Active Vision ACC-V110N User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Network Camera

User Manual
V5.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACC-V110N and is the answer not in the manual?

Questions and answers

Summary of Contents for Active Vision ACC-V110N

  • Page 1: Network Camera

    Network Camera User Manual V5.0...
  • Page 2 User Manual of Network Camera Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to Network Camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 3: Regulatory Information

    User Manual of Network Camera Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Warnings And Cautions

    User Manual of Network Camera Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by employees from our company with knowledge and training in working with these types of devices that contain live circuits.
  • Page 5 User Manual of Network Camera Power Cord Requirements: The connector that plugs into the wall outlet must be a grounding-type male plug designed for use in your region. It must have certification marks showing certification by an agency in your region. The connector that plugs into the AC receptacle on the power supply must be an IEC 320, sheet C13, female connector.
  • Page 6 User Manual of Network Camera determined by turning the equipment on and off, the user is required to take measures to eliminate the interference or discontinue the use of this equipment. Lead Content: Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling;...

  • Page 7: Safety Instruction

    User Manual of Network Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
  • Page 8 User Manual of Network Camera Cautions:  Make sure the power supply voltage is correct before using the camera.  Do not drop the camera or subject it to physical shock.  Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.

  • Page 9: Table Of Contents

    User Manual of Network Camera Contents CHAPTER 1 SYSTEM REQUIREMENT.................... 11 CHAPTER 2 NETWORK CONNECTION ..................12 LAN................12 ETTING THE ETWORK AMERA OVER THE 2.1.1 Wiring over the LAN ......................12 2.1.2 Detecting and Changing the IP Address ................13 WAN ................14 ETTING THE ETWORK AMERA OVER THE...
  • Page 10 User Manual of Network Camera 6.4.1 Configuring Video Settings ....................46 6.4.2 Configuring Audio Settings ....................48 6.4.3 Configuring ROI Encoding ....................48 ....................49 ONFIGURING MAGE ARAMETERS 6.5.1 Configuring Display Settings ....................49 6.5.2 Configuring OSD Settings ....................51 6.5.3 Configuring Text Overlay Settings ..................53 6.5.4 Configuring Privacy Mask ....................53 6.5.5...

  • Page 11: Chapter 1 System Requirement

    User Manual of Network Camera Chapter 1 System Requirement Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above...

  • Page 12: Chapter 2 Network Connection

    User Manual of Network Camera Chapter 2 Network Connection Before you start:  If you want to set the network camera via a LAN (Local Area Network), please refer to Section 2.1 Setting the Network Camera over the LAN.  If you want to set the network camera via a WAN (Wide Area Network), please refer to Section 2.2 Setting the Network Camera over the WAN.

  • Page 13: Detecting And Changing The Ip Address

    User Manual of Network Camera 2.1.2 Detecting and Changing the IP Address You need the IP address to visit the network camera. Steps: 1. To get the IP address, you can choose either of the following methods:  Use SADP, a software tool which can automatically detect the online network cameras in the LAN and list the device information including IP address, subnet mask, port number, device serial number, device version, etc., shown in Figure 2-3.

  • Page 14: Setting The Network Camera Over The Wan

    User Manual of Network Camera 2.2 Setting the Network Camera over the WAN Purpose: This section explains how to connect the network camera to the WAN with a static IP or a dynamic IP. 2.2.1 Static IP Connection Before you start: Please apply a static IP from an ISP (Internet Service Provider).

  • Page 15: Dynamic Ip Connection

    User Manual of Network Camera 2.2.2 Dynamic IP Connection Before you start: Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network camera to a modem or a router.  Connecting the network camera via a router Steps: 1.
  • Page 16 User Manual of Network Camera Normal Domain Name Resolution Figure 2-7 Steps: 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 5.3.4 Configuring DDNS Settings for detailed configuration.

  • Page 17: Chapter 3 Access To The Network Camera

    User Manual of Network Camera Chapter 3 Access to the Network Camera 3.1 Accessing by Web Browsers Steps: 1. Open the web browser. 2. In the address field, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3.
  • Page 18 User Manual of Network Camera Download and Install Plug-in Figure 3-2 Install Plug-in (1) Figure 3-3 Install Plug-in (2) Figure 3-4...

