Summary of Contents for arcelik ARK 293
- Page 1 ARK 293 ARK 294...
- Page 2 Please read this manual first! Dear Customer, We hope that your product which has been manufactured in mod- ern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this manual carefully before using your product and keep it for future reference.
- Page 3 Contents 1 Safety Warnings 2 Technical Aspects Of Your Machine 3 Using Your Machine 4 Maintenance And Cleaning...
- Page 4 Safety Warnings • Do not ever plug the fan without finishing the assembly. • Before plugging the fan, make sure that the source power is the same as the declared voltage on the model sticker. • Make sure that speed setting switch is in position “0”...
- Page 5 Technical Aspects Of Your Machine ARK 293 Front guard Power : 45 W Blade fixing nut Voltage : 230 V ~ Blade Frequency : 50 Hz. Guard fixing nut Isolation class : II Guard lock Water penetration class : Ordinary...
- Page 6 Fan Assembly and Preparation to Use Assembly of the Base 1- Unscrew the base fixing nut from the body (part no:18). 2- Hold the base (part no: 15) with base rubbers facing down and insert the supply cord from the hole. Then insert the body to hole, (you should align the body goes into the groove to the base, correct position)
- Page 7 4- Put the joint nut into place and fix by turning clockwise. Blade Assembly ARK 293 : Place the blade by align- ing with the groove on the blade with motor pim. ARK 294 : Place the blade by align-...
- Page 8 Speed Setting The operation should be done prop- You may run the fan by moving the erly. Otherwise the blade will turn in rotary switch left / right and choosing space and damage the product. a speed position. Fix the blade fixing nut bu turning counter clockwise according to the To turn off set the switch in position direction given on the nut.
-
Page 9: Maintenance And Cleaning
Adjusting The Blow Out Angle Before adjusting the blow out angle turn off your fan. Then you may adjust the blowing angle by moving the guard upwards and downwards as show on the picture. Maintenance And Cleaning 1- Make sure that the fan is turned off and unplugged before starting any cleaning process.
