User's Manual
NVIDIA GeForce GTX 465
NVIDIA GeForce GTX 470
NVIDIA GeForce GTX 480
To ensure safe and easy installation,
please read the following precautions.
http://www.ZALMAN.com
VF3000F
Ver. 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the vf3000f and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZALMAN vf3000f

  • Page 1 User’s Manual VF3000F NVIDIA GeForce GTX 465 NVIDIA GeForce GTX 470 NVIDIA GeForce GTX 480 To ensure safe and easy installation, please read the following precautions. http://www.ZALMAN.com Ver. 1.1...
  • Page 2: Specifications

    NVIDIA GeForce GTX465, GTX470, GTX480. By installing this product on a VGA (Video Graphics Array) card, two PCI slots immediately below the PCIe (or AGP) slot occupied by the VF3000F will become unusable. If this product is to be installed on a recently released VGA card, please check for compatibility at Zalman’s website first.
  • Page 3 3. Components GTX480 GTX470 / 465 VF3000F VGA RAM Heatsink Thermal Grease Fixing Nut × 4 Spring × 4 Nipple × 4 [ZM-STG2] Rubber Ring × 4 User’s Manual Bolt × 10 Rubber Washer × 12 PET Washer × 10 PVC Washer ×...
  • Page 4: Exploded View

    4. Exploded View VGA Cooler Nipple Rubber Ring VGA RAM Heatsink Rubber Washer VGA Chipset PVC Washer Spring Fixing Nut PET Washer Bolt The manual makes references to the installation procedure of GTX470/ 465 VGA RAM Heatsink. .COM...
  • Page 5: Installation

    5. Installation 1) VGA RAM Heatsink Rubber Washer Attachment Attach the Rubber Washers to the VGA RAM Heatsink’s holes. <GTX 470 / 465> <GTX 480> 2) VGA Card PET Washer Attachment Attach the PET Washers to the VGA Card’s holes on the rear. <GTX 470 / 465>...
  • Page 6 4) VGA RAM Heatsink Attachment Attach the VGA RAM Heatsink to the VGA Card. 5) VGA RAM Heatsink Fastening Align the VGA RAM Heatsink to the VGA Card’s installation holes and fasten Bolts on the rear side of the card. Caution ▶...
  • Page 7 7) VGA Chipset Thermal Grease Application Apply a thin and thorough layer of Thermal Grease on the contact surface of the VGA Chipset that touches the base of the VGA cooler 8) Cooler Installation After installing the Nipples and Rubber Rings to the Cooler, mount the Cooler to the VGA Card.
  • Page 8 Caution ▶ Please tighten each of the 4 Fixing Nuts one rotation at a time until all are completely tightened. ※ Completely fastening one Nut at a time can damage the VGA Chipset. ▶ Make sure the Cooler Base is installed in full adhesion with the VGA Chipset. ▶...
  • Page 9 2) Fan Mate 2 Operation Fan Speed Control Knob Adjust the desired RPM setting by moving the Fan Speed Control Knob left or right. .COM...
