Pioneer MEH-P7300R Manual

Multi-cd/dab control high power md player with tuner.
Hide thumbs

Advertisement

Service
Manual
MULTI-CD/DAB CONTROL HIGH POWER MD PLAYER WITH RDS TUNER
MEH-P7300R
MULTI-CD CONTROL HIGH POWER MD PLAYER WITH FM/AM TUNER
MEH-P7350
- This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-1020
CRT2653
- US and foreign patents licensed from Dolby Laboratories Licensing Corporation.
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
4. PCB CONNECTION DIAGRAM ................................42
5. ELECTRICAL PARTS LIST ........................................52
6. ADJUSTMENT..........................................................63
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE INC.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
MEH-P7300R/EW
EQ
SOURCE
DISP
Mech. Module Remarks
MD-4LP
MD Mech. Module:Circuit Description, Mech.Description, Disassembly
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
SELECT
SFEQ
1
2
3
4
5
6
E
B
FUNC
AUDIO
ES
7. GENERAL INFORMATION .......................................67
7.1 DIAGNOSIS ........................................................67
7.1.1 TEST MODE ..............................................67
7.1.2 DISASSEMBLY .........................................71
7.1.3
7.2 IC ........................................................................76
7.3 OPERATIONAL FLOW CHART ...........................84
8. OPERATIONS AND SPECIFICATIONS.....................85
ORDER NO.
CRT2660
EW
.......74
K-ZZS. MAR. 2001 Printed in Japan
