  • Page 1 Size:120X170mm User Manual Of Digital Set Top Box OPTICUM 7002T Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.

  • Page 2: Safety Instructions

    Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Safety is Important To ensure your safety and the safety of others, please ensure you read the Safety Instructions before you operate this product. Keep this information in a safe place for future reference. Please read all the safety information before using the product.
  • Page 3 1. The apparatus shall not be exposed to dripping or Splashing and that no objects filled with liquids, such as Vases, shall be placed the apparatus. 2. The mains plug is used as the disconnect device, the disconnect device shall remain readily operable. 3.

  • Page 4: Table Of Contents

    Table of Contents Introduction ................1 Front and Rear Panel............. 2 Remote Controller ..............3 Connections................5 First Time Installation............. 7 Basic Operations ..............9 Using the On-Screen Setup Menu...........13 Troubleshooting ..............25 Specifications..............26...

  • Page 5: Introduction

    Introduction This Digital Set Top Box is a Free-To-Air digital terrestrial receiver, allowing you to access free-to-air digital terrestrial TV channels and radio broadcasts on your TV set. Its digital reception covers VHF & UHF band. Compared with the analog TV programs, digital TV programs eliminate the noise and interference but offer high quality video and audio.

  • Page 6: Front And Rear Panel

    CHANNEL UP/DOWN: Used to change channels without using the remote control. STANDBY BUTTON: Used to switch the set top box on and off. Serial No.: MODEL: OPTICUM 7002T CAUTION DIGITAL TERRESTRIAL RECEIVER 100-240V~ POWER SUPPLY: 100-240V~ 50/60Hz...

  • Page 7: Remote Controller

    19. NUMBER KEYS Used to select channel numbers or input numbers in menus. 20. AUDIO Used to set the sound output, the available settings are STEREO, LEFT , RIGHT, MONO. OPTICUM 7002T 21. TV/RADIO Used to switch between TV channels and Radio stations. 22. COLOR KEYS(RED/GREEN/YELLOW/BLUE): Used to operate different functions in TEXT screen or other menus.
  • Page 8 STANDBY DTV/VCR MUTE INFO PAUSE MENU EXIT FAVORITE GAME RECALL TV/RADIO AUDIO SUBTITLE TEXT OPTICUM 7002T The remote control will not operate if its path is blocked. Sunlight or very bright light will decrease the sensitivity of the remote control.

  • Page 9: Connections

    Connections Caution: Make sure to check the voltage specification of the wall outlet is the same rating with the receiver. To prevent the risk of electric shock, do not open the cover or the back of the receiver. Connecting to a TV Set 100-240V~ 50/60Hz Digital...
  • Page 10 Connecting to TV and VCR 100-240V~ Digital Digital 50/60Hz Audio Audio R R F F LOOP LOOP Coaxial Coaxial R R F F SERVICE VCR O O VCR O O THROUGH THROUGH Note: When connecting the receiver to other equipment, e.g., TV, VCR and amplifier, make sure to refer to relevant user manual for instruction.

  • Page 11: First Time Installation

    First Time Installation After all the connections have been made properly, switch on your TV. Make sure the receiver is connected to the mains and press Power to switch the receiver on. If you are using the receiver for the first time, a First Time Installation menu will be displayed to guide you through the initial setup.
  • Page 12 3. Select Yes to start the automatic channel search. 4. Wait to complete the scanning. In case you want to stop the scanning, press the EXIT key. The channels already found will still be stored. 5. When finished, all active channels found will be stored automatically.

