WS-6905 User Manual

Product Description

It is a battery powered hand held DVB-T
terrestrial alignment meter demodulating DVB-T
COFDM Signal. It s very convenient for installer to
catch quick and accurate Alignment for Antenna to the
best direction.
It s with microprocessor controller, reliable and
'
stable performance. When it s turned on, channel
1
picture, Signal Strength and Signal Qulaity will be
showed on LCD Screen after you set up your local
1
DVB-T Parameter. Also, it s with multichannel Signal
3
indicator which is very helpful for alignment.
It supports BER, S/N, Signal Strength and signal
3
lock sound.
It detects very faint signal, and supports antenna
3
power OFF/5V/12V/15V/18V/24V selectable.
4
It s with auto-protection for LNB short-circuit.
'
It includes both AV IN and AV OUT for Camera,
7
LCD...etc.
It s used with 12V Power Adaptor when you need
'
8
to use external power.
10
It includes high capacity Lithium Battery 8.4V
3000mAh which works for more than 4 hours after it s
13
fully charged.
Product Description
'
'
'
'

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS-6905 and is the answer not in the manual?

Questions and answers

Summary of Contents for Satlink WS-6905

  • Page 1: Product Description

    WS-6905 User Manual Product Description It is a battery powered hand held DVB-T terrestrial alignment meter demodulating DVB-T COFDM Signal. It s very convenient for installer to catch quick and accurate Alignment for Antenna to the best direction. Product Description It s with microprocessor controller, reliable and stable performance.
  • Page 2 1.Guide To connect it with external antenna Signal Input 1.1 Face Panel & Button To show menu and channel pictures...etc LCD Screen To lock signal when it lights Signal Lock Indicator Light The light is on when its charging; Charging Indicator Light It s off when charging is complete.
  • Page 3 1.2 Power On/Off To turn on the meter when Power Switch moves to I position To turn off the meter when Power Switch moves to 0 position Please turn off the meter to charge the meter in time when system information for showing low power popes 1.3 Power Supply and Battery It s used with 12V 1.5A Power Adaptor.
  • Page 4 2.1.1 Country Setting To select country to receive signal. 2.1.2 Channel To select channel type to be received. 2.1.3 Frequncy To set frequency for receiving signal by inputting frequency value with numerical keys. 2.1.4 Bandwidth 2.1.8.1 Scan To Select Bandwidth 6M/7M/8M based on your local region.
  • Page 5 2.1.8.2 Scan All To scan all channels, and it auto-restores the scanned channels, and then return to previous menu. 2.2 Channel Check 2.3 Multimedia 2.2.1 Move Press button to move Icon. 2.2.2 Select Press button to local channel, and tick the box to select it.
  • Page 6 2.3.2 My Music For multimedia playing, the external flash stick must be inserted into USB port. Otherwise, it will pop up Device " is not ready in the screen. " Play music with MP3/WMA format. 2.3.1 My Album 2.4 System Setup Review pictures with JPG/GIF/BMP format.
  • Page 7 2.4.5 SW Update To update SW or Data via USB port. To insert the external flash stick (including updated SW) into USB port, and then enter into upgrade menu to select updated SW. It automatically returns after updating SW. 2.4.1 Country Setting Select country to receive TV channel.
  • Page 8 Modulation COFDM Constellation QPSK,16QAM,64QAM Modulation Transmission mode 2K,8K Guard interval 1/2,1/4,1/8,1/16,1/32 1/2,2/3,3/4,4/5,5/6,7/8 Processor 32Bit RISC CPU & SDRAM Memories FLASH MPEG 2 Main Proflie@Main Level Date rate Up to 15M bit/s Video Decoder Resolution 720*576,720*480 Video format PAL/NTSC/SECAM 2.4.6 Set Default MPEG-2 Layer 1&2 Press factory default to set default.
