temperature setting is reached.
  • Page 18 Timer programming: cooking time Touch the timer symbol once and the relative symbol will light up. Plus, the clock display will replace the current time: The separator dots flash to indicate that you can program the cooking time. Once the cooking time is entered, the display will flash the current time again and the “cooking time”...
  • Page 19 Set the end-of-cooking time by touching the “+” and “-” symbols. Once the end-of-cooking time is entered, the display will flash the current time again and the “end-of-cooking time” symbol will be lit. The countdown starts now. When the set time has been reached, the oven will beep and the heating elements will turn off, ending cooking.
  • Page 20 Change the end-of-cooking time to what you want, in our example 13:00 The oven goes to standby mode, turning off the oven light. The control automatically turns the oven on at 11:00 (13:00-2:00) and turns it off at 13:00. The roast will be ready when you return! Programming the timer: minute-counter The minute-counter is a function of the timer that is independent from the operation of the oven, i.e., it does not...

  • Page 21: Operation With Microwaves

    TRADITIONAL COOKING FUNCTIONS Circular heating element with fan. Thermostat setting from 50°C to MAX. Large area grill. Thermostat setting from 50°C to MAX. Circular heating element with fan. Thermostat setting from 50°C to MAX. Double top heating element with fan (large area grill). Thermostat setting from 50°C to MAX. Large area grill.
  • Page 22 Time defrosting Turn the oven on using the button; Select the TIME DEFROSTING function Using the - + buttons, you can change the defrosting time in 5-second intervals. If you press - + for longer than 3 seconds, the time setting speeds up; When finished entering settings, press to began defrosting with a countdown of the time on the display.
  • Page 23 Working Rest time Program Weight (g) time (min) (min) Bread 100 – 800 2 – 19 10 - 20 Vegetables 100 – 500 2 – 13 10 - 20 Meat 100 – 2000 2 – 43 20 - 30 Fish 100 –...
  • Page 24 MANUAL FUNCTION: MICROWAVE + CIRCULAR FAN ELEMENT Turn on the oven with the button; Select the MICROWAVE + CIRCULAR FAN ELEMENT function; Using the keys, you can adjust the pre-set power in 150-W steps, starting from the maximum value of 450 - Confirm the selection with - Then, the upper display will change from the power value to the temperature value.
  • Page 25 The display shows the 2 options: - personal recipes; - preset recipes Choose the desired setting with the buttons; using the button, confirm the choice; the following menu appears; press the buttons to select the type of dish and the button to confirm the choice.
  • Page 26 PERSONALISING RECIPES Once a pre-set recipe has finished, if you decide that the parameters must be changed for the results that you want, you can change the recipe you used and save it for the next time by storing the new parameters used (weight and cooking time).
  • Page 27 - then, after selecting the recipe to be deleted, press until the following screen appears: By default, the selection will be set to NO, but, by pressing the + and - scroll keys, select YES and confirm with - The display tells you that the recipe has been deleted...

  • Page 28: For The Installer

    FOR THE INSTALLER Install the oven in the counter The oven can be installed under a cook top, in a column, or combined with the complementary food-warmer drawer. The dimensions of the space must be those shown in pictures below. The cabinet material must be able to withstand the heat.

  • Page 29: Technical Data

    TECHNICAL DATA Power supply 220-240 V~, 50Hz Maximum absorbed power 3200 W Microwave power 900 W Grill 1500 W Circular Fan Element 1500 W Microwave frequency 2450 MHz ELECTRICAL HOOK-UP Before making the electrical hook-up, make sure that: - the characteristics of the electrical system satisfy what is shown on the serial number plate applied to the front of the oven;...
