ASME COMMERCIAL ELECTRIC WATER HEATER
A Spanish language version of these instructions is available by
contacting the company listed on the rating plate.
La versión espãnola de estas instructiones se puede obtener al
escribible a la fábrica cuyo nombre aparece en la placa de
especificaciones.
INSTALLATION & OPERATING
THE WARRANTY ON THIS WATER HEATER IS IN EFFECT ONLY WHEN
THE WATER HEATER IS INSTALLED AND OPERATED IN
ACCORDANCE WITH LOCAL CODES AND THESE INSTRUCTIONS.
THE MANUFACTURER OF THIS WATER HEATER WILL NOT BE LIABLE
FOR ANY DAMAGE RESULTING FROM FAILURE TO COMPLY WITH
THESE INSTRUCTIONS. READ THESE INSTRUCTIONS THOROUGHLY
BEFORE STARTING.
For your family's comfort, safety and convenience, it is
recommended this water heater be installed and serviced by a
plumbing professional.
INSTRUCTION MANUAL
238-45837-00F REV 05/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45837F and is the answer not in the manual?

Questions and answers

Summary of Contents for Bradford White 45837F

  • Page 1 ASME COMMERCIAL ELECTRIC WATER HEATER A Spanish language version of these instructions is available by contacting the company listed on the rating plate. La versión espãnola de estas instructiones se puede obtener al escribible a la fábrica cuyo nombre aparece en la placa de especificaciones.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS General Information ............Installation ................. Locating The Water Heater ............ Water Connections ..............Electrical Connections ............Amperage Chart ..............GPH Recovery Capacities ..........General Operation ............. Thermostat Adjustment ............Maintenance ............... 16 Servicing Guide ..............CONGRATULATIONS! You have just purchased one of the finest water heaters on the market today! This installation, operation and instruction manual will explain in detail the installation and maintenance of your new ASME Commercial...
  • Page 3: General Information

    GENERAL INFORMATION This electric water heater’s design is certified by Underwriters Laboratories (UL) and listed in accordance with UL 1453. C-UL listed in accordance with Canadian National Standard C22.2, No. 110-M90. This water heater must be installed in accordance with local codes. In the absence of local codes, install this water heater in accordance with the latest edition of the National Electrical Code.
  • Page 4: Installation

    General Information continued- A sacrificial anode(s) is used to extend tank life. Removal of any anode, for any reason, will nullify the warranty. In areas where water is unusually active, an odor may occur at the hot water faucet due to a reaction between the sacrificial anode and impurities in the water.
  • Page 5 Locating The Water Heater continued- Water heater corrosion and component failure can be caused by the heating and breakdown of airborne chemical vapors. Examples of some typical compounds that are potentially corrosive are: spray can propellants, cleaning solvents, refrigerator and air conditioning refrigerants, swimming pool chemicals, calcium or sodium chloride, waxes and process chemicals.
  • Page 6: Water Connections

    Water Connections Note: Before proceeding with the installation, close the main water supply valve. After shutting the main water supply valve, open a faucet to relieve the water line pressure in order to prevent water from leaking out of the pipes while making the water connections to the water heater.
  • Page 7 Water Connections continued- WARNING For protection against excessive temperatures and pressure, install temperature and pressure protective equipment required by local codes, but not less than a combination temperature and pressure relief valve certified by a nationally recognized testing laboratory that maintains periodic inspection of production of listed equipment or materials, as meeting the Requirements for Relief Valves and Automatic Gas Shutoff Devices for Hot Water Supply Systems, ANSI Z21.22, and the Standard...
  • Page 8 Water Connections continued- WARNING Hydrogen gas can be produced in the hot water system served by this water heater when there has been no usage for a long period of time (generally two weeks or more). Hydrogen gas is extremely flammable.
  • Page 9 Water Connections continued- Figure 1 Water temperature over 125°F can cause severe burns instantly or death from scalds. Children, disabled and elderly are at highest risk of being scalded. Review this instruction manual before setting temperature at water heater. Feel water before bathing or showering.
  • Page 10 Water Connections continued- Figure 2A (Dual Temperature System With Mixing Valve) 50A, 80A, 120A Figure 2B (Dual Temperature System With Mixing Valve) 6A, 12A, 20A, 30A, 40A...
  • Page 11 Water Connections continued- Figure 3A (Single Installation With Storage Tank Gravity Circulation) 50A, 80A, 120A Figure 3B (Single Installation With Storage Tank Gravity Circulation) 6A, 12A, 20A, 30A, 40A...
  • Page 12 Water Connections continued- Figure 4A (Dual Water Heater Installation) 50A, 80A, 120A Figure 4B (Dual Water Heater Installation) 6A, 12A, 20A, 30A, 40A...
  • Page 13: Electrical Connections

