ENGLISH
e. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.
5. DELETE ALL SCENES:
a. Switch the unit off.
b. Switch the unit back on while you press and hold down the Program and Bank
Down buttons at the same time. All scenes should be cleared.
Note: Be aware that all your scenes will be lost, to be used with care!
6. COPY A BANK OF SCENES:
a. Enter program mode
(Press and hold the "Program" button until its LED blinks)
b. If you want to check the output, verify that the blackout LED is not lit, if it is,
press it once to exit blackout mode.
c. Press the Bank Up/Down buttons to select the bank containing the scenes you
wish to copy.
d. Press the MIDI/Rec button.
e. Press the Bank Up/Down buttons to select the bank you wish to copy to.
f. Press the Music/Bank Copy button, all LEDs will blink three times indicating the
function has been completed.
g. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.

CHASES

A chase is a succession of scenes in a certain order so you must have already
programmed these scenes in order to program a chase. Before programming chases
for the first time it is recommended you delete all chases in the controller.
See Delete All Chases for instructions on how to do so.
1. DELETE ALL CHASES:
a. Switch the unit off.
b. Switch the unit back on while you press and hold down the Auto/Del and Bank
Down buttons at the same time. All chases should be cleared.
Note: Be aware that all your chases will be lost, to be used with care!

2. PROGRAMMING A CHASE:

a. Enter program mode (
Press and hold the "Program" button until its LED blinks)
b. Check the blackout button and verify that the LED is not lit, if it is, press it once
to exit blackout mode.
c. Press the button of the chase you wish to program.
d. Press the Bank Up/Down buttons to select the bank containing the scene(s)
you wish to program in your chase.
e. Press the button of the desired scene.
f. Press the MIDI/Rec button.
g. Repeat steps d to g until all desired scenes have been entered.
h. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.
JB SYSTEMS®
OPERATION MANUAL
9/82 SCANMASTER 1612 (SM-1612)
ENGLISH
3. INSERT A CHASE STEP:
a. Enter program mode
(Press and hold the "Program" button until its LED blinks)
b. Check the blackout button and verify that the LED is not lit, if it is, press it once
to exit blackout mode.
c. Press the button of the chase you wish to program.
d. Press the TAP/Display button, the LCD display will show the current chase
step.
e. Press the Bank Up/Down button and scroll to the step you wish to insert the
step after.
f. Press the MIDI/Rec button, the segment display will read the step one step
higher than before. The LCD shows the current chase, scene, and bank.
g. Press the Bank Up/Down buttons to select the bank containing the scene you
wish to insert in your chase.
h. Once you have selected the scene you wish to insert, press the MIDI/Rec
button again. All LEDs will blink three times indicating the new step has been
inserted into the chase.
i. Repeat steps e to h until all desired scenes have been inserted.
j. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.
4. DELETE A CHASE STEP:
a. Enter program mode
(Press and hold the "Program" button until its LED blinks)
b. Check the blackout button and verify that the LED is not lit, if it is, press it once
to exit blackout mode.
c. Press the button of the chase that contains the step you want to delete.
d. Press the Tap/Display button, the LCD shows the current step.
e. Press the Bank Up/Down buttons and scroll to the step you wish to delete.
f. Press the Auto/Del button to delete the step. All LEDs will flash three times
indicating the requested operation has been performed.
g. Eventually repeat steps e and f until all desired steps have been deleted.
h. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.

5. ADDING A BANK OF SCENES TO A CHASE:

Note: The bank of scenes will be added at the end of the chase.
a. Enter program mode (Press and hold the "Program" button until its LED blinks)
b. Check the blackout button and verify that the LED is not lit, if it is, press it once
to exit blackout mode.
c. Press the button of the chase you wish to edit.
d. Use the Bank Up/Down key to select the bank of scenes you wish to add.
e. Press the Music/Bank Copy button.
f. Press the MIDI/Rec copy button, all LEDs will blink three times indicating that
the requested operation has been performed.
g. Press and hold the program button for some seconds to exit program mode.
The LED will turn off.
JB SYSTEMS® 10/82 SCANMASTER 1612 (SM-1612)
