Instruction Manual for the
MS-4012/4024
Fire Alarm Control Panels
12 Clintonville Road, Northford, CT 06472
Phone: (203) 484-7161
CMS-4012/4024
and
FAX: (203) 484-7118
E
Document 15586
5/11/93 Revision:
P/N 15586:E
ECN 93-119

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-4012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fire-Lite MS-4012

Summary of Contents for Fire-Lite MS-4012

  • Page 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 Instruction Manual for the MS-4012/4024 CMS-4012/4024...
  • Page 2 15586 Rev E 5/14/93 P/N 15586:E...

  • Page 3: Table Of Contents

    Note: This instruction manual covers panels listed by UL (MS-4012 and MS-4024) and by ULC (CMS-4012 and CMS-4024). For simplicity, this document refers to these panels as the "4012" (for the 12-volt MS-4012 and CMS- 4012 control panels) and the "4024" (for the 24-volt MS-4024 and CMS-4024 control panels).

  • Page 4: Table Of Figures

    Table of Figures Page 2A Dress Panel 3A Zone Wiring 3B Dress Panel Terminal Guide 3C Indicating Circuit Wiring Diagram 3D Typical End of Line Relay Connection 3E AC Connections 3F Battery and Meter Connections 3G Remote Zone Annunciator Installation 3H Zone Relay Module Connections 3I General Alarm and Trouble Module Connections 3J Transmitter Module Connections...
  • Page 5 The MS-4012/4024 and CMS-4012/4024 Fire Alarm Control Panels are suitable for service under the following standards: National Fire Protection Association (NFPA) Standards: 71 Signaling Systems for Central Station Service 72 Local Protective Signaling Systems 72 Auxiliary Protective Signaling Systems 72 Remote Station Protective Signaling Systems...
  • Page 6 A Packaging Note Each optional module listed in this manual as "40xx" is offered in 12 and 24-volt versions. The "XX" represents either "12" or "24" volts DC. Each module is further distinguished by its respective two letter abbreviation (such as TM for Transmitter Module).

  • Page 7: Fire Alarm Control System

    1.0 Fire Alarm Control System The MS-4012/4024 and CMS-4012/4024 are 4-zone fire alarm control panels designed for use in commercial, industrial, and institutional applications. The 4012 is designed for 12-volt (nominal) devices. The 4024 is designed for 24-volt (nominal) devices. Activation of any compatible two wire detector or any normally open initiating device will sound audible devices, annunciate a fire zone, trip a municipal box, notify a remote station and activate supplementary relay(s).

  • Page 8: Controls And Indicators

    2.0 Controls and Indicators Control Switches FIRE ALARM CONTROL Trouble Silence switch will si- lence an audible trouble device. The system trouble LED and the ZONE ALARM POWER trouble contact will remain acti- SYSTEM SYSTEM RESET vated until the trouble has been TROUBLE ALARM corrected.

  • Page 9: Status Indicators

    2.2 Status Indicators A.C. Power - A green LED that remains on while the A.C. power supply is operating. If this indicator fails to light under normal conditions, service the system immediately. System Alarm - A red LED that lights when an alarm condition is detected. Supervisory - A yellow LED that indicates need for action in connection with the supervision or maintenance of sprinklers, extinguishing systems or other protective systems.

  • Page 10: Installation Instructions

    3.0 Installation Instructions General Carefully unpack the system and check for shipping damage. Mount the cabinet in a clean, dry, vibration-free area in which extreme temperatures are not encountered. The location should be readily accessible with sufficient room for easy installation and maintenance. Locate the top of the cabinet approximately five feet above the floor with the hinge mounting on the left.

  • Page 11: Output Circuits

    Figure 3B: Dress Panel Terminal Guide Waterflow - For waterflow service without a disable capability, the 4000WF can be employed. This adhesive- backed metal plate can be affixed to the front dress panel over any zone used for monitoring sprinkler waterflow detection devices.

  • Page 12: Power

    Power CAUTION: Several different sources of power can be connected to this panel. Disconnect all sources of power before servicing. The panel and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while this unit is energized. Smoke Detector Power - Resettable power for 4-wire photoelectric and ionization smoke detectors can be obtained from terminals 19 (negative) and 20 (positive).

  • Page 13: Optional Modules

    Battery Power - Observe polarity when connecting battery. Connect battery to P2 on the main board using the plug-in connector provided. See Appendix B for calculation of correct battery rating. See Figure 3F for battery connections. CAUTION: Battery contains sulfuric acid which can cause severe burns to the skin and eyes, and can destroy fabrics.
  • Page 14 Remote Zone Annunciator (RZA-4) - This option provides remote LED annunciation of zone alarms and system trouble status. It includes an audible trouble device with a trouble silence switch. To make use of this remote function, an LED interface board (40xxLI) must be used. The 40xxLI module is supervised for insertion (once JP3 is removed from the main board).
  • Page 15 Zone Relay Module (40xxZR) - One Form-C dry alarm contact per zone, one Form-A general alarm contact, one Form-C trouble contact are provided with this option. The module is supervised for insertion (once jumper JP3 on the main board is cut). If the 40xxZR is then removed, all four zone trouble LEDs and the system trouble LED will come on, and the panel's audible trouble device sounds.
  • Page 16 General Alarm and Trouble Module (40xxAT)- This module provides one Form-C general alarm contact and a system trouble contact. An Auxiliary Disable switch disables the alarm contact and creates a system trouble condition. A yellow LED indicates when the switch is in the disable position. This module is supervised for insertion (once jumper JP4 on the main board is cut).
  • Page 17 Transmitter Module (40xxTM) - Use this module to connect to a local energy municipal box. Reverse polarity alarm and trouble outputs are also provided. The reverse polarity alarm and municipal box outputs can be disabled via a switch. A yellow LED indicates when the switch is in the disable position. The module is supervised for insertion (once JP4 on the main board is removed).
  • Page 18 McCulloh Transmitter - A McCulloh-type transmitter may be connected to the 4012/4024 (see Figure 3K for connection of a model ATTE-B transmitter). The transmitter is mounted in a separate cabinet. Note that a General Alarm and Trouble Module (40xxAT) is required to use the transmitter. NOTE: Be sure to derate available signaling power by the transmitter coil current.

