Summary of Contents for Refco GOBI
- Page 1 GOBI Installation and operating guide Installations- und Bedienungsanleitung Guide d’installation et d’utilisation Istruzioni per l'installazione e l'uso Guía de instalación y funcionamiento Installatiehandleiding en gebruiksaanwijzing Ðóêîâîäñòâî ïî óñòàíîâêå è ýêñïëóàòàöèè...
- Page 2 GOBI Condensate removal pump Installation and operating guide The GOBI is a self-contained condensate removal system for use outside but directly adjacent to air conditioning air handlers, as shown opposite. Box Contents 1. GOBI Pump 2. Filter 3. Backplate 4. Front cover 5.
- Page 3 SAFETY INSTRUCTIONS AND WARNING Under normal use this equipment requires no user intervention. Installation, both fixing and electrical, and maintenance work shall be carried out only by the manufacturer or by its service center or in any case by a person having similar skills, so as to prevent any risk.
- Page 4 Installation The GOBI can be installed on the left or right hand side of the air handler. The following installation instructions refer to a right handed installation. For left handed installations swap the positions of the pump and condensate collection tray as shown below.
- Page 5 Wiring Connections Connect the ground, live and neutral wire from the supply cable of the GOBI pump to the supply terminals (see Fig.6) This product must be connected using a switch with contact separation in all poles that provide full disconnection from the power supply under over-voltage categories III. A fuse non time delay (rated 250V 1A), shall be fitted into the line, supply side (see Fig.6...
- Page 6 Specifications Power supply: 120/240Vac, 50/60Hz Auto sensing Power consumption: 16W max., 0.25W when idle Alarm relay: 5A, 30Vdc, 250Vac Break on fault Capacity: 12 litres/hour max. (3.17 US gal/h) Maximum head: Vertical >20m (65 ft), Horizontal >100 m (328 ft) Suction 1 m max. (3.28 ft) Ambient temp: 0 - 40°C Water temp:...
- Page 7 This product is guaranteed for two years to be free from manufacturing defects or faulty materials. If it should fail for either of these reasons within two years from the date of manufacture it will be repaired or replaced free of charge, at the option of REFCO Manufacturing Ltd.
