Summary of Contents for HobbyKing x200

  • Page 1 X200 Instruction...
  • Page 2 X200 specific for your needs!

  • Page 3: Touch Screen Operation

    WQV- GA(480*270),65 thou- sand resolution The newly developed dedicated charger operating system iM · OS A whole new OS system for X200 profession- al charger with high efficiency 32 bit processor All in one USB Port High precision Entirely new design Output 5V 2.1V USB...
  • Page 4 OS System Type Current Cells Mode X200 support more Input / Output LiXX 1-6S Fast Charging than 6 type batteries Current NiXX 1-16S Balance charging LiPo / Lilon / LiFe / Charging 0.1-10A Pb 1-10S Charging NiMh / NiCd / Pb Discharging 0.1-3A...
  • Page 5 OS System LiPo Lipo Battery,Single Nominal Voltage: 3.7V,Charge cut-off voltage 4.2V,Dis- charge cut-off voltage 3.0V LiIon LiIon Battery,Single Nominal Voltage: 3.6V,Charge cut-off voltage 4.1V,- Discharge cut-off voltage 2.5V LiFe LiFe Battery,Single Nominal Voltage: 3.3V,Charge cut-off voltage 3.6is- charge cut-off voltage 20.V NiMH NiMH Battery,Single Nominal Voltage: 1.2V,Charge cut-off voltage 1.5V,- Discharge cut-off voltage 1.0V...
  • Page 6 Balance Lipo balance charge use CC-CV charging way. The charger will balance the battery voltage when charging, this only for LiPo battery. Please connecting the balance port when charging and discharging. Support 2-6 cells. Charge Use CC-CV charging way. On the basis of Users setting current the charger will charge the battery to the cut-off voltage.
  • Page 7 X200 Fundamental Function Touch Screen No:201230484397.8 DC IN No:201230484396.3...
  • Page 8 All in one。 The socket name match with the plug,please make sure the right port before using All in one. JST-XH Dean Balance port Glow socket No:201230484397.8 Tamiye JST/BEC No:201230484398.2 XT60 JR/FU Avoiding the switch wires making the balance cable and high current cable into one. It ran perfectly on the very first try.
  • Page 9 Preparing Connecting Using...
  • Page 10 X200 is a professional RC model battery charger,please view the manual before using. If you are a fresh man please read this entire operating manual completely before using. 【Warning: 】The warning of charger operation and disclaimer, Please read and abide by the following terms before operation.
  • Page 11 Extras Including X200 included with 1pcs adapter board,1pcs connect cable and 1 pcs manual. X200 All in one Connect cable Manual Chapter 1 Preparing、Connecting、Using...
  • Page 12 Connecting X200 Please follow the below steps connecting: Please connecting the cable to the adapter port and the X200 DC IN port, and Chapter 1 Preparing、Connecting、Using...
  • Page 13 Connecting the adapter board into the X200 IBP port. 【NOTE】 USB support 5V 2.1A charging voltage,and also use for iPad / iPod / iP- hone / HTC and other intelligent electronic equipment. Both the USB and All in one get charged simultaneously.
  • Page 14 Please make sure the port connect with battery（Other ports are same as it）. Chapter 1 Preparing、Connecting、Using...
  • Page 15 Enter into main interface after accepting( Image 4 ). Start to charge and discharge according to the different battery. Action Bar Information Bar Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells: 2Cells 7.4V Current: Load Save Uset Shart C 2.0A D 1.0A...
  • Page 16 Sample 1:Choose a set of LiPo battery charging,please follow the below steps: Step 1: Touch Type( Image 5 ) Enter into the “Type interface”, and then Touch :LiPo ( Image 6 ) will Enter into main interface go on the next step. Present Setting Type...
  • Page 17 Step 2: Touch ‘Mode’ icon( Image 7 ) to enter into Mode interface. Please choose battery charge mode ( Image 8 ) and go back to main interface to continue setting. Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells:...
  • Page 18 Step 3: Touch Cells icon ( Image 9 ) to enter into Cells interface. Please set battery packs by sliding ( Image 10 ). Touch OK to go back to main interface and continue setting. Image 9 Image 10 【Note】Please set according to suitable battery packs. Chapter 1 Preparing、Connecting、Using...
  • Page 19 Step 4: Touch Current icon ( Image 11 ) to enter into Current interface. Please set charge current by sliding ( Image 12 ). Touch OK to go back to main interface and continue setting. Image 11 Image 12 【NOTE】 Set charge current in charge mode and discharge current in discharge mode.
  • Page 20 Step 5: If you often use the same battery, please touch Save icon ( Image 13 ) to enter into Save interface. Touch Unused icon to save the data and it will be easy for you to charge next time. ( Image 14 ) Image 13 Image 14 【NOTE】You could use this function after you have set Type/Mode/Cells and Current...
  • Page 21 Step 6: You could load your previous data according to X200’s load function. Touch Load icon ( Image 15 ) to enter into Load interface. Choose the data you want to load ( Image 16 ). Image 15 Image 16 Chapter 1 Preparing、Connecting、Using...
  • Page 22 Step 7: Touch Start icon ( Image 17 ) to enter into Start interface. The system will check battery status automatically. If everything is OK, the charger will begin to charge.( Image 18 ) Image 17 Image 18 Chapter 1 Preparing、Connecting、Using...
  • Page 23 【NOTE】The charger will pop-up window when the battery is fully charged. Touch OK to finish charging process ( Image 19 ). Input 3720 12.60V 14.0V Warning 3100 Type 0.30A LiPo 2480 Charge completed! Mode 3000mAh 1860 Balance Cells 1240 28℃ 3 Cells 0620 Time...