  • Page 19: Basic System Wiring Diagram

    Indicating Appliance Circuits: Class B operation. Power limited circuitry. 2.5 amps max (1.5 amps/circuit). 1.2 mA in normal. ELR = 10 K, 1/4 watt. Must use polarized indicating appliances. Initiating Device Circuits: Class B operation. 2.0 Dry supplementary alarm contact. Rated 2 amps @ 30 mA per loop.

  • Page 20: Periodic Testing

    4.0 Periodic Testing To insure proper and reliable operation, it is recommended that an inspection and testing of the system be conducted monthly, or as required by National and/or Local codes. Testing should be performed by a qualified service representative. Notification Before testing the panel, notify: ** Fire department and/or the central station receiving any transmitted alarm or trouble condition.

  • Page 21: Trouble Test

    Trouble Test Momentarily open the following circuits, one at a time, and check for a trouble signal: Indicating Appliance Circuits 1 and 2 All initiating zones Supervisory circuit Municipal Box (if employed) Battery Test With fully charged battery, remove AC power and repeat the test procedure outlined in Section 4.2. Measure battery voltage while the indicating appliances are activated.

  • Page 22: Troubleshooting Guide

    5.0 Troubleshooting Guide Troubleshooting is divided into two parts. Section 5.1 is a diagnostic procedure that can be used to determine the general condition of the control panel. Section 5.2 is to be used by QUALIFIED SERVICE PERSONNEL ONLY to isolate a specific problem with the panel. Control Panel Checkup This procedure must be used after initial installation of the control panel.

  • Page 23: Control Panel Checkup

    System Test - Slide the system test switch down and ensure that all LEDs except the zone alarm LEDs light. Release the switch and ensure that all alarm LEDs light. Note: The Supervisory LED may not light during System Test, depending on whether or not Zone 4 is programmed for supervisory service. To test the Supervisory LED, remove the jumper across Terminals 9 and 10, creating a supervisory condition.

  • Page 24: Battery Charger Check Procedure

    (Terminal Block 3) in the upper right-hand part of the control board. Any attempts to adjust this output may result in damage to the batteries (to read and adjust the charger output on earlier model MS-4012/ 4024s, see the next page).
  • Page 25 1K resistor. If the voltage measured is not 13.2 - 13.3 (4012) or 27.5 - 27.7 VDC (4024), perform the following calibration procedure: Step 1 Adjust R5 until the voltage across the 1K resistor is 30 VDC (MS-4024) or 15 VDC (MS-4012). Step 2 Adjust R108 until the the Battery Trouble LED just turns on (threshold point).

  • Page 26: Appendix A: Specifications

    Appendix A: Specifications A.1 Initiating Circuits Power-limited circuitry Operation: Class B (Style B) Standby voltage: 4012 = 12 VDC (ripple = 10mV peak-to-peak) 4024 = 24 VDC (ripple = 10mV peak-to-peak) Alarm current: 15 milliamps minimum Short circuit current: 35 milliamps typical Maximum detector current in standby: 2 milliamps (peak) per zone Maximum loop resistance = 200 ohms End-of-line resistor:...
  • Page 27 A.6 Zone Relay Module (40xxZR) Contacts rated for: 2.0 amps @ 30 VDC (resistive) 0.5 amps @ 120 VAC (resistive) Note: For U.L.C. applications, contacts are derated for: 2.0 amps @ 30 VDC (resistive) 0.5 amps @ 30 VAC (resistive) A.7 General Alarm and Trouble Relay Module (40xxAT).

  • Page 28: Appendix B: Power Calculations

    Appendix B: Power Calculations NOTE: The LED Interface (40xxLI) does not consume any power and can be ignored when calculating power requirements. In addition, the General Alarm and Trouble Module (40xxAT) does not consume power during trouble and the RZA-4 consumes nothing in alarm. Table 1: Standby Battery Requirements Basic Control Panel 79.2 mA...
  • Page 29 Basic Control Panel (all zones in alarm) If using the Zone Relay Module, add 64 mA for the MS-4012 or 32 mA for the MS-4024 If using General Alarm & Trouble Module: add 18 mA for the MS-4012 or 10 mA for the MS-4024...
  • Page 30 MS-4012/4024 Quick Reference Sheet Alarm Condition: 1) The system alarm and zone alarm indicators will light. 2) Indicating appliances will be activated. 3) Supplementary output will be activated. Alarm Silence: Locate alarmed zone and slide zone disable switch downward. Alarm Reset: After correcting the alarm condition, reset the control panel by depressing the SYSTEM RESET switch.
  • Page 31 CMS-4012/4024 Quick Reference Sheet Alarm Condition: 1) The system alarm and zone alarm indicators will light. 2) Indicating appliances will be activated. 3) Supplementary output will be activated. Alarm Silence: Locate alarmed zone and slide zone disable switch downward. Alarm Reset: After correcting the alarm condition, reset the control panel by depressing the SYSTEM RESET switch.