  • Page 19: Accessing By Client Software

    User Manual of Network Camera Install Plug-in (3) Figure 3-5 Note: You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in. 3.2 Accessing by Client Software 3.2.1 Accessing by NVMS7000 Software The product CD contains the NVMS7000 client software (Client or PCNVR).
  • Page 20 User Manual of Network Camera NVMS7000 Live View Figure 3-6 NVMS7000 Configuration Panel Figure 3-7 Note: For detailed information about NVMS7000 client software, please refer to the user manual of the NVMS7000 software.

  • Page 21: Chapter 4 Wi-Fi Settings

    User Manual of Network Camera Chapter 4 Wi-Fi Settings Purpose: By connecting to the wireless network, you don’t need to use cable of any kind for network connection, which is very convenient for the actual surveillance application. Note: This chapter is only applicable for the cameras with the Wi-Fi module built-in. 4.1 Configuring Wi-Fi Connection in Manage and Ad-hoc Modes Before you start: A wireless network must be configured.
  • Page 22 User Manual of Network Camera 4. Check the checkbox to select the Network mode as Manage, and the Security mode and the Encryption Type of the network is automatically shown when you select the wireless network, please don’t change it manually. Note: These parameters are exactly identical with those of the router.
  • Page 23 User Manual of Network Camera Ad-hoc Connection Point Figure 4-6 Choose the SSID and connect. Security Mode Description: You can choose the Security Mode as not –encrypted, WEP, WPA-personal, WPA-enterprise, WPA2-personal, WPA2-enterprise. WEP mode:  Authentication - Select Open or Shared Key System Authentication, depending on the method used by your access point.
  • Page 24 User Manual of Network Camera Authentication.  Key length - This sets the length of the key used for the wireless encryption, 64 or 128 bit. The encryption key length can sometimes be shown as 40/64 and 104/128.  Key type - The key types available depend on the access point being used. The following options are available: HEX - Allows you to manually enter the hex key.

  • Page 25: Easy Wi-Fi Connection With Wps Function

    User Manual of Network Camera  User Name - Enter the user name to present to the network  Password - Enter the password of the network  PEAP Version - Select the PEAP version used at the access point. ...
  • Page 26 User Manual of Network Camera Check the checkbox of to enable WPS. Choose the connection mode as PBC. Note: Support of this mode is mandatory for both the Access Points and the connecting devices. Check on the Wi-Fi router to see if there is a WPS button. If yes push the button and you can see the indicator near the button start flashing, which means the WPS function of the router is enabled.
  • Page 27 User Manual of Network Camera Wi-Fi Settings – WPS PIN Mode Figure 4-8 Choose the If the PIN code is generated from the router side, you should enter the PIN code you get from the router side in the field. Click button.

  • Page 28: Ip Property Settings For Wireless Network Connection

    User Manual of Network Camera 4.3 IP Property Settings for Wireless Network Connection The default IP address of wireless network interface controller is 192.168.1.64. When you connect the wireless network you can change the default IP. Steps: Enter the TCP/IP configuration interface. Configuration>...

  • Page 29: Chapter 5 Live View

    User Manual of Network Camera Chapter 5 Live View 5.1 Live View Page Purpose: The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click on the menu bar of the main page to enter the live view page.

  • Page 30: Starting Live View

    User Manual of Network Camera pan/tilt unit has been installed). Live View Parameters: Configure the image size and stream type of the live video. 5.2 Starting Live View In the live view window as shown in Figure 5-2, click on the toolbar to start the live view of the camera.

  • Page 31: Operating Ptz Control

    User Manual of Network Camera click to record the live video. The saving paths of the captured pictures and clips can be set on the Configuration > Local Configuration page. To configure remote scheduled recording, please refer to Section 6.2. Note: The captured image will be saved as a JPEG file in your computer.

  • Page 32: Setting / Calling A Preset

    User Manual of Network Camera Focus near/far Iris open/close Light on/off Wiper on/off One-touch focus Initialize lens Adjust speed of pan/tilt movements 5.4.2 Setting / Calling a Preset  Setting a Preset: 1. In the PTZ control panel, select a preset number from the preset list. Setting a Preset Figure 5-3 2.

  • Page 33: Configuring Live View Parameters

    User Manual of Network Camera Calling a Preset Figure 5-4 5.5 Configuring Live View Parameters Purpose: You can select the stream type and adjust the image size on the live view page.  Click tab under the menu bar of the live view interface to select the stream type as main stream or sub-stream for live viewing.

