Sony DPF-D70 Service Manual

SERVICE MANUAL
Ver. 1.4 2008.11
Revised-4
Replace the previously issued
SERVICE MANUAL 9-852-290-14
with this Manual.
SPECIFICATIONS
■ Photo frame
LCD screen
LCD panel: 7 inches, TFT active matrix
Total number of dots: 1 152 000
(800 × 3 (RGB) × 480) dots
Display aspect ratio
15:9
Effective display area
7 inches
LCD backlight life
20 000 hours (before brightness of the backlight being reduced to half )
Maximum decodable file size
100 MB
Input/Output connectors
USB connector (miniB, full-speed) Slots
"Memory Stick PRO" slot
SD memory card/MMC/xD-Picture Card slot
CompactFlash card/Microdrive slot
Compatible image file formats
JPEG: DCF 2.0 compatible, Exif 2.21 compatible, JFIF
*2
RAW (preview only ): SRF, SR2, ARW (2.0 or lower version)
(Some image file formats are not compatible.)
Maximum number of pixels that can be displayed
8 000 (H) × 6 000 (V) pixels
File system
FAT12/16/32, sector size of 2 048 bytes or smaller
Image file name
DCF format, 256 characters, within 8th hierarchy
Maximum number of files that can be handled
9 999 files for a memory card/an external device
Internal memory capacity
256 MB (Approx. 500 images
Power requirements
DC IN jack, DC 12V
Power consumption
7.7 W
Operating temperature
5 °C to 35 °C (41 °F to 95 °F)
Dimensions
[Without the stand]
Approx. 207 × 137 × 38.5 mm (8 1/4 × 5 1/2 × 1 9/16 inches)
(width/height/depth)
[With the stand spread out]
Approx. 207 × 137 × 125 mm (8 1/4 × 5 1/2 × 5 inches)
(width/height/depth)
DPF-D70
9-852-290-15
*1
*3
*4
can be saved.)
Sony EMCS Co.
DPF-D70
Canadian Model
East European Model
Australian Model
HongKong Model
Mass
Approx. 550 g (1 lb 3 oz) (excluding the AC adaptor)
Included accessories
• Digital photo frame
• Remote control
• AC adaptor
• Operating Instructions
• Warranty
(In some regions, the warranty is not supplied.)
■ Supplied AC adaptor
Power requirements
~100 V to 240 V, 50/60 Hz
Rated output voltage
12 V 1.2 A
Dimensions
Approx. 34 × 72 × 69 mm (1 3/8 × 2 7/8 × 2 3/4 inches)
(width/height/depth) (excluding the protruding parts)
Mass
Approx. 110 g (4 oz)
See the label of AC adaptor for more details.
Design and specifications are subject to change without notice.
*1: Baseline JPEG with 4:4:4, 4:2:2, or 4:2:0 format
*2: RAW files are displayed as thumbnail preview.
*3: The capacity is calculated as 1 MB is equivalent to
1 000 000 bytes. The actual capacity is reduced as files for
management and applications are included.
Approx. 200 MB can be used for your actual operation.
*4: Approximate number is shown when the images taken by 1 500 000
pixels equivalent camera are saved.
The value may vary depending on the shooting condition.
DIGITAL PHOTO FRAME
US Model
AEP Model
UK Model
Russian Model
E Model
Chinese Model
Korea Model
2008K0200-1
© 2008.11
Published by Kohda TEC
