Users' Manual
DropCam MK2

User Manual

Page 1
Version 1.0
30 September 2010
Specifications subject to change without notice
Cobham Surveillance
Domo Products
11 Manor Court, Barnes Wallis Road, Segensworth,
Hampshire, PO15 5TH, England
T: +44 (0)1489 566 750
F: +44 (0)1489 880 538

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DropCam MK2 and is the answer not in the manual?

Questions and answers

Summary of Contents for COBHAM DropCam MK2

  • Page 1: User Manual

    Users’ Manual DropCam MK2 User Manual Cobham Surveillance Domo Products 11 Manor Court, Barnes Wallis Road, Segensworth, Page 1 Specifications subject to change without notice Hampshire, PO15 5TH, England Version 1.0 T: +44 (0)1489 566 750 30 September 2010 F: +44 (0)1489 880 538...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ....................2 Change History ...................... 3 About this Manual ....................4 Introduction ......................5 Warranty and Support ................... 6 Warranty Cover ....................6 Safety, Compliance and Approvals ..............7 Safe Operating Procedures ................7 EMC / Safety and Radio Approvals ..............
  • Page 3: Change History

    Change History Version Main Changes from Previous Version Edited By v1.0 Initial Release...
  • Page 4: About This Manual

    About this Manual This manual describes the operation of domo DropCam Transmitter. The manual is divided into three main sections. • Getting started and basic operation This section describes to users how to deploy and use a domo DropCam transmitter. •...
  • Page 5: Introduction

    Introduction The SOL4DCAM MK2 is a the second generation drop camera from Cobham. The SOL4DCAM MK2Transmitter incorporates a COFDM digital video transmitter, battery, camera and microphone into a rapid deployment robust chassis. The integral camera can also be abstracted on a cable or used as a generic video input giving the second generation DropCam a high degree of flexibility.
  • Page 6: Warranty And Support

    Warranty and Support 1.1 Warranty Cover domo offers a 12 month standard product warranty. During this period, should the customer encounter a fault with the equipment we recommend the following course of action: Check the support section of the website for information on that product •...
  • Page 7: Safety, Compliance And Approvals

    Safety, Compliance and Approvals 1.1 Safe Operating Procedures Ensure that the power supply arrangements are adequate to meet the • stated requirements of the SOL4DCAM transmitter. Operate within the environmental limits specified for the product. • • Only authorized, trained personnel should open the product. There are no functions that required the User to gain access to the interior of the product.
  • Page 8: Getting Started And Basic Operation

    Getting Started and Basic Operation 1.1 Which Model do I have? The DropCam is marked with a product code panel as shown below, the panel gives the product code, serial number and bar code. domo SOL4DCAM-P-200250 SN 123456 Made in the UK The domo product code can be referenced in the table below.
  • Page 9: Controls

    Controls The DropCam has dual button control panel, a seven segment display indicator and LEDs. Button 1 is the Control Button and is coloured green. The control button is used to enable the DropCam and allows users to cycle between 8 internally stored configurations.
  • Page 10 Status Display Current State Display Meaning Chasing display DropCam is charging ‘C’ displayed DropCam is fully charged Number 1-8 displayed Current configuration number Decimal point displayed External control connected Battery LED Current State LED Colour Meaning Not Charging Flashing Green Normal Operation Flashing Orange Battery Low...
  • Page 11 from 1 to 8 and then back to 1, release the button when you have reached the desired configuration. After approximately 10 seconds the display will shut off, the LED will continue to flash once per second to show charging status. To turn off the unit, press and hold the button, the display will show the configuration number and then turn off, as will the LED.
  • Page 12 Connecting the Antennas The DropCam is supplied with flexible omni directional antennas with a nominal gain of 2dBi. The antenna should be connected to the SMA female connector on the rear of the unit, care should be taken to not over tighten the SMA. The supplied antennas are suitable for all general purpose transmissions, however for longer range transmissions customers may choose to connect higher gain antennas, and domo has a range of...
  • Page 13 The Camera The DropCam is equipped with a camera module, the module can be connected directly to the DropCam body, or remotely using a cable. DropCam with camera connected directly. DropCam with remote camera The camera head can be removed from the body, by gripping the camera head and pulling firmly away from the body.
  • Page 14 Sensitivity: 0.05Lux Signal to noise: >46dB The 3.4mm Lens fitted as standard offers a wide field of view, suitable for surveying a room. However the standard camera accepts M12 lenses and is supplied with additional lenses for longer range surveillance. Changing the Lens Interchanging lenses is a user operation, and there is no need to return the equipment to domo to do this.
  • Page 15 Sensitivity: 60dB +/-3dB Mounting the DropCam The DropCam is a rugged device designed for out door deployment in adverse conditions. The DropCam unit is supplied with a range of mounting options to facilitate easy deployment. 1) ¼ ‘’ threaded tripod mount in the base of the DropCam facilitates the connection to general purpose tripods and camera mounts.
  • Page 16: Advanced Operation