  • Page 34: Chapter 6 Network Camera Configuration

    User Manual of Network Camera Chapter 6 Network Camera Configuration 6.1 Configuring Local Parameters Note: The local configuration refers to the parameters of the live view, record files and captured pictures. The record files and captured pictures are the ones you record and captured using the web browser and thus the saving paths of them are on the PC running the browser.

  • Page 35: Configuring Time Settings

    User Manual of Network Camera Multicast function. For detailed information about Multicast, refer to Section 6.3.1 TCP/IP Settings.  Live View Performance: Set the live view performance to Least Delay, Balanced or Best Fluency.  Record File Settings: Set the saving path of the recorded video files. Valid for the record files you recorded with the web browser.
  • Page 36 User Manual of Network Camera Time Settings Figure 6-2  Select the Time Zone. Select the Time Zone which is the closest to the location of the camera from the drop-down menu.  Synchronizing Time by NTP Server. (1) Check the checkbox to enable the NTP function. (2) Configure the following settings: Server Address: IP address of NTP server.

  • Page 37: Configuring Network Settings

    User Manual of Network Camera Time Sync Manually Figure 6-4  Click the tab page to enable the DST function and Set the date of the DST period. DST Settings Figure 6-5 2. Click to save the settings. 6.3 Configuring Network Settings 6.3.1 Configuring TCP/IP Settings Purpose: TCP/IP settings must be properly configured before you operate the camera over...

  • Page 38: Configuring Port Settings

    User Manual of Network Camera TCP/IP Settings Figure 6-6 2. Configure the basic network settings, including the NIC Type, IPv4 or IPv6 Address, IPv4 or IPv6 Subnet Mask, IPv4 or IPv6 Default Gateway, MTU settings and Multicast Address. Notes:  The valid value range of MTU is 500 ~ 1500. ...

  • Page 39: Configuring Pppoe Settings

    User Manual of Network Camera Port Settings Figure 6-7 2. Set the HTTP port, RTSP port and HTTPS port of the camera. HTTP Port: The default port number is 80, and can be changed to any port range 1024 to 65535. RTSP Port: The default port number is 554.

  • Page 40: Configuring Ddns Settings

    User Manual of Network Camera 6.3.4 Configuring DDNS Settings Purpose: If your camera is set to use PPPoE as its default network connection, you can use the Dynamic DNS (DDNS) for network access. Before you start: Registration on the DDNS server is required before configuring the DDNS settings of the camera.
  • Page 41 User Manual of Network Camera DynDNS Settings Figure 6-10 IP Server:  Steps: (1) Enter the Server Address of the IP Server. (2) Click to save the settings. Note: For the IP Server, you have to apply a static IP, subnet mask, gateway and preferred DNS from the ISP.

  • Page 42: Configuring Snmp Settings

    User Manual of Network Camera device alias in the HiDDNS server. (4) Click to save the new settings. Note: It will ask for a reboot for the settings to take effect. 6.3.5 Configuring SNMP Settings Purpose: You can set the SNMP function to get camera status, parameters and alarm related information and manage the camera remotely when it is connected to the network.

  • Page 43: Configuring 802.1X Settings

    User Manual of Network Camera 2. Check the corresponding version checkbox ( ) to enable the feature. 3. Configure the SNMP settings. Note: The settings of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings.

  • Page 44: Configuring Qos Settings

    User Manual of Network Camera 6.3.7 Configuring QoS Settings Purpose: QoS (Quality of Service) can help solve the network delay and network congestion by configuring the priority of data sending. Steps: Enter the QoS Settings interface: Configuration >Advanced Configuration > Network > QoS QoS Settings Figure 6-14 2.

  • Page 45: Configuring Upnp™ Settings

    User Manual of Network Camera FTP Settings Figure 6-15 2. Configure the FTP settings; and the user name and password are required for login the FTP server. Directory: In the Directory Structure field, you can select the root directory, parent directory and child directory. When the parent directory is selected, you have the option to use the Device Name, Device Number or Device IP for the name of the directory;...

  • Page 46: Configuring Video And Audio Settings

    User Manual of Network Camera Configure UPnP Settings Figure 6-16 To port mapping with the default port numbers: Choose To port mapping with the customized port numbers: Choose And you can customize the value of the port number by yourself. 3.
  • Page 47 User Manual of Network Camera Configure Video Settings Figure 6-17 2. Select the Stream Type of the camera to main stream (normal), sub-stream or third stream. The main stream is usually for recording and live viewing with good bandwidth, and the sub-stream and third stream can be used for live viewing when the bandwidth is limited.

