SERVICE
TFT-LCD TV
LN32B550K1R/LN40B550K1R
LN46B550K1R/LN52B550K1R
Refer to the service manual in the GSPN (see the rear cover) for the more information.
LCD-TV
Chassis
: G5K32MLA
G5K40MLA
G5K46MLA
G5K52MLA
Model
: LN32B550K1R
LN40B550K1R
LN46B550K1R
LN52B550K1R
Manual
1. Precautions
5. Exploded View & Part List

Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LN32B550K1R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung LN32B550K1R

Summary of Contents for Samsung LN32B550K1R

  • Page 1 LCD-TV Chassis : G5K32MLA G5K40MLA G5K46MLA G5K52MLA Model : LN32B550K1R LN40B550K1R LN46B550K1R LN52B550K1R SERVICE Manual TFT-LCD TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Exploded View & Part List 6. Wiring Diagram LN32B550K1R/LN40B550K1R LN46B550K1R/LN52B550K1R Refer to the service manual in the GSPN (see the rear cover) for the more information.

  • Page 2: Table Of Contents

    4-3. Factory Mode Adjustments ................... 4-19 4-4. White Balance - Calibration ..................4-29 4-5. Servicing Information ....................4-31 5. Exploded View & Part List ..................5-1 5-1. LN32B550K1R Exploded View ..................5-1 5-2. LN40B550K1R Exploded View ..................5-3 5-3. LN46B550K1R Exploded View ..................5-5 5-4. LN52B550K1R Exploded View ..................5-7 5-5.
  • Page 3 GSPN (Global Service Partner Network) Area Web Site North America http://service.samsungportal.com Latin America http://latin.samsungportal.com http://cis.samsungportal.com Europe http://europe.samsungportal.com China http://china.samsungportal.com Asia http://asia.samsungportal.com Mideast & Africa http://mea.samsungportal.com © 2009 Samsung Electronics Co.,Ltd. This Service Manual is a property of Samsung Electronics Co.,Ltd. All rights reserved. Any unauthorized use of Manual can be punished under applicable Printed in Korea International and/or domestic law. P/N: BN82-00582A-00...

  • Page 4: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing, and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify any circuitry. 1-1-2. Servicing the LCD TV When servicing the LCD TV, Disconnect the AC line cord from the AC outlet.

  • Page 5: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 6: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than two people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.
  • Page 7 1. Precautions Memo...

  • Page 8: Product Specifications

    2. Product specifications 2. Product specifications 2-1. Feature & Specifications Model LN32B550K1R Feature Analog-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0, D-SUB � Brightness : 500cd/m � Contrast Ratio : 5000:1 � Response time : 8ms � Super-PVA � PIP(in HDMI 1, 2, 3, 4, Component 1, 2, PC Mode and Sub picture is available only in TV mode) �...
  • Page 9 2. Product specifications Model LN40B550K1R Feature Analog-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0, D-SUB � Brightness : 500cd/m � Contrast Ratio : 5000:1 � Response time : 8ms � Super-PVA � PIP(in HDMI 1, 2, 3, 4, Component 1, 2, PC Mode and Sub picture is available only in TV mode) �...
  • Page 10 2. Product specifications Model LN46B550K1R Feature Analog-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0, D-SUB � Brightness : 500cd/m � Contrast Ratio : 5000:1 � Response time : 8ms � Super-PVA � PIP(in HDMI 1, 2, 3, 4, Component 1, 2, PC Mode and Sub picture is available only in TV mode) �...
  • Page 11 2. Product specifications Model LN52B550K1R Feature Analog-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0, D-SUB � Brightness : 500cd/m � Contrast Ratio : 5000:1 � Response time : 8ms � Dynamic contrast, Super-PVA � PIP(in HDMI 1, 2, 3, 4, Component 1, 2, PC Mode and Sub picture is available only in TV mode) �...
  • Page 12 2. Product specifications CHANNEL FREQUENCY TABLE OUTPUT FREQUENCY : ANALOG fv:45.75MHz, fs:41.25MHz DIGITAL Fc:44MHz TUNING STEP SIZE : FIRST PLL 250KHz SECOND PLL 62.5KHz OSD CH NO CH NO CH NO CH NO Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC 72.
  • Page 13 2. Product specifications OSD CH NO CH NO CH NO CH NO Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC 499.25 ULTRA 498.00 499.25 505.25 ULTRA 504.00 505.25 511.25 ULTRA 510.00 511.25 517.25 ULTRA 516.00 517.25 523.25 ULTRA 522.00 523.25 529.25...

