SERVICE MANUAL Colour Television
VIDEO
AUDIO
Specifications
Power Source . . . . . . . . .AC220V, 50Hz / 60Hz
Receiving System . . . . . .PAL (M/M, N/N), NTSC (M/M)
Channel Coverage
Antenna mode VHF: CH02-CH13, UHF: CH14-CH69
CATV mode
VHF band: CH01-CH13, Mid band: CH14-CH22
Super band: CH23-CH36, Hyper band: CH37-CH64
Ultra band: CH65-CH94 and CH100-CH125
Low mid band: CH95-CH99
Video IF . . . . . . . . . . . . . 45.75MHz
Aerial Input Impedance . . 75Ω
Ext. Terminals
Video inputs: Phono jack
Audio inputs: Phono jack
Sound Output (RMS) . . . . 2W
Speakers . . . . . . . . . . . 5 cm x 9 cm x 1 pc.
Dimensions . . . . . . . . . 496 (W)
Weight . . . . . . . . . . . . . approx. 16.7 Kg
Specifications subject to change without notice.
F5TW
-
+
CH
VOL
MENU
2 (1Vp - p, 75Ω)
2 (436mVrms, more than 40KΩ)
464 (H)
472 (D)mm
FILE NO.
Model No. TS4120
Service Ref. No. TS4120-00
JXMRR
Product Code: 111337817
Original Version
Chassis Series: LA5-A
Give complete "SERVICE REF. NO." for parts
order or servicing. It is shown on the rating
plate at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television trans-
mission system and power source differ from
the design specifications. Refer to the specifi-
cation table.
(Argentina)
Advertisement
Table of Contents
Related Manuals for Sansei TS4120
Summary of Contents for Sansei TS4120
- Page 1 FILE NO. SERVICE MANUAL Colour Television Model No. TS4120 (Argentina) Service Ref. No. TS4120-00 VIDEO AUDIO MENU JXMRR Specifications Product Code: 111337817 Power Source ..AC220V, 50Hz / 60Hz Receiving System ..PAL (M/M, N/N), NTSC (M/M)
-
Page 2: Table Of Contents
Contents Safety Notice ............... . 2 Chassis Block Diagram . -
Page 3: Chassis Block Diagram
Chassis Block Diagrams MAIN SIGNAL PROCESSING CIRCUIT... -
Page 4: Chassis Block Diagram
Chassis Block Diagrams SYSTEM CONTROL... -
Page 5: Ic Block Diagrams
IC Block Diagrams IC201 < IF/Video/Chroma/Def. > LA76818A Audio Output SIF Input FM Output/Selected SIF APC Filter Audio Output SIF Output PIF AGC Ext. Audio Input RF AGC Output PIF Input1 APC Filter VCO Coil 1 PIF Input 2 VCO Coil 2 IF Ground VCO Filter IF Vcc... - Page 6 IC Block Diagrams IC201 <IF System Block Diagram> LA76818A...
-
Page 7: Ic Block Diagrams
IC Block Diagrams IC001 < Audio AMP. > LA42052-E 30KΩ 300Ω POWER FILTER INPUT IC501 < Vertical Output > LA78040N, TDA9302H Thermal Protection Pump... -
Page 8: Service Adjustments
Service Adjustments General This set has an On-screen Service Menu system includ- ed in the CPU thar allows remote operation for most of the service adjustments. Service Adjustment-1 1. Enter the Service Menu While pressing the MENU button on the televi- sion, press the Number Key 2 on the remote control unit. - Page 9 Service Adjustments On-screen Service Menu Following table shows the initial values which have been stored in the CPU ROM, and items for the service adjustments. Item Initial value Range Description RFAGC 00~63 RF AGC adjustment H-PHA 00~31 H-PHASE adjustment (50Hz) V-POS 00~63 Vertical position adjustment (50Hz)
-
Page 10: Important Notice
Service Adjustments Item Initial value Range Description COOP 00~07 Colour Killer Y-APF 00, 01 Y-APF Select DEEM 00, 01 De-emphasis TC V-LVL 00~07 Video Level FMLVL 00~31 FM Level TTEST 00~07 Trap Test IFOM-S 00, 01 Over Mod. SW IFMN-S 00, 01 Audio Monitor SW, Monitor/FM IFTRPS... - Page 11 Service Adjustments Item 01 [RFAGC] AGC Item 12 [OSDHP] OSD POSITION NOTE: Do not attempt this adjustment with weak signal. (1) Receive a monochrome circular pattern. (1) Tune the receiver to most clearest (or strongest) VHF (2) Set the brightness and contrast to normal. station in your area.
- Page 12 Service Adjustments Items 16-23 GREY SCALE (1) Receive a monochrome circular pattern. (2) Set the brightness and colour to normal, contrast to maximum. (3) Enter to the service mode. (4) Set each value of Item-16 RBIAS, 17 GBIAS, 18 BBIAS mode to 00. Set each value of Item-19 RDRIV, 21 BDRIV mode to 63, 20 GDRIV to 07.
