5.2 Cleaning the Main Brush and Dusting Brush

Excessive build up of hair in the brushes can damage the robot. Please clean the brushes
at least once per week.
1 Turn the robot over and
put it on a smooth soft
and level surface.
4 Clean any hair and dirt
wrapped around the
brushes with a cleaner
or scissors. Don't wash
the brushes to avoid any
damage.
NOTE:
1. Make sure that the flanges of the brush guard are aligned with the fixed grooves of the
main body.
2. Make sure that the side brushes are not stuck under the brush guard.
5.3 Cleaning the Sensors and Charging Contacts
Turn the robot over, put it on a smooth soft and level surface. Use a soft and dry cloth or
cleaning brush to clean the sensors and charging contact pieces. Please follow the steps
as below:
1
18
2 Remove the brush guard by
lifting both fixing clasps.
5 Install the main brush and
dusting brush into the
robot.
2
3 Lift up the right side of
the brushes and take
them out in order.
6
Make the flanges of the
brush bracket align with the
fixed grooves of the main
body. Then press the fixed
clasps inward. It will click
when installed correctly.
3