  • Page 14: Media Play

    Compatibility problem. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data.SAMSUNG is not responsible for any data file damage or data loss. Do not disconnect the USB device while it is loading.
  • Page 15 2. Product specifications -. movie format File Extention Container Video Decoder Resolution Audio codec Xvid 800 x 600 ADPCM H.264 MP 1920 x 1088 * .avi MPEG4 SP 800 x 600 ADPCM MJPEG 800 x 600 H.264 BP 1920 x 1088 * .mp4 H.264 MP 1920 x 1088...

  • Page 16: Specification Comparison To Old Models

    2. Product specifications 2-3. Specification Comparison to Old Models Model LB5K CORAL Design Display Type LCD TV LCD TV Built-in Tuner Resolution 1920 x 1080 1366 x 768 LCD Panel 40”TFT LCD Panel 60Hz 40”TFT LCD Panel 50Hz Screen Size 40”...

  • Page 17: Accessories

    Remote Control & Batteries BN59-00887A (AAA x 2) Power Cord 3903-000193 Cover-Bottom BN63-05466B Owner’s Instructions BN68-01929A Samsung Electronics Service center Cleaning Cloth BN63-01798B Warranty Card / Registration AA68-03242M Card / Safety Guide Manual BH68-00527B (Not available in all locations) Stand Screw x 4...

  • Page 18: Disassembly And Reassembly

    3. Disassembly and Reassembly 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LN40B550K1R LCD TV. WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components. 3-1. Disassembly and Reassembly Cautions: 1.
  • Page 19 3. Disassembly and Reassembly Description Picture Description Screws 2. Remove the screws of rear-cover. 3. Lift up and remove the rear-cover. * Rear view of 32” / 40” * Rear view of 46” / 52”...
  • Page 20 3. Disassembly and Reassembly Description Picture Description Screws 4. Remove the screws of main board. 4-1. Remove the screws of IP board. Remove the IP board. (32” / 40”) 4-2. Remove the screws of IP board. Remove the IP board. (46” / 52”)
  • Page 21 3. Disassembly and Reassembly Description Picture Description Screws 5. Remove the speakers. (R/L) 6. Remove the screws of Stand BKLT. Lift up the Stand BKLT. 7. Remove the screw of panel top.
  • Page 22 3. Disassembly and Reassembly Description Picture Description Screws 7-1. Remove the screw of wall bracket. (46” / 52” only) 8-1. Front 8-2. Panel Reassembly procedures are in the reverse order of disassembly procedures. ※...

