- Page 1 MPS Hi-Low Seating System Assembly Guide Model# Series 79300105 & 79300305 UMHLM03-15LIT CAUTION Read Instructions Before Using! Save This Guide For Future Reference MADE IN N This product is NOT a certified car seat.
- Page 2 Bergeron Health Care. Use only Special Tomato accessories and parts on Special Tomato products. Special Tomato parts are not interchangeable with other manufacturers’ products. Replace any worn parts immediately for safety.
-
Page 3: Table Of Contents
The MPS Hi-Low Seating System has been designed to offer affordable seating and positioning while providing optimal comfort and function. This manual shows how to easily and safely take advantage of the features this product offers. Contents 03 Safety Information 04 Unpack your MPS Hi-Low Seating System 05 Assembly: Attaching the MPS seat to the Hi-Low Base 06 Assembly: Attaching the Tilt Piston to the MPS seat... -
Page 4: Safety Information
To improve safety we recommend that Always put the seating system at the users should not be left unattended at lowest position when moving a child any time while using Special Tomato around their environment. equipment. Only use this product on a level surface. All... -
Page 5: Unpack Your Mps Hi-Low Seating System
Unpack your MPS Hi-Low Seating System Check Parts Carefully remove them from the boxes and check all the parts you have ordered. Once you have checked all the components you are then ready to assemble the MPS Hi-Low Seating System and attach it to its base. WARNING Keep plastic bags away from children. - Page 6 Assembly Tools allen key (Large) 1. Attaching the MPS seat to the Hi-Low Base Hardware Bag #2 On a flat surface, Place the MPS Seat face down as shown. Then roll the Hi-Low Base up to the MPS shell and align the mounting bracket holes as shown.
- Page 7 2. Attaching the Tilt Helpful Tools Piston to the MPS seat allen key (Small) It is recommended that a second person assists with this part of the assembly process. crescent wrench (not included) Lock all casters on the base Hardware Bag #4 Position tilt piston axle midway through the tilt piston head.
-
Page 8: Assembly: Installing The Footrest
Using the star shaped rubber knobs, secure the footrest leg extensions into the MPS shell. Repeat on opposite side. Finished. Use the round shaped rubber knobs to Enjoy using your Special Tomato MPS Hi-Low install the footrest support as shown. Seating System! Repeat on opposite side. -
Page 9: Assembly: Installing The Tray
4. Installing the Tray (optional) Parts Needed *Velcro facing out Hardware Using round rubber knob bolts and washers, install the tray supports as shown above. Repeat on opposite side. Secure the tray surface by folding the Velcro tabs over the tray supports as shown. Be sure to fully engage Velcro. -
Page 10: Locks
Locks injury; always verify that the tilt & To prevent serious up-down pedal locking pins are fully engaged before you place the child in the seating system. Using Caster Locks Using Tilt Lever & Up-Down Pedal Locks Unlocked Locked Level position is unlocked Down position is locked Pull and rotate pin 90º... -
Page 11: Footrest
Adjustments (cont.) Tray Tray angle and depth can be adjusted. To adjust the tray tilt, loosen round To adjust the tray depth, disengage Velcro tabs knob and reposition the tray support and reposition the tray to the desired depth, angle on both sides. then re-engage Velcro on both sides. -
Page 12: Cushions
Adjustments (cont.) Cushions Headrests Back and headrest cushions adjust up and down along the center track. MHS and MHL headrests fit (MS) and (ML) shells. MHS (Standard) MHL (w/ Laterals) 7"W × 6"H 7.5"W × 6.5"H Back Cushions MS2, MS4 and ML2 back cushions fit (MS) shell. ML2 and ML4 back cushions fit (ML) shell. 8"W ×... -
Page 13: 5-Point Harness
Adjustments (cont.) Always secure child in the restraint • Never leave child unattended 5-Point Harness: Chest & Shoulder • Always keep child in view Proper adjustment of the harness is important for both • Secure straps tightly positioning and safety of the child. Please consult your therapist to ensure the 5-point harness is properly adjusted for the child. -
Page 14: Harness Threading & Connections
Hi-Low Harness For a video tutorial visit youtube.com/ SpecialTomato1 Threading & Connections Strap Diagram Harness Installed UNCLIP ALL HARNESS CHEST STRAPS STRAP BUCKLING LATERAL STRAPS BOLTED UNDERNEATH SEAT PAN 3-POINT CROTCH HARNESS WAIST & CROTCH STRAP BOLTED UNDERNEATH SEAT PAN 3-Point Belt Removal 1. - Page 15 Hi-Low Harness Threading & Connections (cont.) Shoulder Strap Removal 1. Unscrew top part* of vertical bar on left side only. 2. Slide up left side of shoulder strap adjustment mechanism off the vertical bar. 3. Reinstall top part* of left vertical bar. 4.
-
Page 16: Regular Product Maintenance
Regular Product If any parts should fail, please Maintenance stop using the product and contact customer service or your local dealer. We recommend the following daily product inspections: 1. Ensure all adjustment knobs and bolts are secure. 2. Check all harness pads and Velcro for signs of wear and tear. 3. - Page 17 Dimensions Small MPS Seat Cushions Large MPS Seat Cushions MPS Seat Specifications MS1 Target User Age 9 mos - 3 yrs 2 - 5 yrs 4 - 8 yrs 5 - 9 yrs 6 - 9 yrs 8 - 11 yrs 10 - 14 yrs 12 - Adult Target User Height...
-
Page 18: Consumer Information
To exercise this limited warranty, the user should first obtain a Return Authorization Number from the dealer the Special Tomato™ product was purchased from. The product must be delivered charges pre-paid (UPS recommended) to the factory or to an authorized service center, together with a copy of the original invoice, the Return Authorization Number and a written description of the problem.
