USER MANUAL
MAIN FUNCTION AND FEATURES
1. DC 9V power supply, standby current less than 20mA
2. Six groups of alarm telephone numbers can be pre-stored
3. Ten seconds pre-recorded memo messages
4. Long distance via public telephone network set guard status or withdraw guard to the main
dialer
5. Long distance via public telephone network monitor the background sound around the
auto-dialer
6. Setting guard delay time 0~90 seconds for four guard zone
7. Setting alarm delay time 0~90 seconds for four guard zone alarm signal
8. Siren hooting time length control option 1~20 minutes
9. Telephone line cut off alarm function option
10. Six wireless distinguishable guard zones LED indicator on the main set
11. Each of the four guard zones can be set on guard or withdraw guard independently
12. One panic key for help provided on the main set
13. Two panic keys for help is provided on the remote controller which will make the main dialer
give out loud sound or not as well as dialing when being trigged
14. Convenient key input is prepared on the front panel
Various kinds of door magnetic switch and PIR infrared detector are configurable.
Rechargeable DC9V power transformer provided for power cut backup.The dialer can report
the alarm messages to an administration computer immediately via the public telephone
network..
OPERATION METHOD
Fig.1 System connection illustration
Note:the extension can connected to your telephone machine
Set guard and withdraw guard
This alarm system can be divided into four alarm guard zones. Each guard zone can
configured with several door entry detectors, infrared detectors, gas leakage detectors and
smoke detectors. You can set guard or withdraw guard using the remote controller or by
pressing the keypay on the main set.
1. Setting guard by using remote controller
*Setting guard:
Press and release
will light up ,buzzer beep one time ,the main set went into status of setting guard. At this time,
：
key on the remote controller, the ' GUARD" LED on the main set
Advertisement
Summary of Contents for ANSITE AST-2008D2
-
Page 1: User Manual
USER MANUAL MAIN FUNCTION AND FEATURES ： 1. DC 9V power supply, standby current less than 20mA 2. Six groups of alarm telephone numbers can be pre-stored 3. Ten seconds pre-recorded memo messages 4. Long distance via public telephone network set guard status or withdraw guard to the main dialer 5. - Page 2 if the main set received the alarm signals from detectors, it will alarm if set no delay time,but if you set a delay time for guard,for example 30 seconds, setting guard will take into effect only after 30 seconds later from the time you pressed the key.
- Page 3 and stop alarm. Each guard area is corresponding to a LED indicator on the front panel,when alarm take place,the corresponding LED light up, then the alarm system dial out the telephone numbers and alarm. The guard zone doesn t mean the same area ,that is to say, detectors in different places can be configured into the same guard zone and light up the same alarm LED.
- Page 4 key four digit password (such as “1234” or other ) at first,then press “store”, then press“1”, which means first group ,then press “*”, then press “66778899”, then press“store” , this finish first group numbers storing. For example, if you want to store second group telephone numbers such as “012345678”, you press key four digit password (such as “1234”...
- Page 5 Press key: four digit password (such as “1234” or other ) at first,then you press key “program”, then press key “4” . “ This function clear all settings but the user password, include pre-stored telephone numbers, all settings will be stored to its initial settings as it manufactured out. This fuction is often useful to diagnosis the “obstacles”...
- Page 6 Receiving alarm messages and processing When alarm broke out, the siren will resound as you selected, the system will automatically dial out the pre-stored telephone numbers and send memo messages to the alarm callee telephone.When you connected on your telephone to the alarm set and hear the pre-recorded memo messages by the telephone, you can press the key on your telephone to process the alarm messages as you need: You can input the digital key on your callee telephone as follows,...
-
Page 7: Encoding Method
Press“9”: exit telecommunications settings and hook on Press“01”: open guard zone one alarm reporting Press“02”: close guard zone one alarm reporting Press“03”: open guard zone two alarm reporting Press“04”: close guard zone two alarm reporting Press“05”: open guard zone three alarm reporting Press“06”: close guard zone three alarm reporting Press“07”: open guard zone four alarm reporting Press“08”: close guard zone four alarm reporting... - Page 8 protect each alarm system from interfering each other, the wireless signal can use different encoding style for different alarm system, you can add detector to an alarm system by encode the detector. Each alarm system has itd unique wireless communication code, this include 8 bit address code A0,A1,A2,A3,A4,A5,A6,A7, and 4 bit zone code( or date code) D0,D1,D2,D3, each set of alarm system has only one address code, but can have several zone code.
- Page 9 Fig.10 the 8 bit address code in the middle row all in float state”0”, the zone code is “2121”(zone 2). Fig.11 the 8 bit address code in the middle row all in float state”0”, the zone code is “2112”(zone 3) Fig.12 the 8 bit address code in the middle row all in float state”0”, the zone code is “2111”(zone 4) Fig.13 the 8 bit address code in the middle row all in float state”0”, the zone code is set as...
- Page 10 address code is also same as infrared detectors for the same alarm set , but we can set the 4 bit zone code as 24 hours guard zone, of course , you can also set the zone code as zoen 1,2,3,4, as you like.
