EMI
U S E R M A N U A L
Before operating, please read this manual completely
:
FEATURES
5 MIC inputs, 2 AUX inputs, 1 Record input, 1 Record output
Priority muting for chime and siren
Three levels of priority muting: MIC1
5 LED level meter
Individual volume control for each input, master bass and treble control
Speaker outputs 100V, 70V and 4
Power supply AC 220V-240V or DC 24V
Thermal, over load, short circuit protection and siren
Professional Public Address System
Pro
fessional Public Address System
Pro
Pro
fessional Public Address System
fessional Public Address System
＞ ＞ ＞ ＞
s iren
＞ ＞ ＞ ＞
c hime
1
EMMA-45
EMMA-60
EMMA-120
Mixing Amplifier
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EMIX EMMA-45
Summary of Contents for EMIX EMMA-45
- Page 1 Professional Public Address System fessional Public Address System fessional Public Address System fessional Public Address System EMMA-45 EMMA-60 EMMA-120 Mixing Amplifier U S E R M A N U A L Before operating, please read this manual completely FEATURES 5 MIC inputs, 2 AUX inputs, 1 Record input, 1 Record output...
- Page 2 Left blank for memo...
- Page 3 FRONT PANEL ． L ed Power Indicator 7. Treble Control 2. Power Switch 8. Mic1, 2, 3 Volume Control 3. Led Level Meter 9. Mic4 / Aux1 Volume Control 4. Chime 10. Mic5 / Aux2 Volume Control 5. Siren 11. 6.3mm Jack Type Mic1 Input 6.
- Page 4 CONNECTION MIC2 MIC3 IMPEDANCE SPEAKER 4 ohm, 8 ohm, 16 ohm 100V, 70V, LINE SPEAKER 一 一 一 一 C D P L A Y E R DISC OPEN T A P E R E C O R D E R 00:35 MIC5 MIC4...
- Page 5 Tone and volume: “BASS” and “TREBLE” knob provides the tone control of overall system. MIC1, 2, 3, 4, 5 have separate volume control. MIC4 and AUX1 or MIC5 and AUX2 have a common volume control knob. : MIC inputs are balanced with phantom power. Two types of MIC inputs available: 6.3mm (MIC1, 4, 5) and XLR (MIC2, 3).
- Page 6 Model EMMA-45 EMMA-60 EMMA-120 Rated Output 45W RMS 60W RMS 120W RMS Output Less than 3dB from no-load to full load Regulation Ratio Speaker Output 4 Balanced ， 7 0V 、 1 00V REC Output 600 1V Inputs MIC1, 2, 3, 4, 5: 600 , 6mV Balanced AUX 1, 2: 10K , 270mV unbalanced ；...