  • Page 48: Configuring Audio Settings

    User Manual of Network Camera Profile: Basic profile, Main Profile and High Profile for coding are selectable. I Frame Interval: Set the I-Frame interval to 1~400. SVC: Scalable video coding is an extension of the H.264/AVC standard. The technology encodes the video signal with layers; the basic layer and several enhanced layers and it is adaptive to the network condition to transfer different video streams.

  • Page 49: Configuring Image Parameters

    User Manual of Network Camera quality of the ROI whereas the background information is less focused. Steps: 1. Enter the ROI settings interface Configuration > Advanced Configuration > Video / Audio >ROI 2. Draw the region of interest on the image. There are four regions can be drawn. 3.
  • Page 50 User Manual of Network Camera Display Settings Figure 6-19 Descriptions of parameter configuration Overexposure Prevention: Enable or disable the function in this field. Exposure Time: Value ranges from 1/25 to 1/100,000s. Adjust it according to the lightening condition. Iris Mode: Auto and Manual are selectable.

  • Page 51: Configuring Osd Settings

    User Manual of Network Camera Wide dynamic range can be used when there is a high contrast of the bright area and the dark area of the scene. BLC Area: BLC area is the area sense the light intensity; Close, Up, Down, Left, Right and Center are selectable.
  • Page 52 User Manual of Network Camera OSD Settings Figure 6-20 2. Check the corresponding checkbox to select the display of camera name, date or week if required. 3. Edit the camera name in the text field of Camera Name. 4. Select from the drop-down list to set the time format, date format, display mode and the OSD font size.

  • Page 53: Configuring Text Overlay Settings

    User Manual of Network Camera 6.5.3 Configuring Text Overlay Settings Purpose: You can customize the text overlay. Steps: 1. Enter the Text Overlay Settings interface: Configuration > Advanced Configuration > Image > Text Overlay 2. Check the checkbox in front of textbox to enable the on-screen display. 3.

  • Page 54: Configuring Picture Overlay

    User Manual of Network Camera 3. Click Privacy Mask Settings Figure 6-23 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to 4 areas on the same image. 5.

  • Page 55: Configuring And Handling Alarms

    User Manual of Network Camera 2. Click button to add a picture from your PC. 3. Click button to upload it. 4. Check the checkbox to enable the function. X Coordinate and Y Coordinate values are for the location of the picture on the image. And the Picture width and Height are for adjusting the size of the picture.
  • Page 56 User Manual of Network Camera (2)Check the checkbox of Enable Motion Detection. Enable Motion Detection Figure 6-24 (3)Click . Click and drag the mouse on the live video image to draw a motion detection area. Note: You can draw up to 8 motion detection areas on the same image. (4)Click to finish drawing.
  • Page 57 User Manual of Network Camera Arming Time Figure 6-25 (1)Click to edit the arming schedule. The Figure 5-28 shows the editing interface of the arming schedule. (2)Choose the day you want to set the arming schedule. (3)Click to set the time period for the arming schedule. (4)After you set the arming schedule, you can copy the schedule to other days (Optional).

  • Page 58: Configuring Tamper-Proof Alarm

    User Manual of Network Camera You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. Linkage Method Figure 6-27 Steps: (1) Check the checkbox to select the linkage method. Audible warning, notify surveillance center, send email, upload to FTP, trigger channel and trigger alarm output are selectable (Optional).
  • Page 59 User Manual of Network Camera You can configure the camera to trigger the alarm when the lens is covered and take alarm response action. Steps: 1. Enter the Tamper-proof Settings interface: Configuration > Advanced Configuration > Events > Tamper-proof Tamper-proof Alarm Figure 6-28 2.

  • Page 60: Configuring External Alarm Input

    User Manual of Network Camera 6.6.3 Configuring External Alarm Input Steps: 1. Enter the Alarm Input Settings interface: Configuration > Advanced Configuration> Events > Alarm Input: 2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed).

  • Page 61: Configuring Alarm Output

    User Manual of Network Camera Linkage Method Figure 6-30 6.6.4 Configuring Alarm Output Steps: 1. Enter the Alarm Output Settings interface: Configuration>Advanced Configuration> Events > Alarm Output 2. Select one alarm output channel in the Alarm Output drop-down list. You can also set a name for the alarm output (optional).