  • Page 13: Basic Operations

    Basic Operations Once program search is completed, you can start to watch digital terrestrial TV channels and radio broadcasts. Some typical operations are given in this chapter. Switching On and Off Whenever you are not using the receiver, press the Standby key on remote control or button on the receiver to put it into standby mode.
  • Page 14 Watching Favorite List You can press FAVORITE to watch your preset favorite channels. To create your favorite list, go to Main Menu > Program List. Refer to Creating Favorite Channel Groups on page 13 for detailed information. Displaying information To display the detailed information of the current channel, press the INFO key.
  • Page 15 Displaying EPG To view the EPG (electronic program guide) provided by the content provider: 1. Press the EPG key and then use the Up / Down key highlight a desired channel to preview the EPG. To view today's complete EPG, press the Right key. 2.
  • Page 16 4. To exit the detailed EPG screen, press the Left key. Displaying Text Press the TEXT key to open a teletext page (if teletext is transmitted). Press TEXT key again to close it. Selecting Sound Mode To switch the sound mode between LL (left), RR (right) and LR (stereo), press the Audio key.

  • Page 17: Using The On-Screen Setup Menu

    Using the On-Screen Setup Menu The receiver features an on-screen menu providing access to a variety of setup and management controls. Use the remote controller to navigate through the menu and activate required settings. Managing Program List Main Menu > Program List > TV / Radio Program List All active channels are listed in the Program List, allowing you to make your own favorite channel group, move, delete or sort channels.
  • Page 18 Moving a Channel 1. Select the channel which you like to move and go to the Move column. 2. Press OK and symbol will be displayed. 3. Use the Up / Down key to move the channel to a desired position. Deleting a Channel 1.
  • Page 19 Sorting Channels 1. Go to Main Menu > Program List > Sort. 2. You can sort the channels by the channel name, service ID or channel number. Select one method as required. Sort 3. Press MENU or EXIT to return the program list. The list is now sorted by the specified order.
  • Page 20 4. Wait to complete the scanning. In case you want to stop the scanning, press the EXIT key. The channels already found will still be stored. 5. When finished, the last found channel will be played. Manual Search If any channel is missing after auto search, or you want to add newly launched channels, you can use Manual Search to scan the desired channels.
  • Page 21 Parental Control This feature allows you to prevent children or unauthorized people from watching channels. 1. Go to Main Menu > Parental Control. First, you will need to enter PIN as prompted to use the parental control menu. (The default PIN is 6666.) 2.
  • Page 22 Change PIN: Allows you to change the PIN. A PIN can be composed of 1 to 4 digits. To change the PIN, enter the old, new PIN in the provided fields. After pressing OK, a message indicating PIN Code Changed will appear. Note: To activate the parental control feature, Channel Lock must be set to YES.
  • Page 23 System Settings TV Standard This option allows you to select your TV system among PAL, NTSC and Auto. Display Type This option allows you to select the aspect ratio of the video output. If you are using normal 4:3 TV, it is OK to view the regular 4:3 content being broadcasted.
  • Page 24 Video Output Set the video mode as CVBS or RGB. Antenna Power The default setting is OFF. Set this option to ON if this receiver box is connected to an external active antenna that amplifies the received signal. This receiver box can supply 5V DC at 50mA maximum.
  • Page 25 Language OSD Language: Select the on-screen-display language as required. 1 st /2nd Audio Language: This option allows you to select your first and second choice for the audio language. If neither of your selected language is available on the program transmitted, the main language of the program will be used.
  • Page 26 System Schedule This feature allows the receiver to automatically switch on and tune to a pre-specified channel for a pre-set length of time. You can use this feature to schedule recording if your receiver is connected to a VCR or recorder or as reminders of certain programs. Up to 10 tasks can be scheduled.
  • Page 27 SW: v1.08 HW: 212U.IO.LG352(N).9013 Date: DD/MM/YY Factory Default This option allows you to resume factory defaults. 1. To reset defaults, select OK. 2. All programs you have searched will be erased and all parameters, e.g., the regional settings, languages and favorite lists, will return to the factory default.
  • Page 28 Personal Style This option allows you to customize the menu settings. You can set the Menu Color, Transparency level, Border Pattern and Entry Animation as preferred.

  • Page 29: Troubleshooting

    Troubleshooting If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section.

  • Page 30: Specifications

    Specifications...
