Summary of Contents for SADiE LRX2
-
Page 2: Connecting The Lrx2
CONNECTING THE LRX2 Your LRX2 will be supplied with a USB2 (A to B) cable, and a 12V DC power supply (PSU), with a mains plug appropriate to your geographical location. Your USB2 cable will have an "A" type end and a "B" type end. -
Page 3: Audio And Timecode Connections
AUDIO AND TIMECODE CONNECTIONS The LRX2 has dedicated AES and Video reference and Timecode in and out connectors. The main audio inputs and outputs are connected via up to three “Slither” cards – each with 2 x 25-way D Type connectors (labelled “AES I/O”, “Mic / line input”... - Page 4 SLITHER PIN-OUTS ANALOGUE AND MIC / LINE Channel 8 HOT Channel 8 COLD Channel 8 GROUND Channel 7 HOT Channel 7 COLD Channel 7 GROUND Channel 6 HOT Channel 6 COLD Channel 6 GROUND Channel 5 HOT Channel 5 COLD Channel 5 GROUND Channel 4 HOT Channel 4 COLD...
- Page 5 AES/EBU DIGITAL Channel 7+8 OUT HOT Channel 7+8 OUT COLD Channel 7+8 OUT GROUND Channel 5+6 OUT HOT Channel 5+6 OUT COLD Channel 5+6 OUT GROUND Channel 3+4 OUT HOT Channel 3+4 OUT COLD Channel 3+4 OUT GROUND Channel 1+2 OUT HOT Channel 1+2 OUT COLD Channel 1+2 OUT GROUND Channel 7+8 IN HOT...
- Page 6 MADI ANALOGUE LEVEL JUMPERS On the Analogue Line Input and Output slithers, the operating level can be chosen, for each Input and Output individually if required, by changing the setting of some jumpers. With the card components-up, 2 x 25way connectors and face plate to the right, just to the left of the connectors, you will see a vertical line of sixteen three-way headers - one for each Input or Output.
-
Page 7: Lrx2 Panel Quick Start
Talkback - pressing and holding this button opens the auxiliary mini-jack input on the right hand side of the LRX2 unit and this (as of v5.5.3) will be monitored on the Mon L/R and Headphone Outputs, and can be optionally set to record a “Slate” to the stereo mixdown stream. - Page 8 Phantom Power is enabled on Microphone inputs by pressing the small “lightning” icon in the left side of the EDL stream. Input Select Inputs are automatically configured based on the input slithers in the system, thus if you had for instance a Mic card in Slot 1 and an AES card in slot 2 then inputs 1-16 would be Mic/Line, and 17-32 would be AES.
-
Page 9: Performance Considerations
PERFORMANCE CONSIDERATIONS The LRX2 is able to record and playback up to 64 channels of 44.1/48K audio material (or 32 of 88.1/96K) but when recording at the high end of the number of channels, you will need to be more careful over the performance of the PC and hard disks that are used for the recordings. -
Page 10: Maximum Record Time
It is quite normal that a laptop that is reserved for exclusive SADiE use will perform better than the same spec PC that is running many other email, word processor, utilities, anti virus software and other audio software applications. Installing other applications (even if they are not running) may degrade the performance of a PC. -
Page 11: Sadie Lrx2 Registration
*Where did you buy the product? *Date of purchase: Where did you hear about the product? What made choose SADiE LRX2? Tick this box if you do not wish to receive offers and product information from SADiE Fax to SADiE UK +44 1353 648867...
