INSTALLATION OPERATION & SERVICE MANuAL

Heat On Demand

u.S. Patent# 5 306 858 and 5 786 643 and 6 005 233 and 6 188 053

Japanese Patent# 3362855 other u.S. and Foreign Patents Issued and Pending

MODEL IND600

ULTRA

Table of Contents

Troubleshooting

Need help?

Do you have a question about the IND600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aladdin IND600

Page 1 P.O. Box 2978, Hendersonville, TN 37077-2978 1-800-888-8018 or 615-537-3600 MODEL IND600 Fax 1-888-812-9956 www.aladdintemprite.com Heat On Demand ULTRA ® HEAT ACTIVATOR & BASE Manual P/N 98862 INSTALLATION OPERATION & SERVICE MANuAL Rev. H 3/03/2009 Heat On Demand u.S. Patent# 5 306 858 and 5 786 643 and 6 005 233 and 6 188 053 ®...
Page 3 IND600 QUICK REFERENCE SHEET “HEATING” unit is heating the Aladdin base Steady during heating “READY” base has completed its activation and is ready for use Flashes at end of the heating cycle “ERROR” check LED error lights and service status for error code...
Page 5: Table Of Contents
IND 600 Heat On Demand uLTRA SYSTEM ® CONTENTS I. INTRODUCTION II. SPECIFICATIONS III. SAFETY IV. REGULATORY COMPLIANCE & INDEPENDENT TESTING V. RECEIVING INSPECTIONS VI. INSTALLATION ELECTRICAL CONNECTION SETTING UP THE EQUIPMENT REQUIRED CLEARANCE PLUGGING THE UNIT IN VII. OPERATION DO'S and DON'TS VIII.
Page 6: Introduction
Aladdin Temp-Rite Heat On Demand ultra base. ® The activator has been specifically created for use ONLY with Aladdin Temp-Rite's Heat On Demand ultra ® bases. There is no exposed coil open flame or heated surface. The only heat applied to the top surface of the base is that which is absorbed from internal component base parts.
Page 7: Safety
III. SAFETY If you know how to correctly install operate clean and service the Heat On Demand ultra System ® your satisfaction with the system will be increased and safety will be enhanced. In accordance with generally accepted product safety labeling guidelines the following three signal words are used throughout this manual to alert you to potential hazards and to tell you how to avoid them.
Page 8: Receiving Inspections
V. RECEIVING INSPECTIONS Your Aladdin IND 600 Heat On Demand ultra Activator is factory tested for performance and is free from defects when shipped. The utmost care has been taken in packaging this product to protect against damage in transit.
Page 9: Installation
This equipment is to be installed only by a qualified electrician. Installation Instructions may be obtained from the Aladdin Temp-Rite Technical Services Department toll free at 1-800-888-5426.
Page 10: Setting Up The Equipment
 SETTING UP THE EQUIPMENT The activator has been completely checked at the Aladdin factory prior to shipment to you. No adjustments of any sort should be required to place the activator into service. The activator should be located in a position convenient to the tray line operator and within 6 feet of the prescribed electrical outlet.
Page 11 225°F (107°C) and should be at least 265°F (129°C). Starting surface temperatures should be a minimum of 75°F (24°C). If this is not the case notify the Aladdin Temp-Rite Service Department at 1-800-888-5426. Temperatures below 225°F (107°C) can impact system performance.
Page 12: Operation
Installation Operation IND600 Heat On Demand uLTRA SYSTEM ® & Service Manual VII. OPERATION No base should be on the activator surface when first powering the unit up. This may cause an “Err” message. A. The activator has a power switch on the front right side of the control panel.
Page 13: Do's And Don'ts
Never attempt to heat any metal objects or bases Power down the activator after each other than Aladdin Heat On Demand ultra bases. meal service has been completed. Never heat an Aladdin Heat On Demand ultra Allow the heating cycle to finish before base that has been heated within the past hour.
Page 14: Operator Maintenance
Installation Operation IND600 Heat On Demand uLTRA SYSTEM ® & Service Manual VIII. OPERATOR MAINTENANCE ! WARNING ! To prevent electrical shock hazard the power button must be in the OFF position before cleaning the Activator. The operator should never open the back panel or fuse access panel of this activator due to possible electrical shock hazard.
Page 15: Troubleshooting
IX. TROUBLE SHOOTING Error Codes: Displayed in the window. Base too hot or base has already been heated Action Check base temperature Heat sink temperature too high Action Check for air flow at back of unit air filter obstruction or heat sink fan for failure Coil overheating Action Check for air flow at coil, check coil fan connections, product may be...
Page 16: Electrician's Troubleshooting Guide
Inserting the base in the alignment guide at an angle can create a situation where the activator thinks it should begin a heating cycle. However the base may not be properly seated on the IND600 surface. Base in pellet guide upon Always remove base from pellet guide upon initial power up power up of appliance.
Page 17 Allow each base to remain in the alignment guide for before cycle ended the entire heating cycle. Base has been heated within use a cool (room temp.) Aladdin Heat On Demand ® “E02” is immediately the past hour and is still hot ultra base.
Page 18: Parts Illustration
Installation Operation IND600 Heat On Demand uLTRA SYSTEM ® & Service Manual X. PARTS ILLUSTRATION FOR PARTS & SERVICE CALL 1 (800) 888-5426...
Page 19: Parts List
All other service work will require that the Activator be returned to the Aladdin factory for service. Should the Activator have to be returned for service to the Aladdin factory contact the Aladdin Temp-Rite Service Department for information regarding the availability of a "loaner".
Page 20: Electrical Schematic
All other service work will require that the Activator be returned to the Aladdin factory for service. Should the Activator have to be returned for service to the Aladdin factory contact the Aladdin Temp-Rite Service Department for information regarding the availability of a "loaner".
Page 21: Base Care And Handling Instructions
XIII. BASE CARE & HANDLING INSTRUCTIONS ! CAUTION ! To prevent damage ultra bases should be activated (HEATED) only by Aladdin IND600 ultra Activator. Do not microwave. Do not place in any type of oven or heat source. Do not stack bases after activating.
Page 22 Installation Operation IND600 Heat On Demand uLTRA SYSTEM ® & Service Manual 1. HIGH DISH MACHINE TEMPERATuRE Dish machine temperatures should not exceed 190°F. Blow dryer temperature should not exceed 200°F. Avoid prolonged ex- posure to heat inside the dish machine.
Page 23: Service
XIV. SERVICE In the event service is required on your Aladdin HEAT-ON-DEMAND uLTRA activator please have ® your model number and serial number present then call: ALADDIN TEMP-RITE SERVICE DEPARTMENT 1-800-888-5426 Model # IND600 Serial # FOR PARTS & SERVICE CALL 1 (800) 888-5426...
Page 24: Warranty And Liability
LIMITED WARRANTY Effective June 2007 Aladdin Temp-Rite (“ATR”) warrants to the original purchaser that the equipment listed below shall be free from defects in material and workmanship under normal use for the applicable warranty term set forth below. ATR’s obligation under this warranty is limited to the repair or replacement at the sole option of ATR of any part which upon inspection and examination by ATR or its authorized agent is found to be defective.
