NEC px750u Installation Manual

PX750U Installation Guide
Desktop and Ceiling Mount
Contents
Product Description, Lens Specs, Screen/Aspect Ratio
Notes and Formulas
Distance Charts and Formulas
Ceiling Mount/Desktop Installation
Lens Shift Adjustable Range
Cabinet Dimensions
Cabinet Dimensions
Optional Lens Dimensions
Ventilation Requirements
Input Panel and Button Panel
Control Codes

Product Description

Type: 1 chip DMD Reflection Type
0.67 in. 2x LVDS DMD
Resolution: 1920 x 1200 (16:10)
Fan Noise: PX750U: 43 dB / 39dB @ 1 meter
Power Consumption: PX750U: 1008W (max)
Network Ready, integrated wired and wireless adapter
Manual: Lens Shift, Horizontal & Vertical /Zoom/ Focus

Lens Specifications

NP16FL: Throw Ratio: ~ 0.76:1
Screen Sizes: 50"-300"
NP17ZL: Throw Ratio: 1.29 - 1.79:1
Screen Sizes: 50-300"
NP18ZL: Throw Ratio: 1.73. - 2.27:1 Focal Length: 25.7 - 33.7mm
Screen Sizes: 50-300"
Screen/Aspect Ratio
4:3, 16:9 and 16:10 screens are fully supported with proper aspect ratio control for both type sources using NEC developed
scaling technology. Menu selections have settings for each screen type and aspect ratio control for each source type.
Notes

For screen sizes not indicated on the projection tables, use the formulas below.
If the figures on the tables do not match the results of formulas, use the figures in the table..

Distances are in inches, for millimeters multiply by 25.4.

Distances may vary 5%.
Formulas: 16:10 Aspect Ratio (PX750U-WUXGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for "W" in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas:
NP16FL: C = 0.794W - 1.85
NP17ZL: C(Wide) = 1.281W - 2.094 ------ C(Tele) = 1.825W - 1.913
NP18ZL: C(Wide) = 1.764W - 2.677 ------ C(Tele) = 2.313W - 2.638
NP19ZL: C(Wide) = 2.261W - 3.150 ------ C(Tele) = 3.747W - 3.114
NP20ZL: C(Wide) = 3.654W - 5.319 ------ C(Tele) = 5.492W - 5.299
NP21ZL: C(Wide) = 5.469W - 11.626 ------ C(Tele) = 8.527W - 11.531
www.necdisplay.com
Focal Length: 11.6mm
F/#: 1.85
Focal Length: 18.7 - 26.5mm
F/#: 1.85-2.5 _________
F/#: 1.64 - 1.86
PX750U
NEC Display Solutions of America, Inc.
Pg 1
Pg 1-2
Pg 3
Pg 4
Pg 5
Pg 6
Pg 7
Pg 8
Pg 9
Pg 10
Dimensions: 19.84"(W) x 8.67"(H) x 20.55"(D)
Weight: PX750U:
Brightness: PX750U:
BTU's: PX750U:
NP19ZL: Throw Ratio: 2.22 -3.67:1
Screen Sizes: 50-300"
NP20ZL: Throw Ratio: 3.60 - 5.40:1
Screen Sizes: 50-300"
NP21ZL: Throw Ratio: 5.30 - 8.30:1
Screen Sizes: 50-300"
Definitions:
W = Image Width
H = Image Height (size)
C = Throw distance
Rev 1.3
19.7kg / 43.3 lbs
7500 Lumens
3439.44 BTU/hour
Focal Length: 32.9 - 54.2mm
F/#: 1.86 - 2.48
Focal Length: 52.8 - 79.1mm
F/#: 1.85-2.41
Focal Length:78.5 -121.9mm
F/#: 1.85 - 2.48
16:10 Screen Formulas
W = H x 16/10
H = W x 10/16
Screen Diagonal = W x 18.868/16
16:9 Screen Formulas
W = H x 16/9
H = W x 9/16
Screen Diagonal = W x 18.358/16
Page 1 of 10