  • Page 62: Handling Exception

    User Manual of Network Camera Alarm Output Settings Figure 6-31 6.6.5 Handling Exception The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the cameras. Steps: 1. Enter the Exception Settings interface: Configuration >...

  • Page 63: Email Sending Triggered By Alarm

    User Manual of Network Camera 6.6.6 Email Sending Triggered by Alarm Purpose: The system can be configured to send an Email notification to all designated receivers if an alarm event is detected, e.g., motion detection event, video loss, tamper-proof, etc. Before you start: Please configure the DNS Server settings under Basic Configuration >...

  • Page 64: Configuring Snapshot Settings

    User Manual of Network Camera And the SSL SMTP port is 465. Enable SSL: Check the checkbox to enable SSL if it is required by the SMTP server. Attached Image: Check the checkbox of Attached Image if you want to send emails with attached alarm images.

  • Page 65: Face Detection

    User Manual of Network Camera details to configure FTP parameters. 2) Check the Enable Timing Snapshot checkbox.  Upload event-triggered snapshots to FTP Steps: 1) Configure the FTP settings and check checkbox in FTP Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters.

  • Page 66: Configuring Other Alarms

    User Manual of Network Camera Steps: 1. Enter the face detection settings interface: Configuration > Advanced Configuration > Events > Face Detection 2. Check the Enable Face Detection to checkbox to enable the function. 3. (Optional)You can check the Enable Dynamic Analysis for Face Detection checkbox if you want the face detected get marked with rectangle in the live view.
  • Page 67 User Manual of Network Camera Remote Control Settings Figure 6-35 2. Study the code of the remote control or the wireless alarm. To study a remote control, select Remote Control from the Study drop-down list, and click ; and then press any of the buttons on the remote control against the camera to send the signal.
  • Page 68 User Manual of Network Camera Remote Control: Remote Control Figure 6-36 Remote Control Description: Indicating the status of the remote; when Status Indicator you press the button on the remote, the indicator flicks in red. Press the button to arm the camera. In arming status, the alarm function, such as the wireless alarm and the PIR alarm, is enabled.
  • Page 69 User Manual of Network Camera  To study the wireless alarms, e.g. the access control device, select Wireless Alarm from the Study drop-down list, and select the device serial number (1-8) from the drop-down list, and click ; and then send the signal from the wireless alarm device to the camera.
  • Page 70 User Manual of Network Camera Note: Not all cameras support wireless audible and visual alarm as the wireless alarm output for the wireless alarm. Check the check box of Wireless audible and visual alarm to activate the alarm output. Wireless Alarm Output Figure 6-39 (5) Click to save the settings.

  • Page 71: Arming Or Disarming The Camera

    User Manual of Network Camera Manual Alarm/Emergency Alarm Certain series of camera support manual alarm by the remote control. It can be manually triggered and linked to the audio warning if any emergency happens. You can press and hold the manual alarm button on the remote control for 2 seconds to trigger the audio warning manually.
  • Page 72 User Manual of Network Camera  You can also press the Arm/Disarm button on the remote control to arm/disarm the camera if the camera has already studied the remote control.  The arming indicator glows red when the camera is armed and glows blue when it’s disarmed.

  • Page 73: Chapter 7 Storage Settings

    User Manual of Network Camera Chapter 7 Storage Settings Before you start: To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your camera. 7.1 Configuring NAS Settings Before you start: The network disk should be available within the network and properly configured to store the recorded files, log files, etc.

  • Page 74: Configuring Recording Schedule

    User Manual of Network Camera Initializing Figure 7-3 When the initialization completed, the status of disk will become Normal. View Disk Status Figure 7-4 Notes:  Up to 8 NAS disks can be connected to the camera.  To initialize and use the SD card after insert it to the camera, please refer to the steps of NAS disk initialization.
  • Page 75 User Manual of Network Camera Recording Schedule Interface Figure 7-5 2. Check the checkbox of Enable Record Schedule to enable scheduled recording. 3. Set the record parameters of the camera. Record Parameters Figure 7-6  Pre-record: The time you set to start recording before the scheduled time or the event.
  • Page 76 User Manual of Network Camera Record Schedule Figure 7-7 5. Choose the day to set the record schedule. (1) Set all-day record or segment record:  If you want to configure the all-day recording, please check the All Day checkbox. ...
  • Page 77 User Manual of Network Camera Section 5.6.4.  Record Triggered by Motion & Alarm If you select Motion & Alarm, the video will be recorded when the motion and alarm are triggered at the same time. Besides configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input Settings interfaces.
  • Page 78 User Manual of Network Camera Edit Record Schedule Figure 7-8 (3) Check the checkbox and click to copy settings of this day to the whole week. You can also check any of the checkboxes before the date and click (4) Click to save the settings and exit the Edit Record Schedule interface.

