Summary of Contents for Square ip29
- Page 1 HD 1080P IR Table Clock Security Wi-Fi Camera User Manual Version:Nov,2015...
- Page 5 Quick guide of Wi-Fi camera function 1. Plug in power —> Turn on device’s backside ON/OFF button, wait for 2 minutes; 2. Enter smartphone setting —> Search and connect device’s wi named: YM……,wait till phone status bar appear Wi-Fi symbol; 3.
- Page 6 Overview The HD 1080P IR Table Clock Security Wi-Fi Camera is a totally new design, rm housing table clock with an integrated smart & powerful 1080P Wi-Fi Camera. First, it is a super simple table clock with time display only (12 /24 hour);...
-
Page 7: Product Instruction
Product instruction Time display Camera Wi-Fi indicator light IR LED lights DOWN ON/OFF (For Wi-Fi Camera) Micro SD card slot Reset key Charging indicator light USB port Battrey... - Page 8 Time display Camera Wi-Fi indicator light IR LED lights DOWN ON/OFF (For Wi-Fi Camera) Micro SD card slot Reset key Charging indicator light USB port Battrey...
- Page 9 Getting started of clock part Open back cover, remove the protective seal from the battery and plug it into AC power using the included adapter; Time display will be lighted on. Press SET to set hour/minutes; Press UP to set 12/24 hour format. Getting started of Wi-Fi camera part Step1: Download and install APP Scan below QR code or search and download free...
- Page 10 Step2: Connect power and turn on device Remove the protective seal from the battery and plug it into AC power using the included adapter; Turn on backside switch, and wait for 2 minutes. (Front blue light blink slowly.) Step 3:Connect Wi-Fi 1.
- Page 11 2. Open APP, press symbol + at the top right corner, select “Add new online camera”； Search for new camera and press ok. Then back to the rst page to see the live video of camera and do the following setting.
- Page 12 3. Press the gear icon after the camera or long press the camera and select Advance Con g, select Wi-Fi Con g. 4. Select your Wi-Fi and input passcode, camera will be connected to your Wi-Fi. Your smartphone will disconnect the signal from device and connect to your Wi-Fi.
- Page 13 Set camera name and private code Set name:Press the after the camera or long press the camera,select Modify camera, select Name and revise name like Of ce, Room…... Set code: Long press the camera and select Advance Con g ,select Change P2P password.
-
Page 14: App Introduction
APP introduction Camera name Camera setting key Camera UID Camera online user number Snapshot: Review snapshot pictures Record: Review recorded videos Alarm: Review alarmed pictures Live video page - Click camera to check Brightness Resolution 1080p/720p/640p/ （ Contrast 480p,1080p=Highest resolution ）... - Page 15 Alarm Con g: Set motion detection sensitivity / Alarm interval Wi-Fi Con g: Set camera to other Wi-Fi SD Card Record Con g: Set SD card record mode / Resolution /File length … Set time Set motion alarm with email (Need turn on email alert rst in alarm con g) Change P2P password: Set camera new password...
- Page 16 Set and watch by PC in LAN 1. Once camera connected well with Wi-Fi, install software “IPCamera”from included CD and open software to nd the connected device’s IP address. 2. Double click the IP address, insert name“admin” (no password) and press ok.
- Page 17 3. After above steps, you can insert setting interface. For rst use, please choose langauge, then click download and install plug-in.
- Page 18 4. Click to go to the nal setting interface. 5. Click left options to set other needed functions.
-
Page 19: Specification
Specification Resolution 5 Mega CMOS Video pixel 1920*1080 Frames 25fps Compressed format H.264 Video format View angle 140° Type of memory card TF card>=Class 4/10 and HC marked Maximum capacity of memory card 32GB PC operation system Windows 7, 8 / Mac OS X Play software VLCPlayer/SMPlayer Mobile phone operation system... - Page 20 3. Q: Can’t add or set camera after connected with camera Wi-Fi? A: Please wait phone status bar appear Wi-Fi symbol, then to do follow settings. 4. Q: Why live video screen shows up black and a searching circle spins in center but nothing ever displays? A: 1).
- Page 21 9. Q: Motion detect set and alarm? A: 1). Set motion detect sensitivity in Advance Con g - Alarm Con g, and scroll down press OK; 2). When motion detected, camera will push a alarm message to your phone and take 3 pictures for checking in the APP [ Page 12 - Alarm - 10.
- Page 22 14. Q: Forget camera password, or item goes abnormal? A: Turn on camera and wait for 2 minutes, press reset key around 5 seconds till front blue light off to restore factory default. Camera restarts and get ready again in 2 minutes. 15.
- Page 23 The End!
