Page 1: Table Of Contents
WASHING MACHINE P1401 P1201 P1001 P801 SERVICE Manual WASHING MACHINE CONTENTS Caution for the safety during servicing 1. SPECIFICATIONS 2. OVERVIEW OF THE WASHING MACHINE 3. OVERVIEW OF THE CONTROL PANEL 4. GENERAL ERROR FUNCTION 5. TROUBLE DIAGNOSIS 6. TEST MODE 7. -
Page 2: Caution For The Safety During Servicing
19. When the wash-heater is replaced, check it is inserted in the bracket-heater and screw the nut. If the wash-heater is not inserted in the bracket-heater properly, this may cause the noise and leakage since it is contacted to the drum. SAMSUNG ELECTRONICS CO., LTD... -
Page 3: Specifications
220 V 2000 HEATING 240 V 2400 MODEL P1401 P1201 P1001 P801 SPIN 550W 500W 500W 430W 220-240V PUMPING 34 W WATER CONSUMPTION 49l (STANDARD COURSE) MODEL P1401 P1201 P1001 P801 SPIN REVOLUTION 1400 1200 1000 SAMSUNG ELECTRONICS CO., LTD... -
Page 4: Overview Of The Washing Machine
2. Overview of the Washing Machine SAMSUNG ELECTRONICS CO., LTD... -
Page 5: Overview Of The Control Panel
Press the button to select one of the eight available wash programs. Cotton, Colour, Synthetic, Delicate, Wool, Quick, Rinse+Spin, Spin 4. Option Button Press the button repeatedly to cycle through the available partial wash options P1401/P1201 : Eco Rinse Prewash (Eco +Rinse... - Page 6 1) Capacity : AC 230V/2000W 2) Location : Bottom of TUB 3) Function : Raise the water temperature Thermistor supplied at the wash process. 4) Resistance value : 23Ω ~ 29Ω 5) Thermal Fuse : 128°C SAMSUNG ELECTRONICS CO., LTD...
- Page 7 CODE-NO. REMARK Lifter type ø 30 ø 25 ø 44.7 DC97-01463A P1001/P1201/P1401 ø 30 ø 25 ø 44.7 DC91-12281A P1001/P1201 ø 30 ø 25 ø 44.7 DC97-00785B P1401 ø 20 ø 17 ø 25 DC97-00785A P801 SAMSUNG ELECTRONICS CO., LTD...
-
Page 8: General Error Function
2 min when the abnormal frequency of 25.24KHz is detected. - Display shows ‘E8’. - This error can be cleared by POWER S/W OFF. 9. WATER LEAKAGE ERROR (E9) - Water Leakage error occures when water is drained naturally after washing program starts. SAMSUNG ELECTRONICS CO., LTD... -
Page 9: Trouble Diagnosis
3) As the P.C.B assembly is designed for no trouble, do not replace the P.C.B assembly by the wrong diagnosis and follow the procedure of the trouble diagnosis when the micom is not operated normally. SAMSUNG ELECTRONICS CO., LTD... - Page 10 The heating is not executed. - Is the wash heater terminal unplugged? - Is the wash heater normal? - If above points are not found, the PCB assembly is out of order. Replace it. SAMSUNG ELECTRONICS CO., LTD...
-
Page 11: Test Mode
POWER S/W “4” on. (Whole lamps turn on and display show “tl” after 3 Seconds.) B. Press the “1” key and display shows “t2” C. Press the “3” key and display shows the inside temperature of tub. SAMSUNG ELECTRONICS CO., LTD... -
Page 12: Main Function
5. Main function 9) Power-out compensation function ● If power is out on selected process, the process before power out is stored to EEPROM, once power is back the process before power out continues. ● When power is back, washing process starts from the process at the point of the power out, rinse/drain process starts from the initial process. - Page 13 POWER S/W “4” on. (Whole lamps turn on and display show “tl” after 3 Seconds.) B. Press the “1” key and display shows “t2” C. Press the “3” key and display shows the inside temperature of tub. SAMSUNG ELECTRONICS CO., LTD...