- Page 13 Service Adjustments Service Adjustment-2 FINE TUNING This adjustment is used to do a fine tuning of the channels with poor reception after they have been stored by the automatic tuning. This function is available for one channel only and the fine-tuned channel is memorized into IC802 (EEPROM). 1.
-
Page 14: Protection Circuit
Service Adjustments Service Adjustment-3 FOCUS ADJUSTMENT HIGH VOLTAGE CHECK (1) Receive the monochrome circular pattern. Note: +B (+130V) Voltage Check and Grayscale Adjustment (2) Set the brightness to normal and contrast to maximum. must be completed before attempting High Voltage Check. (3) Adjust the focus control on the F.B.T. -
Page 15: Purity And Convergence Adjustment
Purity and Convergence Adjustment CAUTION: The Convergence and Purity adjustments have been made at the factory. Readjustment should be made only after picture tube or deflection yoke replacement, following the steps below: PURITY ADJUSTMENT 8. Tighten the mounting screw of the Deflection Yoke. Adjust 1. -
Page 16: Cabinet Parts List
Cabinet Parts List Note: Parts order must contain Service Ref. No., Part No., and descriptions. AUDIO ANT.75Ω VIDEO IN VIDEO AUDIO MENU Key No. Part No. Description Key No. Part No. Description 610 269 8923 BUTTON POWER-F5TB 610 252 8725 SPRING-S-S6KL 610 270 5591 SPRING-HKG-S6KL... -
Page 17: Chassis Electrical Parts List
Chassis Electrical Parts List F5TW Product safety should be considered when a component replacement is made in any area of a receiver. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety. - Page 18 F5TW Ref. No. Part No. Description Ref. No. Part No. Description 405 013 7006 TR 2SC2274-F 405 020 7709 TR 2SC945A-QA Q641 406 000 6804 TR 2SA1015-GR(SAN) 405 020 7907 TR 2SC945A-RA 405 001 7605 TR 2SA1015-Y(SAN) Q693 405 011 8401 TR 2SC1740S-Q 405 004 3208 TR 2SA564A-R(CU)
- Page 19 F5TW Ref. No. Part No. Description Ref. No. Part No. Description IC801 410 527 1907 IC LC863440W-53Z0-TLM C441 403 346 6901 MT-POLYPRO 0.22U J 250V IC802 409 495 7004 IC CAT24WC04P C442 403 346 6901 MT-POLYPRO 0.22U J 250V 409 470 3403 IC KS24C041C C469 403 049 4204...
- Page 20 F5TW Ref. No. Part No. Description Ref. No. Part No. Description C681 403 040 5408 ELECT 2200U M R224 401 105 5301 MT-GLAZE 4.7K JA 1/16W C691 403 039 6508 ELECT 100U M R225 401 105 5301 MT-GLAZE 4.7K JA 1/16W C693 403 043 9106 ELECT...
- Page 21 F5TW Ref. No. Part No. Description Ref. No. Part No. Description R619 401 016 1508 CARBON 22 JA 1/4W R851 401 025 1605 CARBON 1.5K JA 1/6W R620 401 010 4802 CARBON 470K JA 1/2W R853 401 027 8602 CARBON 8.2K JA 1/6W R621...
- Page 22 F5TW Ref. No. Part No. Description Ref. No. Part No. Description D1910 407 206 5608 ZENER DIODE UDZS-TE-1710B 408 047 8605 ZENER DIODE MTZJ6.8A D249 407 099 6003 ZENER DIODE MTZJ9.1B D664 407 099 6102 ZENER DIODE MTZJ10B D352 407 063 8705 ZENER DIODE MTZJ5.1C 407 054 0008 ZENER DIODE RD10EB2...
- Page 23 F5TW Ref. No. Part No. Description Ref. No. Part No. Description 405 066 9903 TR 2SC2688(1)-K COIL 405 067 0008 TR 2SC2688(1)-L L701 645 001 4826 INDUCTOR,180U K 405 067 0107 TR 2SC2688(1)-M DIODE Q711 406 000 3605 TR 2SC3620(LB-SAN-1) 405 041 6507 TR 2SC2621-D-RA D741...
- Page 24 July/’04...
- Page 25 12 X 10 =12K SERVICE Rated wattage (1/2W) W: Wire wounding TS4120-00 may be some components or partial circuit differences between the C: Solid actual chassis and the circuit diagram. REF. NO. 9. Parts specified with "X" are not installed in this model.
- Page 26 Waveforms & Voltages CRT BOARD (Component Location) (On the Main Board) 1AA4B10E6900B IC001 (AUDIO AMP.) Pin-1 1.1V 0.7V 0.7V 0.7V 14.8V Q701 R741 B-OUT D741 D742 J702 IC201 (IF/VIDEO/CHROMA) Q701-L D754 Q711 Pin-1 2.3V 2.2V 2.7V 1.7V 2.9V 2.9V 5.0V 2.3V L700 Q721...
