Operating Instructions
This manual is common to all the models regardless of suffixes of the model number.
*
U : for US, Canada and Mexico
E : for EU and CIS
W : for South East Asia and Middle East Asia
Please read these instructions before operating your set and retain
English
them for future reference.
Operating Instructions
Touch Screen LCD Display For business use
Network Operations
TH-80BF1U
Model No.
TH-65BF1U
TH-50BF1U
TH-80BF1E
TH-65BF1E
TH-50BF1E
TH-80BF1W
TH-65BF1W
TH-50BF1W
80-inch model
65-inch model
50-inch model
80-inch model
65-inch model
50-inch model
80-inch model
65-inch model
50-inch model
DPQP1035ZA/X1
Advertisement
Table of Contents
Related Manuals for Panasonic TH-80BF1U
Summary of Contents for Panasonic TH-80BF1U
-
Page 1: Operating Instructions
Operating Instructions Network Operations Touch Screen LCD Display For business use TH-80BF1U 80-inch model Model No. TH-65BF1U 65-inch model TH-50BF1U 50-inch model TH-80BF1E 80-inch model TH-65BF1E 65-inch model TH-50BF1E 50-inch model TH-80BF1W 80-inch model TH-65BF1W 65-inch model TH-50BF1W 50-inch model This manual is common to all the models regardless of suffixes of the model number. -
Page 2: Table Of Contents
Contents Before use • Illustrations and screens in this Operating Instructions are images for illustration purposes, and may be different from the actual ones. • Descriptive illustrations in this Operating Instructions are created mainly based on the 50 inch model. Read this first! ·... -
Page 3: Read This First
FCC CAUTION: To assure continued compliance, follow the attached installation instructions and use only the provided power supply cord. Any changes or modifications not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate this device. -
Page 4: Lcd Display
LCD Display Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this Display is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” If you want to get a copy of the original DoC of this Display, please visit the following website: http://www.doc.panasonic.de... -
Page 5: Request Regarding Security
Please contact Panasonic if you need help taking care of security settings or other such. If you cannot perform security settings for your wireless LAN by yourself, please contact the Panasonic Support Center. Panasonic asks customers to thoroughly understand the risk of using this product without making security settings, and... -
Page 6: What You Can Do
This unit does not support the following functions. Virtual remote control function USB display function ● Wireless Projector for iOS (Panasonic Wireless Projector for iOS) Software for sending PowerPoint files / PDF files, images, etc. saved in an iPad/iPhone/iPod touch to this unit ®... - Page 7 Multi Monitoring & Control Software This unit supports “Multi Monitoring & Control Software” which monitors and controls devices (projectors or flat-panel displays) connected to an intranet. For details, see the following website. http://panasonic.net/prodisplays/download/software/index.html • This unit is not compatible with content list distribution function.
-
Page 8: Notes On Using Wireless Connection
IEEE802.11b/g/n 1 - 11 2.412 GHz - 2.462 GHz (Except for Europe and CIS) For M-DIRECT mode (When the connecting method is “M-DIRECT” of “Panasonic APPLICATION” (see page 16)) Country or region Standard Channels used Frequency band (Center frequency) For Europe and CIS IEEE802.11b/g/n... -
Page 9: Notes On Using Wired Lan
Notes on Using Wireless Connection For USER mode (When the connecting method is “USER1”/“USER2”/“USER3” of “Panasonic APPLICATION” (see page 17)) Frequency band Country or region Standard Channels used Scanning type (Center frequency) IEEE802.11b/g/n 1 - 13 2.412 GHz - 2.472 GHz... -
Page 10: Check Your Computer
Check your computer Necessary environment for computers to be connected • First, check your computer to see whether or not it has a wired LAN or a built-in wireless LAN function. • Before connecting the Display to the computer, be sure to check the following settings. •... -
Page 11: Connection
Connection Example of Network Connection (Wired LAN) COMPUTER Display (main unit, rear) LAN cable (not supplied) LAN cable (commercial) Hub or broadband router • When using network, set “Network settings” - “Network control” to “On”. (see page 22) When the unit enters the standby mode from power on (Picture is displayed.) status, the network function is disabled for approx. -
Page 12: Example Of Network Connection (Digital Link)
Connection Example of Network Connection (DIGITAL LINK) A twisted pair cable transmitter, such as the Panasonic device that supports DIGITAL LINK output (ET-YFB100G, ET-YFB200G) uses twisted pair cables to transmit inputted video and audio signals, and these digital signals can be input to the Display via the DIGITAL LINK terminal. -
Page 13: Network Settings
Network Wired LAN Wireless LAN MIRRORING Name change Network control WEB Control AMX D.D. Crestron Connected™ Network status Panasonic APPLICATION Password Multi-Live Live mode cut in DIGITAL LINK DIGITAL LINK status DIGITAL LINK menu DIGITAL LINK mode Auto Extron XTP Reset Press ▲... -
