Summary of Contents for Avson MKT Platform
-
Page 1: User Manual
All-in-one GPS + DVD Car Entertainment System (MKT Platform) User Manual Ver. 1.0 (2014-05-30) AVSON MTK User Manual-en Page 1 / 28... -
Page 2: Table Of Contents
8.6 File Path............................14 ........................15 ANGUAGE ETTING 10 S ................15 TEERING HEEL ONTROL ROGRAMMING 11 D & T ......................16 ETTINGS RADIO OPERATION ......................17 GPS NAVIGATION OPERATION..................18 DISC OPERATION......................18 USB / SD OPERATION......................20 AVSON MTK User Manual-en Page 2 / 28... - Page 3 VIRTUAL MULTI CD (OPTION) ..................22 IPOD MUSIC CONNECTION (OPTION)................23 AV-IN OPERATION......................23 BLUETOOTH HANDS-FREE OPERATION................24 BLUETOOTH MUSIC......................25 GPS ANTENNA INSTALLATION..................26 HEAD UNIT INSTALLATION GUIDE AND WIRING DIAGRAM........26 TROUBLESHOOTING......................27 DECLARATION STATEMENTS..................28 AVSON MTK User Manual-en Page 3 / 28...
-
Page 4: Precautions For Use
The DVD/CD module of this device can only play one 12cm disc per time. Do not insert 8cm disc or other object into the device which may cause the laser head or the mechanical parts malfunction. AVSON MTK User Manual-en Page 4 / 28... -
Page 5: Basic Functions
The operations of these functions will be described later in this manual. Slide the homepage to the left or right to bring up additional pages. AVSON MTK User Manual-en Page 5 / 28... - Page 6 OFF, it will stay in OFF mode when the car restarts. If it is in Radio mode, it will continue on the last station selected. If it is in audio or video mode, it will start to play from the last position. AVSON MTK User Manual-en Page 6 / 28...
-
Page 7: Settings
Click Wallpaper to enter background setting menu as below: Flip around the images and select the favourite one. Customized Background If the built-in background images do not meet your requirement, the device allows you to use your own AVSON MTK User Manual-en Page 7 / 28... -
Page 8: Start Up Logo
Select the favorite Boot Logo image by highlighting it and press the “Update” button to activate it. General Settings Select ”Common” to enter the general settings pages. AVSON MTK User Manual-en Page 8 / 28... -
Page 9: Button Beep
Note: if the current deviation is so huge that makes entering the Setting menu impossible, simply Press and Hold the “NAVI” or “GPS” button on the panel will lead to the calibration mode. Display Settings Daytime Brightness Drag the slider to select screen brightness value during the day. AVSON MTK User Manual-en Page 9 / 28... -
Page 10: Night Brightness
The device provides 10 bands of DSP EQ settings and 6 types of EQ pre-sets for user to choose. Personal customized setting is automatically saved in the USER button. Balance Settings Press the balance icon to enter the Balance setting screen. Use the up, down, left and right arrows to AVSON MTK User Manual-en Page 10 / 28... -
Page 11: Loudness Setting
Note: for safety reasons, it is recommended to switch on this setting. Reverse Video Mirrored According to the reverse camera installed, please adjust this setting if the reverse camera image is left and right flipped over. AVSON MTK User Manual-en Page 11 / 28... -
Page 12: Show Time While Video Playing
Show time while video playing If turned on, time will be shown on the top left corner in video playback. If turned off, no time will be shown during video playback. AVSON MTK User Manual-en Page 12 / 28... -
Page 13: Blue-Tooth Settings
If enabled, the Blue-tooth hands-free function will automatically search and connect to the last connected mobile phone at each power up. Auto Answer If enabled, the device will automatically answer any incoming call whenever the Blue-tooth is connected. AVSON MTK User Manual-en Page 13 / 28... -
Page 14: Navigation Settings
GPS card slot. The device will search and list the proper “exe” executable files for user to choose. The proper “exe” file along with its file path must be set up here before the navigation function works. AVSON MTK User Manual-en Page 14 / 28... -