    Advanced Operation 1.1 SOLO System PC Controller Application Software Advanced control of the SOLO4 DropCam system is available by using PC control applications. Typically users may want to customize the default configurations to control settings such as frequency, scrambling keys, modulation parameters, and video resolution.
  • Page 17 For both controllers, changes can be made to the unit configuration using the drop down and data entry fields. Changes are only applied to the unit when the “Apply” button is clicked. Current values, as running in the unit, can be read using the “Refresh” button.
  • Page 18: Transmitter Control Application

    1.2 Transmitter Control Application Engineering Polling Set Polling Enter an Enter a Menu Enable Options Encryption Licence key Restore Connectivity Factory Status Defaults Current selected Config All parameter changes must be applied Communications Video alarm Connected RF Output Toggle & status The ‘Advanced’...
  • Page 19 Bandwidth Mode The Bandwidth Mode switches the unit between either domo Narrowband (2.5MHz or 1.25MHz channel bandwidths) or DVB-T 8MHz bandwidth. To select 6MHz and 7MHx DVB-T modes the user must first click on ‘Advanced’ to enter the Advanced setting page. Audio Turns ‘On’...
  • Page 20 Advanced TX Controller Window Output Frequency (MHz) The transmit frequency can be changed by entering the new desired frequency in this field. Values outside the range supported by a particular transmitter type will be rounded to the highest of lowest supported frequency as appropriate.
  • Page 21 Link Bitrate Sensitivity 2.4Mb/s -99dBm 1.2Mb/s -102dBm Narrow Band Guard Interval This option applies to SOLO4 transmitters only. The Guard Interval defaults to 1/16. Interval 1/8 is also available for very long range (aircraft downlinks) applications. Narrow Band Modulation This option applies to SOLO4 transmitters only. The COFDM mode can be changed between QPSK and 16QAM.
  • Page 22 Output Attenuation This control can be used to make minor adjustments to the output power level, but in normal operation should be disregarded. Video Input This control is used to select the composite video input standard. Options are PAL, and NTSC both with and without 7.5 IRE pedestal. The licensed SDI digital video input can also be selected.
  • Page 23 Horizontal resolution The video coding resolution can be selected from 704, 528, 480 and 352 pixels. Changing the horizontal resolution to lower values will make the coded picture softer. Care should be taken to match the horizontal resolution to the resolution of the camera connected to the transmitter;...
  • Page 24 Data With this ON / OFF control the user can select whether the transmitter passes serial RS232 data across the RF link to the receiver. Data Baud Rate This field is used to select the baud rate of any RS232 serial data component to be passed from the transmitter to the receiver across the RF link.
  • Page 25 Serial Number (Status Only) This status information is the electronic serial number of the transmitter PCB. This number can be exchanged with domo to purchase extra licensable features, such as upgrades to support AES encryption. Chaining (Status Only) This field reports the status of the chaining input to the SOLO transmitter, and is not active in current units.
  • Page 26: Fault Finding

    Fault Finding Symptom Suggested Action No RF Link Check a suitable transmitter RF source is active, on correct frequency. Ensure Downconverters are connected. Ensure antennas are connected to downconverters. Ensure there is no interfering signal. Poor link Poor performance of the link can occur for the following reasons. performance Interference.
  • Page 27: Connector Pin Outs