  • Page 23: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting Check the various cable connections first. • Check to see if there is a burnt or damaged cable. • Check to see if there is a disconnected or loose cable connection. • Check to see if the cables are connected according to the connection diagram. Check the power input to the Main Board.
  • Page 24 4. Troubleshooting Simple flow chart of malfunction  Does the TV turn on? Can you see anything on the screen? Can you see OSD menu running on the screen? Can you see Digital Channel broadcast ? Check LVDS cable connected Check the Power Cord to Main Board.
  • Page 25 The WLAN does not work. An explanation of Equipment other than the WLAN USB stick supplied by Samsung Electronics (as a bundle) will not work. MEDIA PLAY The sharer must support IEEE 801.11 g/b. IEEE 801.11 n is not supported.
  • Page 26 4. Troubleshooting I cannot find Internet Sharer in the Wlan An explanation of Only InfraStructure mode of the sharer is supported. Ad- settings menu. MEDIA PLAY Hoc mode is not supported. If multiple sharers are being used, configure them so that they do not use the same channel.
  • Page 27 4. Troubleshooting 4-1-1. No Power The LEDs on the front panel do not work when connecting the power cord. Symptom The IP BOARD relay does not work when connecting the power cord. The units appears to be dead. The IP relay or the LEDs on the front panel does not work when connecting the power cord if the cables are improperly connected or the Main Board or IP BOARD is not functioning.
  • Page 28 4. Troubleshooting 4-1-2. No Video (Analog PC signal) Symptom Audio is normal but no picture is displayed on the screen. Check the PC source Major Check the SEMS03. checkpoints This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. Check a set in the Power indicator LED is off.
  • Page 29 4. Troubleshooting WAVEFORMS R,G,B Output Signal...
  • Page 30 4. Troubleshooting 4-1-3. No Video (HDMI 1, 2, 3, 4 - Digital Signal) Symptom Audio is normal but no picture is displayed on the screen. Check the HDMI source. Major Check the HDMI switch, Check the SEMS03. checkpoints This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. Power Indicator is off.
  • Page 31 4. Troubleshooting WAVEFORMS Digital Output Data Signal of HDMI(Data)
  • Page 32 4. Troubleshooting 4-1-4. No Video (Tuner_CVBS) Symptom Audio is normal but no picture is displayed on the screen. Check the Tuner CVBS source. Major Check the Tuner, Check the SEMS03. checkpoints This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. Power indicator LED is off.
  • Page 33 4. Troubleshooting WAVEFORMS CVBS Output Signal Tuner_CVBS Output Signal 4-11...
  • Page 34 4. Troubleshooting 4-1-5. No Video (Video CVBS 1, 2) Symptom Audio is normal but no picture is displayed on the screen. Check the Video CVBS source Major Check the SEMS03. checkpoints This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. Power indicator LED is off.
  • Page 35 4. Troubleshooting WAVEFORMS CVBS Output Signal 4-13...
  • Page 36 4. Troubleshooting 4-1-6. No Video (Component 1, 2) Symptom Audio is normal but no picture is displayed on the screen. Check the Component source Major Check the SEMS03. checkpoints This may happen when the LVDS cable connecting the Main Board and the Panel is disconnected. Power indicator LED is off.
  • Page 37 4. Troubleshooting WAVEFORMS Digital Output Data Analog Signal(Y,C) 4-15...
  • Page 38 4. Troubleshooting 4-1-7. No Sound Symptom Video is normal but there is no sound.. When the speaker connectors are disconnected or damaged. Major When the sound processing part of the Main Board is not functioning. checkpoints Speaker defect.. Check the source and Input the sound source properly.
  • Page 39 4. Troubleshooting WAVEFORMS The Signal are Inputed to IC1201 The Signal are Inputed to IC1202 4-17...

  • Page 40: Alignments And Adjustments

    4. Troubleshooting 4-2. Alignments and Adjustments 4-2-1. General Alignment Instuction Usually, a color LCD-TV needs only slight touch-up adjustment upon installation. Check the basic characteristics such as height, horizontal and vertical sync. Use the specified test equipment or its equivalent. Correct impedance matching is essential.

  • Page 41: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1 Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : - If you do not have Factory remote - control INFO MENU MUTE Power on - If you have Factory remote - control PICTURE ON DISPLAY FACTORY...

