- Page 1 Minitar MVA11A VoIP ATA (SIP) Quick Installation Guide ...
-
Page 2: Hardware Installation
Installation & Setup LAN Connection Connect an Ethernet cable from your PC's Ethernet port to the LAN port of the VoIP ATA. WAN Connection Connect an Ethernet cable from the router to the WAN port of the VoIP ATA. VoIP Connection Connect the telephone to PHONE port and your PSTN line to LINE port. - Page 3 Step 3. Connect the PSTN line to the RJ-11 Line port. Step 4. Connect the power adapter to the Router. Connect the power adapter to the port labeled POWER on the rear panel of router. Power Adapter Connection Connect the power adapter to the power inlet. Configuring VoIP ATA with Web Browser Open web browser and type http://192.168.3.1 in the browser's address box.
- Page 4 • Setup Wizard – WAN Settings The Setup Wizard is an easy way to set up the VoIP ATA quickly. In the first step, you can set the LAN mode and WAN IP type. When you are finished changing the settings, click the Next button to move to the next page.
- Page 5 • Setup Wizard – Service Domain Settings In this page, you set up the SIP server settings. You need to input the account details as provided by your VSP or SIP provider. You can register up to three VSP/SIP accounts (Realms). Click the Next button to move to the next page.
- Page 6 1. Insert the CD into your CD-ROM, and the CD will Auto-Run. Package Contents • VOIP ATA unit • AC Power Adaptor • RJ-11/RJ-45 cable • User Guide on CD • Quick Installation Guide MVA11A Quick Installation Guide © 2008 Minitar Corporation...
