GRUNDFOS INSTRUCTIONS
Grundfos GO Remote
Grundfos MI 202, MI 204 and MI 301
Installation and operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MI 202 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grundfos MI 202

  • Page 1 GRUNDFOS INSTRUCTIONS Grundfos GO Remote Grundfos MI 202, MI 204 and MI 301 Installation and operating instructions...
  • Page 2: Table Of Contents

    Symbols used in this document Radio frequency 2.1 EU 2.2 USA and Canada Definitions and abbreviations Product introduction 4.1 MI 202 and MI 204 4.2 MI 301 4.3 Supported devices 4.4 Supported Grundfos products Connecting to a Grundfos product 5.1 Radio - List 5.2 Radio - Connect...
  • Page 3: Symbols Used In This Document

    Warning Prior to installation, read these installation and operating instructions. Installation and operation must comply with local regulations and accepted codes of good practice. 1. Symbols used in this document Warning If these safety instructions are not observed, it may result in personal injury.
  • Page 4: Usa And Canada

    2.1 EU Grundfos MI 202 and MI 204 - class 1 device The radio part of this device is a class 1 device and can be used anywhere in the EU member states without restrictions. Intended use This product is intended for remote control of Grundfos products.
  • Page 5 This device complies with part 15 of the FCC rules. Users are cautioned that changes or modifications not expressly approved by Grundfos could void the user's authority to operate the equipment. Class B product This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 6 2.2.2 Canada This product contains IC ID: IC ID: 10447A-MI202M01 10447A-MI204M01 10447A-MI301M01 Complies with the Canadian ICES-003 Class B specifications. "Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada." This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations.
  • Page 7: Definitions And Abbreviations

    3. Definitions and abbreviations Description Infrared Specific absorption rate Bluetooth Radio Radio communication...
  • Page 8: Product Introduction

    The Grundfos GO app can be used to establish wireless connection to Grundfos products. It is available from Apple App Store and Google Play. The Grundfos GO app must be used in conjunction with one of these MI (mobile interface) devices: •...
  • Page 9: Mi 202 And Mi 204

    The MI 202 and MI 204 are add-on modules for Apple devices. For Apple iPod touch 4 and iPhone 4 and 4S, use the MI 202. For Apple products with Lightning connector, e.g. iPhone 5 and iPhone 6, use the MI 204.
  • Page 10: Mi 301

    Please note that the use of this accessory with iPod may affect wireless performance. Scope of delivery • Grundfos MI 301 • battery charger (optional) • quick guide.
  • Page 11 2. Switch on the MI 301 by pressing its power button. The indicator light will flash every five seconds, indicating that the MI 301 is charged and ready. 3. Start the Grundfos GO app on the smart device. Press [List] or [Connect]. Bluetooth will be enabled automatically on the smart device, and it will ask if you want to pair with the MI 301.
  • Page 12 3. Turn on Bluetooth in the Apple device. Find the MI 301 in the list of available devices and pair the devices. 4. Start the Grundfos GO app on the smart device. It will show "Mobile interface connected" at the bottom of the display.
  • Page 13: Supported Devices

    Galaxy S III ● Galaxy tab 2 7.0 ● Xperia Arc ● Xperia Arc S ● Sony Xperia Tipo ● Xperia V ● Note: Similar Android and iOS-based devices may work as well, but have not been tested by Grundfos.
  • Page 14: Supported Grundfos Products

    ● ●* TPE single-stage pump ● ●* NBE, NKE single-stage pumps ● ●* MP 204 motor protector ● Grundfos Hydro Multi-E booster system ● ●* Grundfos AUTO sewage system ● ●** ADAPT IO 351 module ● CU 3 motor protector ●...
  • Page 15: Connecting To A Grundfos Product

    5. Connecting to a Grundfos product The function "Connect" under "Remote" in the menu allows you to connect to a Grundfos product. Connecting to a Grundfos product Fig. 3 Action Pos. More information Check that your mobile interface has been 7.
  • Page 16: Radio - List

    5.1 Radio - List "Radio - Connect" and "Radio - List" are methods for radio communication between the Grundfos GO and a Grundfos product. See also section Connect. Check section to see 5.2 Radio - 4.4 Supported Grundfos products if your Grundfos product is supported.
  • Page 17 Step Description Display All products within radio range are listed. It may take some time to scan for all products. The list shows the product name, pump status, signal strength and whether the product is locked or unlocked. Use the wink command to identify the product you have selected.
  • Page 18 Step Description Display Press the product name to connect to the product. If the product is locked, press [OK] or a dedicated connection button on the product. Connection has been established, and the Grundfos GO shows the product dashboard.
  • Page 19 Step Description Display Press [Disconnect] to leave the product and connect to another one.
  • Page 20: Radio - Connect

    5.2 Radio - Connect "Radio - Connect" and "Radio - List" are methods for radio communication between the Grundfos GO and a Grundfos product. See also section List. Check section to see if 5.1 Radio - 4.4 Supported Grundfos products your Grundfos product supports radio communication.
  • Page 21 Step Description Display Connection has been established, and the Grundfos GO shows the product dashboard. Press [Disconnect] to leave the product and connect to another one.
  • Page 22: Ir - Connect