Page 14: Wired Lan
Network settings Wired LAN Detailed network settings for the LAN established via the LAN terminal of the Display or twisted pair cable transmitter can be configured. Select “Wired LAN” in “Network settings” menu and press button. Select the item and press button. -
Page 15: Wireless Lan
Use the wireless LAN function via the application software which supports “Wireless Manager ME6.3”, iPad / iPhone / iPod touch and Android devices. Switch the input to “Panasonic APPLICATION”, the idle screen will appear. You can confirm the SSID and KEY. The factory default value of the KEY can be changed. For details, refer to the following “Configuration of Wireless LAN “Simple””. - Page 16 The following settings as “M-DIRECT” in the “Wireless LAN” are set before the Display leaves the factory. IP address 192.168.12.100 Subnet mask 255.255.255.0 SSID M-DIRECT + The last 4 digits of the Network ID Channel The same string as the SSID Off (TH-80BF1U, TH-65BF1U, TH-50BF1U, Wireless network standby TH-80BF1W, TH-65BF1W, TH-50BF1W) Wireless WEB control...
- Page 17 Network settings • The authentication method is WPA2-PSK, and the encryption method is AES. Both methods are fixed. • When you need to change initial configuration of “M-DIRECT”, please contact your network administrator. • Make sure the initial Key is changed for safety. •...
- Page 18 Network settings Press ▼ to go to the next item. Make the settings related to the wireless connection between the Display and the network. SSID Authentication Open Encryption None ● SSID : Enter the SSID registered at the access point. Entering characters page 21 •...
- Page 19 Save the current network settings. ■ Default settings of “USER1” - “USER3” The following settings as “USER1” - “USER3” in the “Wireless LAN” are set before the Display leaves the factory. SSID Panasonic Display Authentication Open DHCP Encryption None IP address 192.168.11.100...
-
Page 20: Mirroring
Network settings MIRRORING You can make detailed settings of the MIRRORING function. Select “MIRRORING” in “Network settings” menu and press button. Set each item in “MIRRORING”. Sets the display to be or not to be the autonomous group owner via Intel ®... -
Page 21: Name Change
Network settings Name change You can change the Display name to be displayed on the network. Select “Name change” in “Network settings” menu and press button. The keyboard is displayed. Up to 8 characters can be entered for the Display name. Name Change Name0000 █... -
Page 22: Network Control
Network settings Network control Set when controlling with the unit’s DIGITAL LINK / LAN terminal. Select “Network control” in “Network settings” menu and press button. Select “On” or “Off”. Controls via LAN using the LAN terminal of the Display or twisted pair cable transmitter or via RS-232C using the SERIAL (RS-232C) terminal of twisted pair cable transmitter. -
Page 23: Network Status
It is recommended to change password on a regular basis for keeping it private. Multi-Live Switch to the MULTI-LIVE mode when using the “Wireless Manager”. See the “Wireless Manager” operation manual for details. When using Panasonic APPLICATION input, select “Multi-Live” in “Network settings” menu and press button. -
Page 24: Live Mode Cut In
Panasonic device that supports DIGITAL LINK output. • This function can only be selected when the Panasonic device that supports DIGITAL LINK output (ET-YFB100G, ET-YFB200G) is connected to a LAN terminal and its power is on. -
Page 25: Digital Link Mode
Network settings DIGITAL LINK mode You can switch the setting of DIGITAL LINK/LAN terminal. LAN: Enables LAN communication via the Display's LAN terminal. Auto (LAN): Enables automatic selection between LAN communication via the Display's LAN terminal and HDMI/ LAN communication via the twisted pair cable transmitter. DIGITAL LINK (LAN): Enables HDMI/LAN communication via the twisted pair cable transmitter. -
Page 26: Connecting With Wired Lan
SSID is “M-DIRECT + The last 4 digits of the Network ID”. When you select default settings of “USER1” - “USER3” for “Wireless LAN” in the “Network settings” menu, the SSID is “Panasonic Display”. • If you use any wireless utility other than Windows “Wireless Network Connection”, follow its operation procedure for connection. -
Page 27: Using Web Browser Control
Using Web Browser Control You can use a Web browser to control the unit and set up a network and password. Before Using Web Browser Control To use the Web browser control, the unit and computer set ups are required. ■... -
Page 28: Accessing From The Web Browser
Enter your “User name” and “Password”. The factory default settings are user1 (user privileges) or admin1 (administrator privileges) for the user name and panasonic for the password. Click “OK” to display the Display status page. “Display status” page is displayed. - Page 29 Using Web Browser Control ■ Description of each item Page tab Detailed set up Click this item to display the advanced settings Click these to switch pages. page. Status Change password Click this item, and the status of the Display is displayed.