    Electrical Connections Before any electrical connections are attempted, be sure the water heater is full of water and that the manual shut-off valve in the cold water supply line is open. Heating elements, which have been energized for a very short period of time, can be damaged (burned-out) if they are not completely immersed in water.
  • Page 14: Amperage Chart

    Amperage Chart 208V 240V 277V 380V 415V 480V 600V Input 1Ø 3Ø 1Ø 3Ø 1Ø 3Ø 3Ø 1Ø 3Ø 3Ø 13.5 Water heaters with amperage draw of 120 AMPS or more require factory installed internal fusing to comply with Underwriters Laboratories requirements. GPH Recovery Capacities Temperature Rise Input...
  • Page 15: General Operation

    GENERAL OPERATION Before closing the switch to allow electric current to flow to the water heater, make certain that the water heater is full of water and that the cold water inlet valve is open. Complete failure of the heating elements will result if they are not totally immersed in water at all times.
  • Page 16: Maintenance

    Thermostat adjustment continued- DANGER Hotter water increases the risk of scald injury. Scalding may occur within five (5) seconds at a temperature setting of 140°F (60°C). To protect against hot water injury, install an anti-scald tempering valve in the water system.
  • Page 17 Maintenance continued- The following maintenance should be performed by a qualified service technician at the minimum periodic intervals suggested below. In some installations, the maintenance interval may be more frequent depending on the amount of use and the operating conditions of the water heater. Regular inspection and maintenance of the water heater will help to insure safe and reliable operation.
  • Page 18 Maintenance continued- 7. If this water heater is equipped with fuses, before removing any fuse, disconnect the all power to the water heater. Open the control box door and replace fuses according to the size indicated on the wiring diagram affixed to the inside of the control box door.
  • Page 19: Servicing Guide

    SERVICING GUIDE This “Servicing Guide“ section of this Installation and Operation Installation manual is provided for the purpose of improving the effectiveness and the efficiency of servicing this water heater. This information is intended to assist qualified service personnel. Servicing of this water heater may require knowledge of electrical testing instruments.
  • Page 20 Servicing Guide continued- Certain other control components are available as “Optional“. When these optional components are installed with the water heater, the control circuit wiring diagram accordingly will include these components. The optional equipment available from the manufacturer includes the following: ...
  • Page 21 Servicing Guide continued- The following unusual situations will give reason for the pressure controls to interrupt the electrical current to the coil of the contactor:  Upon installation or occasions of re-starting heater operation, if the inlet supply line is closed (i.e. a shut-off valve), the high pressure limit may be exceeded due to reasons of thermal expansion of the water.
  • Page 22 Servicing Guide continued- When installing the control refer to the direction of the arrow on the hex and insure that it is pointing upwards. If it is not pointing upward, the control switch will not activate when the tank is refilled with water. Refer to Figure 7 for clarification.
  • Page 23 Servicing Guide continued- The following unusual situations will give reason for the alarm to sound:  If a High Pressure Control is installed, upon installation of the water heater or occasions of re-starting water heater operation, if the inlet supply line is closed (i.e. a shut-off valve), the high pressure may be exceeded due to reasons of thermal expansion of the water.
  • Page 24 Servicing Guide continued- Electrical Door Lock: An electrical door lock is offered in order to secure the access to the water heater control cabinet. This device will lock the control cabinet door when the 120VAC control circuit voltage is applied to it. Note: Once the door is opened, the water heater can be re-energized, if necessary, for service diagnosis.