-
Page 14: Pcb Schematic Diagram
8. PCB Schematic Diagram SAMSUNG ELECTRONICS CO., LTD... -
Page 15: Pcb Circuit Diagram
8. PCB CIRCUIT DIAGRAM SAMSUNG ELECTRONICS CO., LTD... - Page 16 WB008 2802-001058 RESONATOR-CERAMIC 8MHz,0.2%,TP,10x5x8mm RESO WB007 DE13-20017A IC-DRIVE KID65003AP,DIP,16P,STICK IC3,IC5,IC6 WB007 1103-001160 IC-EEPROM 4C010,128X8BIT,DIP,8P WB009 DE30-20016A BUZZER CBE2220BA,STICK ± WB010 3404-001022 SWITCH-TACT 15V,20mA,130° 40gf,6x6x5mm SW 1~7 WB011 DE07-20040A LED LAMP SLH-34VC70F,RED,T,PI5 WB012 0703-001056 LED DISPLAY Y-GRN,4dig,7seg,46X19X24.6mm SAMSUNG ELECTRONICS CO., LTD...
-
Page 17: Assemble And Disassemble
5) Part the diaphragm and the wire diaphragm away from the frame-front. 6) Remove the eight screws fixing the frame-front. 7) It’s possible to exchange and service the heater, the pump, the shock-absorber and the door lock s/w. LEVER SAMSUNG ELECTRONICS CO., LTD... - Page 18 Motor Assemble Hole 5. How to Assemble the RELAY Housing. Relay <CAUTION> Insert the Relay Housing to the Relays on the opposite direation each other. [Relay Housing Color] Relay Housing (A) WHITE BLUE Relay Housing (B) SAMSUNG ELECTRONICS CO., LTD...
-
Page 19: Tools For Disassembly And Assembly
17mm. Vice pliers Tool to protect the idle and abrasion of the bolt for the box driver. Other(Driver, Nipper, Long nose) General tools for the after service. JIG for the Tub 1 (Disassemble and Assemble) SAMSUNG ELECTRONICS CO., LTD... -
Page 20: Designation Of Main Components
10. Designation of Main Components 10-1 Normal / Reverse Revolution of Motor and R. P. M. Control 1 2 3 4 5 6 7 8 9 10 Rotor Stator coil Rotor Stator coil STATOR WASHING MOTOR <Figure1> <Figure2> ( ± 7%) STATOR(51) ROTOR(8.9) TACHO(3.4) PROTECTOR(6.7) "H"(mm) Code-No. - Page 21 10-3 Heater 1) Capacity : AC 230V/1900W 2) Location : Bottom of TUB 3) Function : Raise the water temperature supplied at the wash process. Thermistor 4) Resistance value : 23~29 5) Thermal Fuse : 169°C 10-4 Detergent tub and water supply value A Detergent tub is composed of housing and 3 drawers .
- Page 22 10-6 ASSY-TUB BACK INNER-BEARING OUT-BEARING OIL-SEAL (unit : mm) TYPE INNER-BEARING(A) OUT-BEARING(B) OIL-SEAL(C) Assy-Housing Bearing(D) Assy-Tub Back ø 30 ø 25 ø 34 DC97-05168A DC97-00214R 10-7 ASSY- DRUM (unit : mm) TYPE CODE-NO. REMARK ø 30 ø 23 ø 35 DC97-01463H 10-8 ASSY-PUMP DRAIN 1) Capacity : AC 230V 34W...
- Page 23 11. WC:TOP(FRONT) - Exploded View SAMSUNG ELECTRONICS CO., LTD...
- Page 24 ASSY-FRAME PLATE(U) DC97-00417A WCD05 ASSY-HOUSING DRAWER DC91-12085A WZ001 SCREW TAPPING DC60-20049A WCD07 COVER-DOOR DC61-00055A WCD08 DOOR-GLASS DC61-00013A WCD09 HOLDER-GLASS DC61-00057A WCD10 LEVER-DOOR DC66-00016A WCD11 ASSY-HINGE DC97-00100A WZ008 WASHER-PLAIN DC60-60025C WZ016 NUT-FLANGE DD60-50018A WCD12 ASSY-FRAME FRONT DC97-00702A SAMSUNG ELECTRONICS CO., LTD...
- Page 25 12. WD : TUB - Exploded View SAMSUNG ELECTRONICS CO., LTD...
- Page 26 DC47-00001A WDD13 TUB-FRONT DC61-30346A WDD14 BRACKET-NUT DC61-40348B WDD15 BRACKET-HEATER DC61-40344A WDD16 SPACER-HEATER DC61-60496A WDD17 VANE-CHECK DC62-20311A WDD18 ASSY-DRUM DC97-00785A DC91-12281A DC97-00785B WDD19 PACKING-TUB DC62-40183A WDD20 CLIP-TUB DC61-60499B WDD21 ASSY-TUB BACK DC97-00214K DC97-00214B DC97-00214A WDD20 CLIP-TUB DC61-60520A SAMSUNG ELECTRONICS CO., LTD...
