  • Page 1 FWA8206 Series Network Appliance User′s Manual Version: 1.1...

  • Page 2: Table Of Contents

    Chapter 10 Installing the 2.5” HDD ....................14 Chapter 11 BIOS Information ......................15 Chapter 12 Bypass Information ....................28 Chapter 13 Factory Default Information ..................31 Chapter 14 GPO LED Information ....................33 Chapter 15 System Architecture ....................36 FWA8206 Series User’s Manual...
  • Page 3 3. Avoid short-circuiting the lithium battery; this can cause it to superheat and cause burns if touched. 4. Do not operate the processor without a thermal solution. Damage to the processor can occur in seconds. 5. Do not block air vents at least minimum 1/2-inch clearance required. FWA8206 Series User’s Manual...

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction The FWA8206 series was specifically designed for the network security & management market. Network Security Applications: • Firewall • Virtual Private Network • Proxy Server • Caching Server Network Management Applications: • Load balancing • Quality of Service •...

  • Page 5: System Specification

    88 mm (H) x 430 mm (W) x mm (D) Operating Temperature : 0 ~ 40℃ Humidity : 20% ~ 90% Environment Storage Environment Temperature : 0 ~ 70℃ Humidity : 5% ~ 95% Chapter 3 Hardware Configuration FWA8206 Series User’s Manual...
  • Page 6 JP2 Pin 1-2 & 3-4 OpenJP1 Pin 2-3 Closed System LANs bypass function controlled by SIO GPIO15. JP1 & JP2 : JP2 Pin 1-2 & 3-4 ClosedJP1 Pin 1-2 Closed (Default) System will reboot upon the time out of watchdog timer. FWA8206 Series User’s Manual...

  • Page 7: Rear Panel Features

    Pin 2-3 Short/Closed: Power on by system button Open: Recovery Rear Panel Features Front Panel Features Note : The NBP LED means None ByPass function. If NBP LED turns on, it indicates Normal mode. If NBP LED turns off, it indicates Bypass mode. FWA8206 Series User’s Manual...

  • Page 8: Chapter 4 Console Mode Information

    2. Customize your name for the new connection. 3. Choose the COM port on the client computer for the connection. 4. Please make the port settings to Baud rate 19200, Parity None, Data bits 8, Stop bits 1 FWA8206 Series User’s Manual...
  • Page 9 5. Power up the FWA8206, and the screen will display the following information. 6. Press <Tab> key to enter BIOS setup screen in Console mode. Press <Del> key to enter BIOS setup screen in mode. FWA8206 Series User’s Manual...
  • Page 10 (Fig. 5-1). Fig. 5-1 Take off screws 2. The top lead (Fig. 5-2) can be removed from the base stand (Fig. 5-3). Fig. 5-2 The top lead Fig. 5-3 The base stand FWA8206 Series User’s Manual...

  • Page 11: Chapter 6 Removing And Installing Dimm

    Fig. 6-1 Eject a DIMM module Fig. 6-2 Install DIMM Note: FWA8206 series support two groups of dual channels memory. One group is on the black DIMM sockets and the other one is on the blue DIMM sockets. (Fig. 6-3) If you would like to upgrade the memory modules, we suggest the height of memory modules don’t exceed 30mm.

  • Page 12: Chapter 7 Removing And Installing Compactflash Card

    Fig. 7-1 Compact Flash Card Fig. 7-2 Insert Compact Flash Card into the CF interface 格式化: 項目符號及編號 The completed installation of CompactFlash Card is shown in Fig. 7-3. Fig. 7-3 Completion of Compact Flash Card connection FWA8206 Series User’s Manual...

  • Page 13: Chapter 8 Removing And Installing The Battery

    Press the metal clip back to eject the button battery (Fig. 8-1). Replace it with a new one by pressing the battery with fingertip to restore the battery (Fig. 8-2). Fig. 8-1 Eject the battery Fig. 8-2 Restore the battery FWA8206 Series User’s Manual...