    Connector Pin Outs 1.1 Power and Control – 12 Pin Male Cable - Binder 9991330212, RS 469-086 Female Cable - Binder 9991340212, RS 468-932 Pin No Function +12V Out CVBS/Luma VGnd Chroma Camera RS232 TX Camera RS232 RX Microphone Microphone GND Ext Trig 1 Ext Trig 2 1.2 Power and Control –...
  • Page 28: Control Protocols

    Control Protocols The following section describes the control protocol employed on the RS232 link for controlling the SOLO transmitters and receiver equipment. Connection details are detailed in previous sections. Note that only features that are licensed for use in the SOLO units can be controlled. The protocols listed here cover all possible features.
  • Page 29: Packet Structure Reply (From Controlled Device)

    1.3 Packet Structure Reply (from controlled device) ASCII Value Start byte 30h-39h 4 byte unit address. In range 0-9999 20h-7Eh Status BYTE 20h-7Eh Data –Optional, variable length Separator 20h-7Eh Sum Check End byte The Sum check byte is the summation of all bytes in the packet, not including the start and end bytes.
  • Page 30: Transmitter Command List

    1.4 Transmitter Command List Type ‘o’ messages for Modulation commands Function Block Command Data Type 1 byte Modulation 0 OFF IF output 1 COFDM Set Narrow 1 byte Band 1 = 2/3 Modulation 2 = 1/3 Set Narrow 1 byte Band 1 = 1/16 Modulation...
  • Page 31 Type ‘z’ messages for Scrambling commands Function Block Command Data Type Scrambling 1 byte 0 = Off 1 = ABS 4 = AES128 6 = AES256 8 = Bcrypt128 10 = Bcrypt256 AES Key Encryption key for Hex string lower 128 AES lower 128 characters) AES Key...
  • Page 32 Type ‘v’ and ‘e’ messages for Video commands Function Block Command Data Type Video Input 1 byte 0 = Off 2 = PAL 3 = NTSC 4 = NTSC No Pedestal 5 = PAL S-vid 6 = NTSC S-vid 7 = NTSC S-Vid No pedestal 8 = SDI PAL 9 = SDI NTSC...
  • Page 33 Type ‘a’ messages for Audio commands (applies to audio channel 1 and audio channel 2) Function Block Command Data Type Audio 1 byte Encoder 0 = Off 1 = 32kHz,12cbit,S 2 = 32kHz,12cbit,M 3 = 32kHz,8cbit,S 4 = 32kHz,8cbit,M 5 = 16kHz,8cbit,S 6 = 16kHz,8cbit,M 7 = 8kHz,8cbit,S 8 = 8kHz,8cbit,M...
  • Page 34 Audio 0 = analogue Source 1 = aes/ebu digital 2 = embedded MPEG Audio PTS offset for Offset MPEG Audio Type ‘g’ messages for Unit Level commands Function Block Command Data Type Software Software version Hex string Version number FPGA FPGA version Hex string Version...
  • Page 35 2= discharging 3=temp fault 4=bad battery Drop cam Voltage in multiples voltage of 100mV Drop Cam Current in multiples charger of 10mA current...
  • Page 36 Type ‘p’ messages for SI Function Block Command Data Type PCR PID 0 = default Other = value PMT PID 0 = default Other = value Video 0 = default Stream ID Other = value Audio 0 = default Stream ID Other = value Transport 0 = default...
  • Page 37 Type ‘c’ messages for Chaining commands Function Block Command Data Type Chaining 0 = Off Input 1 = On 2 = Relay Chaining 0 = Off Output 1 = On Chaining 0 = Off Loop 1 = output loop to input for external encryption Chaining...
  • Page 38: Default Configurations

    Default Configurations This section tabulates the default configuration settings for domo SOLO products. Item DROPCAM-x-200250 (2.0 DROPCAM-x-100150 (1.0 to 2.5GHz) to 1.5GHz) RF Output Frequency 2405MHz 1395MHZ Modulation QPSK QPSK Power Maximum Maximum Standby Unit Address 0001 0001 Unit name Solo-01 (SOLO4) Unit 1 (SOLO2) Solo-01 (SOLO4) Unit 1 (SOLO2) Horizontal...
