WIRELESS REMOTE
CONTROLLER
RM02A/BGE-A
OPERATION MANUAL
MAN-O-RCVRF-0615
intensity.mx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM02A and is the answer not in the manual?

Questions and answers

Summary of Contents for intensity RM02A

  • Page 1 WIRELESS REMOTE CONTROLLER RM02A/BGE-A OPERATION MANUAL MAN-O-RCVRF-0615 intensity.mx...

  • Page 2: Table Of Contents

    Make sure to read chapter PRECAUTIONS before you operate the air conditioner. This manual is available for model RM02A/BGE-A and RM02A/BGE(T)-A. RM02A/BGE-A and RM02A/BGE(T)-A can be applicable for cool&heat type air conditioners. CONTENTS 1 Safety Precautions............. 2 Model And Specification.............

  • Page 3: Safety Precautions

    I. Safety Precautions The following contents are stated on the product and the operation manual, including usage, precautions against personal harm and property loss, and the methods of using the product correctly and safely. After fully understanding the following contents (identifiers and icons), read the text body and observe the following rules.

  • Page 4: Model And Specification

    2. Model And Specification Model RM02A/BGE-A RM02A/BGE(T)-A Rated voltage 3.0V(2 pieces of LR03 7# batteries) Min voltage for sending 2.0V signal of CPU Effective receiving distance 8m(Where is 3.0V,that will be 11m) -5~60°C Operation condition 3. Buttons And Their Functions...
  • Page 5 ON/OFF: For turning on or turning off the air conditioner. 26 °C: Press this button, can operate the cool mode with the setting temperature 26 °C . MODE: Once pressing, running mode will be selected in the following sequence: HEAT COOL AUTO TIMER...

  • Page 6: Names Of Indicators And Their Functions

    STRONG Press this button, set the air conditioner to operate as strong mode, and the frequency will be raised, press again will cancel this mode. (Only available when remote controller is used with corresponding unit.) DRY·AUXILIARY HEAT FOLLOW ME Press the left of the button when it is operating the dry cleaning function, will close the dry cleaning function;...

  • Page 7: Operation Instructions

    Timing ON/OFF When adjusting timing ON state or only the timing ON function has been set, the “Timing ON” will be displayed; when adjust- ing timing OFF state or only the timing OFF function has been set, the “Timing OFF” will be displayed. Lock Press MODE and TIMER button for 5s simultaneously lock...

  • Page 8: Auto Operation

    5.2 Auto Operation (Normal) AUTO operation TEMP ON/OFF AUTO MODE FAN SPEED Lighting Lighting Running Fig.5-1 Press MODE to select AUTO. Adjust temp via . Generally the range is 17 ~30 Press ON/OFF and running indicator light on indoor unit is lightened.

  • Page 9: Other Functions Operation

    CAUTION “FAN” operation can not set the temperature, when select this operation only can do 1,3,4 steps. “DRY” operation can not set the fan speed, when selsect this operation only can do 1,2,4 steps. 5.4 Other Functions Operation Dry function Function instruction Lighting This air conditioner has dry function,...
  • Page 10 Strong operation function Function instruction TURBO Lighting When operating cooling, press the “TURBO” button and Running Turbo operate the strong cooling operation, at the same time raise the frequency, Fig.5-5 press again will close the strong operation. This function is invalid under operating sleep function. Energy-saving function Function instruction When operating COOL/AUTO, press the “ECO”...
  • Page 11 Auto heat recycling mode function instruction Function Temperature difference, means the different temperature between the indoor temperature (Tf) detected by the remote controller and the remote controller setting temperature (Ts). (the default difference is 3°C, the difference range is 1~4°C) instruction press buttons for 5S simultaneously,...

  • Page 12: Timer Operation

    5.5 Timer Operation Setting timing ON Timing Setting TIMER TIMER ON TIMER ON TIMER TIMER ON COOL COOL COOL FAN SPEED FAN SPEED FAN SPEED Fig.5-7 Under the remote controller is OFF, press the “TIMER” button, then the remote controller will display the timing ON icon and number display area will show up last timing ON time, and will display icon “h”.

  • Page 13: Precautions

    Check the preset time of timing: press the corresponding timing button once, then will display the timing time. Change the timing ON or OFF time: press the corre- sponding timing button, then reset timing ON or OFF time. Cancel the timing: adjust the timing ON or OFF time to be 0.