  • Page 42: Factory Data

    PB350, PB430, PB450, PB550, PB550_FBE, L_ BASIC, LB350, LB360, LB360_22, LB450, LB450_22, LB460, LB480, LB480_22, LB530, LB550, B550_FBE, LB622, LB550_FBE_NM Tuner Select SEMCO SEMCO, XUGUANG Samsung Samsung Ch Table SUWON SUWON, SESK, SHE, TTSEC, SEIN, SDMA, TSED, SAVINA, SIEL, TSE Local Set...
  • Page 43 4. Troubleshooting ADC Result 1st_AV_Gain 0 ~ 255 1st_AV_Offset 0 ~ 255 1st_Comp_Gain 0 ~ 255 1st_Comp_Gain_Cb 0 ~ 255 1st_Comp_Gain_Cr 0 ~ 255 1st_Comp_Offset 0 ~ 255 1st_Comp_Offset_Cb 0 ~ 255 1st_Comp_Offset_Cr 0 ~ 255 1st_PC_R_Gain 0 ~ 255 1st_PC_G_Gain 0 ~ 255 1st_PC_B_Gain...
  • Page 44 4. Troubleshooting Control  EDID EDID Protect On/Off EDID Type L13_1920_1080 P12_1024_768, P13_1024_768, P12_1366_768, P13_1366_768, P12_1920_1080, P13_1920_1080, L12_1366_768, L13_1366_768, L12_1920_1080, L13_1920_1080 EDID Write(0x4D,0) L13_1920_1080 P12_1024_768, P13_1024_768, SUCCESS P12_1366_768, P13_1366_768, P12_1920_1080, P13_1920_1080, L12_1366_768, L13_1366_768, L12_1920_1080, L13_1920_1080 Video Mute Time 0~99 Sub Option Inch 32”...
  • Page 45 4. Troubleshooting Hotel Option  Hotel Option Hotel Mode On/Off Shop Option  Shop Option Shop Mode On/Off Sound  Detection Threshold OPTION RANGE SOUND Pilot Threshold M2S Thr High 0~255 M2S Thr Low 0~255 S2M Thr High 0~255 S2M Thr Low 0~255 Carrier1 Threshold Amp On Thr High 0~255...
  • Page 46 4. Troubleshooting MST69A84HQ  VDEC SYNC_LVL 0~255 HPLL_MD HPLL_SPD1 0~63 HPLL_SPD2 0~255 CBCRLP_MD YC_DLY IFCOMP 0~63 SAT_ADJ 0~255 YSEPFLT NOISE_LVL 0~255 Film Det Speed NT 0~255 IPC/MJC Film Det Speed PAL 0~255 Motion Hist Motion History Red Sat 0~30 Color Space Red Hue 0~127 Green Sat...
  • Page 47 4. Troubleshooting  Pattern Select 0~25 B-Slope Gain 0~255 B-Tilt Min 0~255 B-Tilt Max 0~255 LFuc-Basis 0~255 HFuc-Basis 0~255 Mean-Offset1 0~255 Mean-Offset2 0~255 Mean-Slope 0~255 ACR Offset 0~127 ACR Th1 0~255 ACR Th2 0~255 Skin Enable 0~255 Skin Uv 0~255 Mskin Uv 0~255 Sub Color...
  • Page 48 4. Troubleshooting EPA Standard  Std Contr 0~100 EPA Standard Std Bright 0~100 Std Sharp 0~100 Std Color 0~100 Std Tint 0~100 Std Backlight 0~10 Adjsut  Dynamic Dimming On/Off Adjsut Dynamic CE Dynamic CE On/Off B Slope On/Off LNA Plus RF Db 0 Level 0~255 RF Db 1 Level...
  • Page 49 4. Troubleshooting YC_Delay  PAL BG YC Delay PAL DK PAL I SECAM BG SECAM DK SECAM L NTSC 358 NTSC 443 AV PAL AV SECAM AV NT358 AV NT443 AV PAL60 Sharpness  Sharpness H1 Gain 0~63 H2 Gain 0~63 H3Gain 0~63...
  • Page 50 4. Troubleshooting  Skin X 0~11 Skin Y 0~11 B Slope 0~255 DLC ML 0~255 DLC_MH 0~255 DLC_H 0~255 Skin_SAT 0~15 Skin_Hue 0~127 M_Skin_Hue M_Skin_X 0~11 M_Skin_Y 0~11 Mid_color_level 0~255 M_Mid_color_level 0~255 EEPROM Reset  EEPROM Reset EEPROM Reset NVR All Clear On/Off Defect Log ...

  • Page 51: White Balance - Calibration

    4. Troubleshooting 4-4. White Balance - Calibration 4-4-1 White Balance -Calibration 1. ADC AV Calibration Comp Calibration PC Calibration HDMI Calibration 4-4-2 Service Adjustment - You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration ...
  • Page 52 4. Troubleshooting Method of Color Calibration (AV)  1) Apply the PAL Lattice (NO. 2) pattern signal to the AV IN 1 port 2) Press the Source key to switch to “AV1” mode 3) Enter Service mode 4) Select the “ADC” menu 5) Select the “AV Calibration”...