  • Page 14: Chapter 9 Installing The 3.5" Hdd

    Fig. 9-3 Connect SATA cable and power Fig. 9-4 Connect SATA cable to MB935 connector to 3.5” HDD Fig. 9-5 Fixed HDD bracket and Fix two Fig. 9-6 Fix all four screws back screws back FWA8206 Series User’s Manual...
  • Page 15 Fig. 10-3 Fasten the four screws to lock 2.5” Fig. 10-4 Connect SATA cable and power HDD and bracket together. connector to 2.5” HDD Fig. 10-5 Connect SATA cable to MB935 Fig. 10-6 Fixed HDD bracket and Fix two screws back FWA8206 Series User’s Manual...

  • Page 16: Chapter 11 Bios Information

    Change the day, month, IDE Channel 0 Slave None Year and century IDE Channel 1 Master None IDE Channel 1 Slave None Video EGA/VGA Halt On All Errors Base Memory 640K Extended Memory 129024K Total Memory 130048K FWA8206 Series User’s Manual...
  • Page 17 The system boot will not be halted for a disk error; it will stop for all other errors. All, But Disk/Key The system boot will not be halted for a key- board or disk error; it will stop for all others. FWA8206 Series User’s Manual...
  • Page 18 Floppy, LS120, Hard Disk, CDROM, ZIP100, USB-FDD, USB-CDROM and Disable. Boot Other Device These fields allow the system to search for an operating system from other devices other than the ones selected in the First/Second/Third Boot Device. FWA8206 Series User’s Manual...
  • Page 19 If you set this feature to Disabled, the BIOS will not report the missing floppy drive to Win95/98. Small Logo (EPA) Show The EPA logo appears at the right side of the monitor screen when the system is boot up. The default setting is Disabled. FWA8206 Series User’s Manual...
  • Page 20 In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be On-Chip Frame Buffer Size Memory Allow user to select the amount of system memory pre-allocated by the internal graphics device. FWA8206 Series User’s Manual...
  • Page 21 Enabled Onboard Serial Port 1 3F8/IRQ4 Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal RxD , TxD Active Hi, Lo IR Transmission Delay Enabled UR2 Duplex Mode Half Use IR Pins IR-Rx2Tx2 PWRON After PWR-Fail FWA8206 Series User’s Manual...
  • Page 22 UART Mode Select This field determines the UART 2 mode in your computer. The default value is Normal. Other options include IrDA and ASKIR. Onboard LAN Boot Enable or Disable the Marvell 88E8053 PXE Boot ROM. FWA8206 Series User’s Manual...
  • Page 23 This field sets the IRQ used by the Modem. By default, the setting is 3. Suspend Mode When enabled, and after the set time of system inactivity, all devices except the CPU will be shut off. FWA8206 Series User’s Manual...
  • Page 24 Enable the PNP OS Install option if it is supported by the operating system installed. The default value is No. Reset Configuration Data This field allows you to determine whether to reset the configuration data or not. The default value is Disabled. FWA8206 Series User’s Manual...
  • Page 25 This field allows the user to set the temperature by which the system automatically shuts down once the threshold temperature is reached. This function can help prevent damage to the system that is caused by overheating. FWA8206 Series User’s Manual...
  • Page 26 ), the fan turns to duty cycle. The final phase Smart FAN functionality: 20 ℃ If the CPU is over temperature of approximately (first phase + second phase temperature + ), the fan turns to 100% duty cycle. FWA8206 Series User’s Manual...
  • Page 27 Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility. FWA8206 Series User’s Manual...

