media-tech MT6350 Instruction Manual

UNIVERSAL NOTEBOOK
BATTERY
Emergency Power Delivery for Most of Mobile Computers
Warnings and cautions
■ Avoid physical impact on the battery.
■ Do not expose it directly under sunlight or operate it
near heat source.
■ Use the battery in dry locations only. Never immerse
the battery in water or any chemical solvents.
■ Do not short-circuit the battery with metal objects.
■ Do not transport, pack or store the battery with
small objects such as paper clippers.
■ Do not disassemble the battery pack.
■ Stop using the battery when it generates unusual
smell, heating, distortion or any other abnormalities.
■ Turn off your computer during MT6350 charging
your internal battery.
Other useful tips
1. During charging or discharge MT6350, it's normal to
feel some heat on the product.
2. Make a full charging and discharging cycle at least
once every two weeks.
Product overview
Instructions manual
1. Rotatable Output Port
2. Input Port
(For charging MT6350 with AC Adapter)
3. USB Output Port
(For USB-Powered Electronics)
4. Check Button
(To check Remaining Battery Power Level)
5. LED Indicators
(Show Charge Level)
6. Tips
(To connect Notebook Computer)
7. AC Adapter
(100V~240V)
8. Connection Cable
Getting started
Before using MT6350 for the fi rst time, fully charge it by
using included AC adapter for at least 5 hours. Connect
the AC adapter until all LED indicators go off .
The built-in lithium ion batteries don't have so-called "memory ef-
fect" problem. This product can be recharge anytime.
LED lights
MT6350 has 4 LED lights to indicate the working status,
charging status, and the remaining power level.
Work with notebook computer
IMPORTANT:
Before connecting to your notebook computer,
check the input voltage of the computer, and set
MT6350 Rotatable Port to matching the voltage.
MT6350
(16.5V, 19.0V, 22.0V)
EN