  • Page 24 Example 2: If you want to charge a pack of NiMh battery, please execute the oper- ation as follows: Step 1: touch Type icon ( Image 21 ) to enter into Type interface. Touch NiMh icon to go back to main interface and continue setting ( Image 22 ). Present Setting Type...
  • Page 25 Step 2: Touch Mode icon ( Image 23 ) to enter into Mode interface. Touch Charge icon ( Image 24 ) to go back to main interface and continue setting. Image 23 Image 24 【NOTE】 There are four charge/discharge modes in Mode interface( Image 24 ), see iM.OS System function for further details.
  • Page 26 Step 3: touch Cells icon to enter into Cells interface. Please set NiMh battery packs by sliding ( Image 25). Touch OK to go back to main interface and continue setting ( Image 26). Image 25 Image 26 【NOTE】The battery cannot be charged if each pack of the battery voltage is less than 0.7V, please use the less battery packs to activate charging process.
  • Page 27 Step 4: touch Current icon ( Image 27 ) to enter into Current interface. Please set charge current by sliding ( Image 28 ). Touch OK to go back to main interface and continue setting. Image 27 Image 28 【NOTE】Please set charge current in charge mode and discharge current in dis- charge mode.
  • Page 28 Step 5: touch Start icon ( Image 29 ) to enter into Start interface. The charger will check battery status automatically. If everything is OK, the charger will begin to charge ( Image 30 ). Image 29 Image 30 Chapter 1 Preparing、Connecting、Using...
  • Page 29 【NOTE】The charger will pop-up window when the battery is fully charged. Touch OK to finish charging process ( Image 30 ). Image 30 【NOTE】The charger will send out an alert and pop-up window if the battery packs’ setting is not correct. ( Image 31 ) All Lipo battery packs setting are the same operation. Image 31 Chapter 1 Preparing、Connecting、Using...
  • Page 30 Example 3: If you want to charge a pack of Pb battery, please execute the opera- tion as follows, Step 1: touch Type icon ( Image 32 ) to enter into Type interface. Touch Pb icon ( Image 33) to go back to main interface and continue setting. Present Setting Type...
  • Page 31 Step 2: Touch Mode icon ( Image 34 ) to enter into Mode interface. Touch Charge icon ( Image 35 ) to go back to main interface and continue setting. Image 34 Image 35 【NOTE】 There are some options in Mode interface ( Image 35 ). Please set accord- ing to your requirement.
  • Page 32 Step 3: touch Cells icon ( Image 36 ) to enter into Cells interface. Please set Pb battery packs by sliding ( Image 37 ). Touch OK to go back to main interface and continue setting. Image 36 Image 37 【NOTE】Please set according to suitable battery packs.
  • Page 33 Step 4: touch Current icon ( Image 38 ) to enter into Current interface. Please set charge current by sliding ( Image 39 ). Touch OK to go back to main interface and continue setting. Image 38 Image 39 【NOTE】Set charge current in charge mode and discharge current in discharge mode. As for Save and Load functions, please see Step 5 and 6 in Example1 for further details.
  • Page 34 Step 5: touch Start icon ( Image 40 ) to enter into Start interface. The charger will check battery status automatically. If everything is OK, the charger will begin to charge. ( Image 41 ) Image 40 Image 41 Chapter 1 Preparing、Connecting、Using...
  • Page 35 【NOTE】The charger will pop-up window when the battery is fully charged. Touch OK to finish charging process ( Image 42 ). Image 42 【NOTE】The charger will send out an alert and pop-up window if the battery packs’ setting is incorrect. ( Image 43 ) All Lipo battery packs setting are the same operation. Image 43 Chapter 1 Preparing、Connecting、Using...
  • Page 36 X200 Experiments...
  • Page 37 OS SYSTEM is bran-new software of charger which was Independently research and develop by HobbyKing. It is the first operation system in the world especially to support touch screen charger,and it’s going to be Industry standard for touch screen charger series.
  • Page 38 Cut off Cut off tempe- Capacity Time Input raturey Lixx Nixx Wasle Cycle Check Delta Time Times Time Peak Backlight Buzzer Language Level Back Image 47 Please find detailed list of features on next page. Chapter 2 Enjoy function of X200...
  • Page 39 Rang of setting: 5-60mins. Time for checking cells count of LiPo battery pack. NixxDeltaPeak Nixx Delta Peak Rang of setting: 5-200mV. NiHm/NiCd Delta peak. Waste Time Wasle Time Spacing interval between 2 Cycles. Rang of setting: 1-60mins. Chapter 2 Enjoy function of X200...

  • Page 40: Cycle Time

    2. when charging power reach 100W, fan speed will be one level up as charging power rise by each 5W. 3. Fan speed will be one level up as discharging power rise by each 2W. NOTE: Fan Speed of X200 charger will begin to change in any of above situation. Chapter 2 Enjoy function of X200...
  • Page 41 IMPORTANT REMIND...

  • Page 42: Safety Precautions And Warnings

    Please follow the instruction to operate your X200 charger, to insure safety of you and charger, and use it easily. Please keep manual within easy reach, to be easy reference for you and other user. 【NOTE】 Procedures, which if not properly followed, can result in potential nullification of any vendor warranties or liabilities.
  • Page 43 X200 charger from air-vent. This may lead inner surface of screen appear mist. Do not Maintain Yourself X200 charger not include any spare part for user to make the maintenance , never dismantle the product by yourselves. Please contact with HobbyKing authorized distrib- utor for maintenance.
  • Page 44 All specifications and figures are subject to change without notice. Printed in China © 2012...