  • Page 28: Chapter 12 Bypass Information

    &= 0xef;//Configure bit 4 as 0 to be watchdog function. outb(0x2b,0x4e); outb(i,0x4f); outb(0x7,0x4e); outb(0x8,0x4f);//watchdog in logic device 8 outb(0x30,0x4e);//Active wdt outb(0x1,0x4f); outb(0xf5,0x4e); i = inb(0x4f); i &= 0xf7; outb(0xf5,0x4e); outb(i,0x4f); outb(0xf6,0x4e); outb(1,0x4f);//Set timeout value to inital the normal mode. outb(0xf7,0x4e); FWA8206 Series User’s Manual...
  • Page 29 = i & 0xf7; //Select second outb(0xf5,0x4e); outb(i,0x4f); outb(0xf6,0x4e); outb(TIMEOUT,0x4f); outb(0xf7,0x4e); outb(0x0,0x4f); void retrigger ( void ) { outb(0xf6,0x4e); outb(TIMEOUT,0x4f); /* Disable WDT function */ void dis_wdt ( void ) { outb(0xf6,0x4e); outb(0x00,0x4f); int main(int argc, char **argv) FWA8206 Series User’s Manual...
  • Page 30 Or , call retrigger() for retrigger WDT. */ /* Display countdown */ outb(0xf6,0x4e); c = inb(0x4f); printf("Watchdog countdown %d\n",c); if ( ! c ) { printf("Switch to Bypass mode !\n"); break; //retrigger();//retrigger watchdog //dis_wdt();//Disable watchdog function return 0; FWA8206 Series User’s Manual...

  • Page 31: Chapter 13 Factory Default Information

    //Assign GPIO1 (GP15) outb(0x2a,0x4e); i = inb(0x4f); i |= 0x82; outb(0x2a,0x4e); outb(i,0x4f); //Active logic device 7 outb(0x30,0x4e); outb(0x1,0x4f); //Select I/O mode //Configure GP15 as an input port. outb(0xf0,0x4e); i = inb(0x4f); i &= 0xff; i |= 0x20; outb(i,0x4f); FWA8206 Series User’s Manual...
  • Page 32 ( status == 0 ) { // Check the Factory Default button i++; printf("### MB893 Load Default Setting (%d) ###\n",i); usleep(500000); //You could call your function here to load the //software default value. return 0; FWA8206 Series User’s Manual...

  • Page 33: Chapter 14 Gpo Led Information

    = inb(0x4f); i |= 0xfc; outb(0x2f,0x4e); outb(i,0x4f); //Active logic device 7 outb(0x30,0x4e); outb(0x1,0x4f); //Select I/O mode outb(0xf0,0x4e); i = inb(0x4f); i &= 0x3; outb(0xf0,0x4e); outb(i,0x4f); //Select inversion mode outb(0xf2,0x4e); i = inb(0x4f); i &= 0x3; outb(0xf2,0x4e); outb(i,0x4f); FWA8206 Series User’s Manual...
  • Page 34 = ( flag==1 ?(led | 8) :(led & 0xf7)); outb(0xf1,0x4e); outb(led,0x4f); break; case 5: outb(0xf1,0x4e);//GP14 , LED5 led = inb(0x4f); led &= 0xff; led = ( flag==1 ?(led | 0x10) :(led & 0xef)); outb(0xf1,0x4e); outb(led,0x4f); break; FWA8206 Series User’s Manual...
  • Page 35 ( iopl(3) ) { fprintf(stderr, "iopl(): %s\n", strerror(errno)); return -1; for (;;) { gpo_onoff(1,ON); usleep(200000); gpo_onoff(1,OFF); usleep(200000); gpo_onoff(2,ON); usleep(200000); gpo_onoff(2,OFF); usleep(200000); gpo_onoff(3,ON); usleep(200000); gpo_onoff(3,OFF); usleep(200000); gpo_onoff(4,ON); usleep(200000); gpo_onoff(4,OFF); usleep(200000); gpo_onoff(5,ON); usleep(200000); gpo_onoff(5,OFF); usleep(200000); return 0; FWA8206 Series User’s Manual...

  • Page 36: Chapter 15 System Architecture

    Chapter 15 System Architecture The following block diagram illustrates a basic design reference of MB935, a highly integrated system solution. FWA8206 Series User’s Manual...
