Quick Start Manual
SV3018 Package Contents
1. SV3018 IP Camera
2. Mounting Kit
3. Screw Sets
4. SV3018 Warranty Card
5. SV5100 Installation software tools
6. Switch setting & grounding sheet
SV3018 Monitor
Other Items Required for Installation
1. Small TV
2. Notebook or tabletop PC
3. CATE 5E Cable
4. Power Line Cable
SV3018
Warranty
Card
Grounding sheet
Mounting
Kit
Screw Sets
SV5100 software
Advertisement
Table of Contents
Summary of Contents for SunVision SV3018
- Page 1 Quick Start Manual SV3018 Package Contents 1. SV3018 IP Camera 2. Mounting Kit 3. Screw Sets 4. SV3018 Warranty Card 5. SV5100 Installation software tools 6. Switch setting & grounding sheet SV3018 Monitor Mounting SV3018 Warranty Card Screw Sets Grounding sheet...
- Page 2 Installation Step Step1. Mounting and wiring Thread the cat5E and AC power supply cables through the head of mounting kit to the bottom, and install the mounting kit at desired location. And, fasten the screw at the bottom of the mounting kit to fix the horizontal and vertical angles of the camera.
- Page 3 Step4. Grounding Step5. Power on & stop tracking After power on the SV3018, switch down the SW3 & SW39 then push the reset button. SW39 Reset button **Please waitting one minute for cameras booting.
- Page 4 Switch up the SW3 & SW39 then push the reset button. Please wait for over one minute booting. Step8. Run SV5100 installation software tool After finish the connection between SV3018 and notebook, run SV5100 tool. Select camera you want to set, and then connect it.If connecting fail, please check netware connecting.
- Page 5 Switch to LIVE page and check the SV3018 tracking performance. Step12. Connect to NVR or network-recording system, the SV3018 setting is complete. SV3018 is VIVOTEK-compatible, the cameras are IP8162 inside. About IP video management system, please contact with VIVOTEK dealer.
