The Alarm is a Z-Wave enabled device which is fully compatible with any Z-Wave enabled
network. Z-Wave enabled devices displaying the Z-Wave logo can also be used with it regardless
of the manufacture, and ours can also be used in other manufacture's networks. This device can
control our modules via controller settings. Inclusion of this alarm on other manufacture's
Wireless Controller menu allows remote turn-on of connected modules when the detector is
triggered. After this product included into the network, when the associated device (such as:
sensor) is triggered, the alarm can send out alarm after receiving the wireless message. The alarm
is a combination of alarm and flash, the alarm volume can reach 100 db and 90 db. When the
alarm receiving a wireless (RF) directive, may be lead to two kinds of results: it is to start the
alarm and flash or it is to close the alarm and flash.
CAP-TECH INTERNATIONAL CO.,LTD.
www.cap-homey.com
ALARM

Introduction

User Manual
CT-SMZW2008-ES
Alarm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-SMZW2008-ES and is the answer not in the manual?

Questions and answers

Summary of Contents for CAP CT-SMZW2008-ES

  • Page 1 100 db and 90 db. When the alarm receiving a wireless (RF) directive, may be lead to two kinds of results: it is to start the alarm and flash or it is to close the alarm and flash. CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 2 Alarm volume: 100 db and 90 db. Operation As shown below, respectively alarm front, side and rear graph: NOTE: ① LED ② Red flashing lights ③ Two phase volume jumper ④ Tamper warning jumper ⑤ Tamper Switch CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 3 Please go to the device list interface, and refresh the device list, the device will not be displayed. If the device can still be displayed (network exclusion failed), repeat steps 2-4. NOTE: CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 4 Loosen and remove the screw at the bottom of the alarm, then slip he alarm back cover, the back cover can be removed;(Fig. 1 & 2) Insert 4 LR14/1.5 V alkaline batteries to the battery compartment, ensuring correct polarity is put (Fig.3). Fig.1 Fig.2 Fig.3 CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 5 Using the back cover as the example, identified three screw holes on the wall. Use the attached plastic gecko and screws, fixed the back cover on the wall (Fig.6). Fig.6 Put the alarm main body into the back cover, and lock the screws (Fig.7). Fig.7 CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 6 3 minutes. Safety Notice  Don't make the device directly to the window/fan/air-conditioner or sunlight.  Do not install the device above or facing any source of heat directly, such as fires, radiators, CAP-TECH INTERNATIONAL CO.,LTD.
  • Page 7 Where possible, mount the detector so that the logical path of an intruder would cut across the fan pattern rather than directly towards the detector.  In order to obtain the best results, please put the detector directly facing the entrance. CAP-TECH INTERNATIONAL CO.,LTD.