  • Page 53: Servicing Information

    4-5. Servicing Information 4-5-1 USB Download Method Samsung may offer upgrades for TV’s firmware in the future. Please contact the Samsung call center at 1-800- SAMSUNG (726-7864) to receive information about downloading upgrades and using a USB drive. Upgrades will be possible by connecting a USB drive to the USB port located on your TV.

  • Page 54: Exploded View & Part List

    5. Exploded View & Part List 5. Exploded View & Part List 5-1. LN40B550K1R Exploded View...

  • Page 55: Ln40B550K1R Parts List

    5. Exploded View & Part List 5-1-1. LN40B550K1R Parts List Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark T0003 BN96-09668G ASSY COVER P-FRONT;LB550 40,SO,PMMA(CLR) S.N.A M0215 BN07-00675D LCD-PANEL;LTF400HA08 M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 S.N.A M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 S.N.A M0115 BN61-04918A BRACKET-STAND LINK;40, B610,SECC,T1.6...
  • Page 56 S.N.A M0045 BN96-10275W ASSY ACCESSORY-MANUAL;LN32B550K1RXZB ...3 M0156 BN68-01965D MANUAL USERS-01;B550,SAMSUNG,ENG/SPA,ARG S.N.A ...3 T0524 6902-000009 BAG PE;HDPE,T0.03,W240,L400,TRP,8,2,-,5. S.N.A ...3 BN68-01402E MANUAL FLYER-STAND GUIDE;32",SAMSUNG,Eng S.N.A M0045 BN96-10275Y ASSY ACCESSORY-CABLE;LN40B550K1RXZB ...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC S.N.A ...3 T0531 BN63-05468B COVER-BOTTOM;37,40B550,HIPS,HB,BK500 ...3 BN81-02301A A/S-LABEL-E PASS;SEDA,ART PAPER,W42,L12, S.N.A...
  • Page 57 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...3 BN98-01769A ASSY K/D-REMOCON ,BN59-00868A;PL42B450 / S.N.A ..4 M0014 BN94-02736A ASSY PCB MAIN-REMOCON;PL42B450 S.N.A ..5 AA83-00262A CKD-ELE-CAPACITOR;SHL 16V 47uF 5.0## S.N.A ..5 BN83-01257A CKD-IR-LED;SI-5312H S.N.A ..5...
  • Page 58 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..5 QP802S BN81-00953A A/S-SCREW-MACHINE;6006-000261,-,-,-,-,-, S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 DP804 BN81-01336A A/S-DIODE-RECTIFIER;0402-001766,-,-,-,-, S.N.A...
  • Page 59 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..6 J812 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 J825 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 J826 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 FOR FM802S BN81-00947A A/S-FUSE-CLIP;3602-000158,-,-,-,-,-,- S.N.A...
  • Page 60 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..7 DP807 BN81-00750A A/S-DIODE-ARRAY;0407-001009,-,-,-,-,-,- S.N.A ..7 ZP801 BN81-01112A A/S-DIODE-ZENER;0403-001500 S.N.A ..7 UP801S BN81-01119A A/S-IC-PWM CONTROLLER;1203-004854 S.N.A ..7 RP804 BN81-01125A A/S-R-CHIP;2007-000052 S.N.A ..7 RP806 BN81-01125A A/S-R-CHIP;2007-000052 S.N.A...
  • Page 61 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..5 UM801S BN81-00953A A/S-SCREW-MACHINE;6006-000261,-,-,-,-,-, S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5 BN81-01002A A/S-CAPACITOR-AL;ML61-00150C,-,-,-,-,-,- S.N.A ..5...
  • Page 62 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..6 J823 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 J824 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 J827 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A ..6 J829 BN81-00709A A/S-WIRE-NO SHEATH CU;3812-001283,-,-,-, S.N.A...
  • Page 63 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..6 BN97-03502A ASSY SMD-SUB;BN44-00264A S.N.A ..7 DI803 BN81-00608A A/S-DIODE-ARRAY;0407-000122,-,-,-,-,-,- S.N.A ..7 DI804 BN81-00608A A/S-DIODE-ARRAY;0407-000122,-,-,-,-,-,- S.N.A ..7 DI805 BN81-00608A A/S-DIODE-ARRAY;0407-000122,-,-,-,-,-,- S.N.A ..7 DI806 BN81-00608A A/S-DIODE-ARRAY;0407-000122,-,-,-,-,-,- S.N.A ..7...
  • Page 64 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..7 QM803 BN81-00752A A/S-TR-SMALL SIGNAL;0501-000734,-,-,-,-, S.N.A ..7 QI801 BN81-00754A A/S-FET-SILICON;0505-001427,-,-,-,-,-,- S.N.A ..7 QI804 BN81-00754A A/S-FET-SILICON;0505-001427,-,-,-,-,-,- S.N.A ..7 QI808 BN81-00754A A/S-FET-SILICON;0505-001427,-,-,-,-,-,- S.N.A ..7 RI859 BN81-00793A A/S-R-CHIP;2007-000307,-,-,-,-,-,- S.N.A...
  • Page 65 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..7 CI835 BN81-01190A A/S-C-CER,CHIP;2203-005249 S.N.A ..7 CI880 BN81-01190A A/S-C-CER,CHIP;2203-005249 S.N.A ..7 CM803 BN81-01190A A/S-C-CER,CHIP;2203-005249 S.N.A ..7 CI809 BN81-01226A A/S-CAPACITOR-MLCC;ML59-00014X S.N.A ..7 CI805 BN81-01230A A/S-CAPACITOR;ML59-00017M S.N.A ..7...
  • Page 66 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..7 RB851 BN81-01590A A/S-R-CHIP;2007-000118,-,-,-,-,-,- S.N.A ..7 RM852 BN81-01590A A/S-R-CHIP;2007-000118,-,-,-,-,-,- S.N.A ..7 RI835 BN81-01591A A/S-R-CHIP;2007-000336,-,-,-,-,-,- S.N.A ..7 RI837 BN81-01592A A/S-R-CHIP;2007-000467,-,-,-,-,-,- S.N.A ..7 RI838 BN81-01592A A/S-R-CHIP;2007-000467,-,-,-,-,-,- S.N.A ..7...
  • Page 67 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..7 RB814 BN81-03155A A/S-R-CHIP;2007-001199 S.N.A ..7 RI873 BN83-00102A CKD-R-CHIP;2007-000934,GH17ASPS/XAZ,SEDA S.N.A ..7 RI874 BN83-00102A CKD-R-CHIP;2007-000934,GH17ASPS/XAZ,SEDA S.N.A ..7 RI878 BN83-00102A CKD-R-CHIP;2007-000934,GH17ASPS/XAZ,SEDA S.N.A ..7 RI879 BN83-00102A CKD-R-CHIP;2007-000934,GH17ASPS/XAZ,SEDA S.N.A ..7...
  • Page 68 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.07 S.N.A ..4 BN61-05115D HOLDER-BOSS SIDE;40,LB550,PMMA+ABS,HB,BK S.N.A ...3 BN98-01954A ASSY K/D-ASSY BOARD P-TOUCH FU;BN96-1021 S.N.A ..4 M0014 BN94-02891A ASSY PCB MAIN;BN96-10210F S.N.A ..5 D0254...
  • Page 69 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...3 JA4005_PC 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN ...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG ...3 CN1001 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG ...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN S.N.A ...3 JA330...
  • Page 70 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 D5006 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4 D5008 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4 D5009 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4 D5011 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4 D5013 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4...
  • Page 71 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-001165 FET-SILICON;SI3443BDV,P,-20V,+-4.4A,65mo ..4 IC106 1001-001567 IC-VIDEO SWITCH;TMDS361,TQFP,64P,9x9mm,3 ..4 IC7003...
  • Page 72 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 VT5013 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 VT5014 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 R4063_DE 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012 ..4 R1031 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 S.N.A ..4 R1032 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 S.N.A ..4 R7016 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608...