- Page 27 13. WE:CASE - Exploded View *option SAMSUNG ELECTRONICS CO., LTD...
- Page 28 BAND RING DC65-60125B WZ005 ASSY-HOSE DRAIN(O) DC97-00139B WA001 ASSY-POWER CORD DC96-00146A WAD02 FILTER-EMI DC29-00003A WED10 SPRING-HANGER DC61-70216C WED11 SLEEVE-PLUG DC61-60180A WA009 VALVE-WATER(COOL) DC62-30313A WZ015 CLAMP-HOSE DC61-60063B WED12 HOSE-DRAWER DC62-10068A WCD13 ASSY-COVER TOP DC97-00851A WZ007 HOSE WATER(C) DC62-10289B SAMSUNG ELECTRONICS CO., LTD...
- Page 29 15. TOP(FRONT) - Exploded View R0019 C0115 C0002 F0125 A0242 R0036 R0036 D0004 F0064 D0112 D0061 D0045 C0103...
- Page 30 15. TUB - Exploded View U0355 U0004 U0095 U0010 R0158 U0015 U0028 U0033 U0355 U0038 U0328 U0029 R0030 U0016 R0001 U0078 U0026 U0018...
- Page 31 15. CASE - Exploded View P0001 W0001 W0002 W0004 A0115 Y0040 R0159 R0158 W0032 A0025 R0027 I0041 I0022 C0058 F0027 U0133 A0114 U0133 I0040 B0070 A0006 J0013 I0046 A0132...
- Page 32 DC96-00171A ASSY WIRE EARTH P-PJT(DRUM),-,-,WIRE/UL1 A0362 DC61-40081A HOLDER-WIRE DAWH-2NC,NYLON66,-,-,-,-,NTR B0070 DC97-14289A ASSY LEG ALL MODEL,Φ39 NUT-HEX FLANGE,-, C0002 DC97-01328A ASSY PANEL CON- P1401/P1201/P1001,-,- TROL C0058 DC61-20205B DOOR-LOCK S/W -,-,-,-,-,P1092,-,-,BITRON C0103 DC66-00016A LEVER-DOOR POM,-,-,-,-,NTR,DWM599W,DANBY C0115 MFS-P801H-00 ASSY PCB PARTS(M) P801DWN D0004...
- Page 33 J0025 DC31-30008F PUMP-DRAIN SW-70XP,120V,60Hz,SYNCHRONOUS P0001 DC97-11090B ASSY COVER TOP P1053GW/XEH,6.0KG/HUNGARY P0036 DC61-10687B CAP-RINSE SEW-HW108,ABS,-,-,-,GRN,- R0001 DC97-01463E ASSY DRUM P801(800RPM)KRNJM,LEFTER TYPE/ R0002 DC66-10179B DRUM-FRONT SB-PJT,STS430,-,-,-,-,T0.4 R0005 DC66-10178A DRUM-BACK SWF-P12,STS430,-,-,-,-,T0.5 R0017 DC97-13901A ASSY DRUM LIFTER B MODEL,SSEC/B MODEL,-, R0019 DC97-06572P ASSY HOUSING B/P2/H+C,VALVE/110V/ DRAWER R0019...
- Page 34 U0353 DC61-60359E CLAMPER HOSE F1235AS/F1035AS,SK5,-,ID7.8 U0353 DC61-60497A CLAMPER HOSE-JOINT SWF-P12,HSWR,-,ID70/O U0353 DC65-00019A CLAMPER HOSE DRUM W/M,SK5,-,D34/H5/T1.5, U0353 DC61-00133A CLAMPER HOSE-FIX P1291,PP,ID24.5,OD29.5, U0355 DC66-60153A WEIGHT-BALANCER SWF-P12,CONCRETE,UPPER, U0355 DC66-60154A WEIGHT-BALANCER SWF-P12,CONCRETE,LOWER, U0360 DC61-60499B CLIP-TUB HSWR,P1291,-,NO/PAINT, U0360 DC61-60520A CLIP-TUB SK5,SWF-P12,-,PLATE-TYPE, V0005 DC68-02315A LABEL-ENERGY P1005J~P801,-,MOJO+REMOV,-, W0001 DC96-00174B...
- Page 35 ELECTRONICS © Samsung Electronics Co., Ltd. May 2000 Printed in Korea Code No. : DC68 - 00799A...