- Page 30 Using Web Browser Control Network status page Click “Status”, then “Network status” to display the Status information page. Displays the current configuration information of the network. Displays the configuration details of wireless LAN. Displays the configuration details of wired LAN.
- Page 31 Switching to MIRRORING and MEMORY VIEWER input will not be possible. • Control will not be possible with Crestron Connected™. TH-80BF1U, TH-65BF1U, TH-50BF1U, TH-80BF1W, TH-65BF1W, TH-50BF1W • When “Wireless network standby” is off, operation for turning the power on/off will not be shown.
- Page 32 Button for executing password change • When changing the administrator account, both “Current user name” and “Current password” are required. • The default password is “panasonic”. • Up to 16 alphanumeric characters can be used for a password. • When the password is changed properly, “Password has changed.” message is displayed.
- Page 33 Using Web Browser Control Network config page You can make detail network settings on Display, when connecting without the administrator authority or when connecting with Wireless LAN. ■ LAN settings Click “Detailed set up” in the menu. Select the items to change and click “Next”. The settings window appears, showing the current settings.
- Page 34 Using Web Browser Control Click “Submit”. The settings will be registered. (Wireless LAN screen) ■ Making the above settings effective (Only for wireless LAN) Select “Wireless LAN” in “Network settings” menu of the Display, and select the network set in this page. •...
- Page 35 Using Web Browser Control Ping test page This page makes it possible to check whether the network is connected to the DNS server, etc. Click “Detailed set up”, then “Ping test” to display the Ping test page. Display which appears when the connection was successful.
- Page 36 Using Web Browser Control E-mail set up page You can send image data displayed by the whiteboard function using an E-mail. Click “Detailed set up” → “E-mail set up”. “ENABLE” Select “Enable” to use the e-mail function. “SMTP SERVER NAME” Enter the IP address or the server name of the e-mail server (SMTP).
- Page 37 Using Web Browser Control Authentication server setup page Set the authentication items for the server necessary to send an e-mail. Click “Detailed set up” → “Authentication set up”. “Auth” Select the authentication method specified by your network administrator. (OFF, SMPT Auth, POP before SMTP) “SMTP Auth”...
- Page 38 Using Web Browser Control Crestron Connected™ page You can monitor or control the Display using Crestron Connected™. When you click “Crestron Connected™”, the Crestron Connected™ operation page is displayed. If Adobe Flash Player is not installed in your computer, or if the browser does not support Flash, this page does not appear.
- Page 39 Using Web Browser Control Info page Click Info on the operation page. Display Name Panasonic LCD Display Displays the name of the Display. Mac address Displays the MAC address. Name1234 Resolution Displays the resolution of the Display. Power Status Displays the status of the power.
-
Page 40: Pjlink™ Protocol
NAME? Display name query The name set for “Name change” in “Network settings” is returned. INF1? Manufacturer name query Returns “Panasonic” INF2? Model name query Returns “80BF1U” / “65BF1U” / “50BF1U” (U model) Returns “80BF1E” / “65BF1E” / “50BF1E” (E model) Returns “80BF1W”... - Page 41 5770 Ambler Drive Mississauga, Ontario L4W 2T3 For TH-80BF1E, TH-65BF1E and TH-50BF1E Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, F.R. Germany Web Site : http://panasonic.com M0416TS0 -PB Panasonic Corporation 2016...