Page 15: Language Setting
4. Press the corresponding button on the screen. When that button turns from red to green, it signified that the button has been programmed properly. 5. Repeat the steps to programme the remaining buttons on the steering wheel. AVSON MTK User Manual-en Page 15 / 28... -
Page 16: Date & Time Settings
If GPS signal is strong, the “GPS Time” function will be available. Press the “GPS Time” button to automatically set the system time. Since GPS time is standard GMT, please select the appropriate time zone to reflect the correct local time. AVSON MTK User Manual-en Page 16 / 28... -
Page 17: Radio Operation
After a favorite radio station is found and in play, press and hold one of the six pre-set buttons in a radio band to save the current radio station in that button. The frequency number will appear on the button indicating the memory action is successful. AVSON MTK User Manual-en Page 17 / 28... -
Page 18: Gps Navigation Operation
When there is no disc in the device, insert a disc into the disc slot will automatically enter the disc reading mode. Where there is a disc in the device, press the “DVD” button on the device panel or the “DVD” icon in the Main Menu to enter the disc reading mode. AVSON MTK User Manual-en Page 18 / 28... - Page 19 Press again to resume the playback. Select by Number Press to bring up the numeric pad. Select a number and press “OK” will jump to the specific song / track / chapter. AVSON MTK User Manual-en Page 19 / 28...
-
Page 20: Usb / Sd Operation
USB / SD Operation This device can play audio, video and picture files in USB Flash Drive and SD card. It supports FAT16 / FAT32 / EXFAT / NTFS format file system. AVSON MTK User Manual-en Page 20 / 28... - Page 21 Repeat and Random Play Press to circle through the various repeat modes; repeat current song → repeat current folder → repeat all music. Press to switch between Random play and Normal Sequence play. AVSON MTK User Manual-en Page 21 / 28...
-
Page 22: Virtual Multi Cd (Option)
Slide up and down and press the disc icon on the left to choose the ripped CD. Press to go to the previous disc and to go to the next disc. Delete Function Press to delete current disc in play and press to delete current song. AVSON MTK User Manual-en Page 22 / 28... -
Page 23: Ipod Music Connection (Option)
AV-IN Operation This Device supports auxiliary Audio/Video Input through the RCA jacks at the back of the head unit. Press the “AV-IN” icon on the Main Menu to enter the AV mode. AVSON MTK User Manual-en Page 23 / 28... -
Page 24: Bluetooth Hands-Free Operation
Switching between Car Speaker and Handset In some occasions, it is inconvenient to have the call broadcast through the car speakers. Press switch between car speaker mode and handset mode. AVSON MTK User Manual-en Page 24 / 28... -
Page 25: Bluetooth Music
This Device supports standard A2DP (Advanced Audio Distribution Profile) for transmitting stereo audio from mobile phone to the Device via Bluetooth connection. It also supports music control functions including "Previous Song", "Next Song" and "Pause / Play" operations. AVSON MTK User Manual-en Page 25 / 28... -
Page 26: Gps Antenna Installation
6. The left and right bracket screws must not exceed 8mm in length. Otherwise, it may damage the components inside the Device. Wiring diagram： Remove the DVD drive protecting screws before installation. Always connect the wires according to the schematic wiring diagram. AVSON MTK User Manual-en Page 26 / 28... -
Page 27: Troubleshooting
Drive the car to other locations to current position There may be very weak or check for GPS reception. If no GPS signal in some area. problem persists, please contact the Dealer. AVSON MTK User Manual-en Page 27 / 28... -
Page 28: Declaration Statements
We reserve the right to enhance any hardware or software in manufacturing without any prior notice. This product has passed the GB/T 19392-2003 General Specification Standard for Car GPS navigation system AVSON MTK User Manual-en Page 28 / 28...