    5.3 IR - Connect "IR - Connect" is a method of infra-red communication with the Grundfos product. Step Description Display When using the Grundfos GO with the MI 202 or MI 204, turn the MI device 180 degrees and point the dongle at the product.
  • Page 23 Hold the MI device steady until all data have been read. An indicator light on the product flashes when the product is communicating via IR. Connection has been established, and the Grundfos GO shows the product dashboard. See section 5.4 Signalling communication with remote control.
  • Page 24: Signalling Communication With Remote Control

    5.4 Signalling communication with remote control The centre indicator light in the Grundfos Eye will indicate communication with the Grundfos GO. See fig. 4, pos. 1. Grundfos Eye Fig. 4 The table below describes the desired function of the centre indicator light.
  • Page 25: Creating A Pdf Report

    5.5 Creating a PDF report You can create a full PDF report of the product status at a given time and send it by email. Step Description Display On an Apple device: At the bottom of the product dashboard, press [Reports]. On an Android device: When in the product dashboard, press the menu button of your device and select "New...
  • Page 26 Apple AirPrint. To send a report by email, an email account must be connected to the device. The report is automatically saved in Grundfos GO. It can be accessed from the Grundfos GO main menu: Under "Remote", select "Browse reports".
  • Page 27: Help

    5.6 Help Help texts are available for some icons and buttons. Press this icon at the bottom of the display. When you press this icon, all objects with further help are highlighted and have a question mark. When you press a question mark, the description will be displayed.
  • Page 28: Maintenance

    MI 202 and MI 204 These products are powered by the Apple device. By using a micro USB connector, it is possible to charge the Apple device through the MI 202/204. MI 301 This product has a rechargeable battery. If the battery needs charging, the indicator light on the MI 301 will flash every second.
  • Page 29: Software Installation And Update

    6.3 Software installation and update If you have installed Grundfos GO on a smart device, you will be notified when software updates are available through either Apple App Store or Google Play. Apple App Store The Grundfos GO app for Apple iOS devices can be downloaded or updated from the Apple App Store, free of charge.
  • Page 30: Fault Finding

    Press and hold any icon in the bar until a red minus appears on the icons. The app needs to be restarted. Press the red minus on the Grundfos GO app icon to close the app. Start the app again by means of its icon.
  • Page 31: Communication

    Communicate at the correct angle of ± 12 °. Fully charge the MI 301. Low battery level Low battery in MI 301 dongle. affects Bluetooth connection. Remove and insert the MI 202/204 into the iPod/iPhone. Bad connection to IR dongle. MI 301: Make sure that Bluetooth is turned on, and the MI 301 is paired with the smart device.
  • Page 32: Mi 202 And Mi 204

    Charge the battery for two to four hours. The Apple device is faulty. Contact Apple's customer service. When started, the Grundfos GO app shows "Mobile interface disconnected". Remove and insert the MI 202/204 in the The MI 202/204 is not Apple device.
  • Page 33: Mi 301

    7.4 MI 301 The connection between the smart device and the MI 301 is lost. The display shows "Mobile interface disconnected". Move the smart device closer to the MI 301. Outside Bluetooth range. If this does not solve the problem, it may be necessary to pair the devices again in menu "GO settings".
  • Page 34: Technical Data

    -10 °C - +50 °C Operating temperature -4 °F - +122 °F -20 °C - +70 °C Storage temperature -4 °F - +158 °F Grundfos MI 202/204 Voltage supply Via Apple smart device Current consumption Max. 30 mA Enclosure class...
  • Page 35: Disposal

    This product or parts of it must be disposed of in an environmentally sound way: 1. Use the public or private waste collection service. 2. If this is not possible, contact the nearest Grundfos company or service workshop. The waste battery should be disposed of through the national collective schemes.
  • Page 36: Declaration Of Conformity

    Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário. MI 202 / MI 204 MI 301 1503-14-7763 1505-14-7763...
  • Page 37 Argentina China Bombas GRUNDFOS de GRUNDFOS Pumps HILGE GmbH & Co. KG Argentina S.A. (Shanghai) Co. Ltd. Tel.: +49 6135 75-0 Phone: +54-3327 414 444 Phone: +86-021-612 252 22 Telefax: +49 6135 1737 Telefax: +54-3327 411 111 Telefax: +86-021-612 253 e-mail: hilge@hilge.de...
  • Page 38 Phone: +971-4- 8815 166 Telefax: +31-88-478 6332 s Telefax: +386 (0) 1 5680 Telefax: +971-4-8815 136 New Zealand United Kingdom GRUNDFOS Pumps NZ Ltd. South Africa GRUNDFOS Pumps Ltd. Phone: +64-9-415 3240 GRUNDFOS (PTY) LTD Phone: +44-1525-850000 Telefax: +64-9-415 3250...
  • Page 39 Uzbekistan Grundfos Tashkent, Uzbekistan The Representative Office of Grundfos Kazakhstan in Uzbekistan Телефон: (+998) 71 150 3290 / 71 150 3291 Факс: (+998) 71 150 3292 Addresses revised 21.05.2014...
  • Page 40 98133717 0115 ECM: 1149262 www.grundfos.com www.grundfos.com...