  • Page 73 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R6080 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 S.N.A ..4 R6081 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 S.N.A ..4 R6082 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 S.N.A ..4 R6083 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 S.N.A ..4 R6084 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 74 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R2018_OP 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3023 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3024_550 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3056 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3058_S 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 75 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R3040_550 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3041 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3042_550 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3049 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R3050_550 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 76 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R6218 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R6219 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R7015 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R7032_550 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4 R7039 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 77 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R6086 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R6088 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R6090 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R6091 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R6093 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 78 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R8152_NFBE 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R8153_NFBE 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R8154_NFBE 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R8155_NFBE 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4 R8156_NFBE 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 79 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R3070_S 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R4001 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R4005 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R7001 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R7002 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 80 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R6001 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 S.N.A ..4 R6002 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 S.N.A ..4 R6054 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 S.N.A ..4 R6055 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 S.N.A ..4 R6222 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 81 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R2043 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 S.N.A ..4 R2045 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 S.N.A ..4 R6130 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 S.N.A ..4 R6131 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 S.N.A ..4 R2021 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 82 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C4016 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C6006 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C6011 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C6014 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C6057 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C7046 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ..4 C1024...
  • Page 83 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C2056 2203-002687 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1005 ..4 C1018 2203-002793 C-CER,CHIP;1000nF,+80-20%,25V,Y5V,2012 S.N.A ..4 C1047 2203-002793 C-CER,CHIP;1000nF,+80-20%,25V,Y5V,2012 S.N.A ..4 C9101 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10 ..4 C9102 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10 ..4 C9103 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10...
  • Page 84 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C6034 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 S.N.A ..4 C6035 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 S.N.A ..4 C6036 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 S.N.A ..4 C6041 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 S.N.A ..4 C6053 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 S.N.A ..4...
  • Page 85 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C7044 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C7045 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C7059 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C7060 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C7063 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4...
  • Page 86 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C2018_OP 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 S.N.A ..4 C2061 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 S.N.A ..4 C2062 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 S.N.A ..4 C2063 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 S.N.A ..4 C4026 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 S.N.A ..4...
  • Page 87 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C7022 2203-006681 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005 S.N.A ..4 C7023 2203-006681 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005 S.N.A ..4 C7024 2203-006681 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005 S.N.A ..4 C7026 2203-006681 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005 S.N.A ..4 C7027 2203-006681 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005 S.N.A ..4...
  • Page 88 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 L2001 2704-000018 INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh S.N.A ..4 L2002 2704-000018 INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh S.N.A ..4 X202 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh ..4 T0568 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- S.N.A ..4 T0568 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- S.N.A ..4 T0568...