  • Page 79: Chapter 8 Playback

    User Manual of Network Camera Chapter 8 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or SD cards. Steps: 1. Click on the menu bar to enter playback interface. Playback Interface Figure 8-1 2.
  • Page 80 User Manual of Network Camera process. Playback Toolbar Figure 8-3 Description of the buttons Table 8-1 Button Operation Button Operation Play Capture a picture Start/Stop clipping video Pause files Audio on and adjust Stop volume/Mute Speed down Download video files Download captured Speed up pictures...

  • Page 81: Chapter 9 Log Searching

    User Manual of Network Camera Chapter 9 Log Searching Purpose: The operation, alarm, exception and information of the camera can be stored in log files. You can also export the log files on your demand. Before you start: Please configure network storage for the camera or insert a SD card in the camera. Steps: 1.

  • Page 82: Chapter 10 Others

    User Manual of Network Camera Chapter 10 Others 10.1 Managing User Accounts Enter the User Management interface: Configuration >Basic Configuration> Security > User Or Configuration > Advanced Configuration> Security > User The admin user has access to create, modify or delete other accounts. Up to 15 user accounts can be created.
  • Page 83 User Manual of Network Camera Add a User Figure 10-2  Modify a User Steps: 1. Left-click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions.

  • Page 84: Configuring Rtsp Authentication

    User Manual of Network Camera  Delete a User Steps: 1. Left-click the user name you want to delete and click 2. Click on the pop-up dialogue box to delete the user. Delete a User Figure 10-4  Anonymous Visit 10.2 Configuring RTSP Authentication Purpose: You can specifically secure the stream data of live view.

  • Page 85: Ip Address Filter

    User Manual of Network Camera Enabling this function allows visit for whom doesn’t have the user name and password of the device. Steps: 1. Enter the Anonymous Visit interface: Configuration> Advanced Configuration> Security > Anonymous Visit Anonymous Visit Figure 10-6 2.
  • Page 86 User Manual of Network Camera IP Address Filter Interface Figure 10-8 2. Check the checkbox of Enable IP Address Filter. 3. Select the type of IP Address Filter in the drop-down list, Forbidden and Allowed are selectable. 4. Set the IP Address Filter list. ...

  • Page 87: Viewing Device Information

    User Manual of Network Camera Modify an IP Figure 10-10 (3) Click the button to finish modifying.  Delete an IP Address Left-click an IP address from filter list and click button.  Delete all IP Addresses Click button to delete all the IP addrsses. 5.

  • Page 88: Maintenance

    User Manual of Network Camera 10.6 Maintenance 10.6.1 Rebooting the Camera Steps: 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance: 2. Click to reboot the network camera. Reboot the Device Figure 10-12 10.6.2 Restoring Default Settings Steps:...

  • Page 89: Upgrading The System

    User Manual of Network Camera start importing configuration file. Note: You need to reboot the camera after importing configuration file. 2. Click and set the saving path to save the configuration file in local storage. Import/Export Configuration File Figure 10-14 10.6.4 Upgrading the System Steps: 1.

  • Page 90: Rs-485 Settings

    User Manual of Network Camera 1. Enter RS-232 Port Setting interface: Configuration> Advanced Configuration> System > RS232 RS-232 Settings Figure 10-16 Note: If you want to connect the camera by the RS-232 port, the parameters of the RS-232 should be exactly the same with the parameters you configured here. 2.

  • Page 91: Appendix

    User Manual of Network Camera Appendix Appendix 1 SADP Software Introduction  Description of SADP V 2.0 SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices.
  • Page 92 User Manual of Network Camera Note: You can click on each column heading to order the information; you can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.

  • Page 93: Appendix 2 Port Mapping

    Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-R410). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2. Set the LAN parameters of the router as in the following figure, including IP address and subnet mask settings.
  • Page 94 User Manual of Network Camera ports of another camera as 81, 8001, 555, 8201 with IP 192.168.1.24. Refer to the steps as below: Note: The 8200 port changes with the 8000 port with a constant value of 200. E.g. if the 8000 port is changed to 8005, then the 8200 port should be changed to 8205.