  • Page 89: Wiring Diagram

    6. Wiring Diagram 6. Wiring Diagram 6-1. Wiring Diagram 32” /40”...

  • Page 90: Wiring Diagram 46"/52"

    6. Wiring Diagram 6-2. Wiring Diagram 46”/52”...
  • Page 91 6. Wiring Diagram CN8002 (to Panel) JA3001 (HDMI1) JA4001 (PC sound) RE[0]- HDMI1_RX2+ 12 T_Micom_Reset PC_SR_IN PVCC_SW RO[4]+ HDMI1_RX2- PC_SL_IN SDA (FRC Control) RO[4]- HDMI1_RX1+ 15 PC_SL_IN FRC Reset RO[3]+ PC_SL_IN SCL (FRC Control) RO[3]- HDMI1_RX1- PC_SR_IN LVDS opt HDMI1_RX0+ 18 PC_SR_IN H-Sync Out ROCLK+...
  • Page 92 6. Wiring Diagram JA3003_S (HDMI4) JA4005_PC (PC) CN4007 (to Function IR) HDMI4_RX2+ 12 PC_RED KEY_2 PC_GREEN KEY_SDA (NC) HDMI4_RX2- PC_BLUE A3.3V HDMI4_RX1+ 15 LED_INDICATOR KEY_SCL(NC) BUZZER LED_DECO(NC) HDMI4_RX1- KEY_1 A5V(NC) HDMI4_RX0+ 18 HDMI4_RX0- PC_5V HDMI4_RXCLK+ PC_IDENT EMU_SDA PC_H_SYNC PC_V_SYNC EMU_SCL...

  • Page 93: Connector Functions

    6. Wiring Diagram 6-5. Connector Functions Connector Functions CN1001 <-> CN801 Supply main power and dimming signal from IP board to Main Board. CN8002 <-> CN505 The LVDS signal transfered from Main Board to Panel . CN1806 <-> Panel CN3 Feedback signal from driver.
