Cat. No. 1771-P3, -P4, -P5 and -P5E
Use this document as a guide when installing the catalog number
1771-P3, -P4, -P5 or -P5E power supplies.
To
For this reference information
Because of the variety of uses for the products described in this
publication, those responsible for the application and use of these
products must satisfy themselves that all necessary steps have been
taken to assure that each application and use meets all performance
and safety requirements, including any applicable laws, regulations,
codes and standards. In no event will Allen-Bradley be responsible
or liable for indirect or consequential damage resulting from the use
or application of these products.
Any illustrations, charts, sample programs, and layout examples
shown in this publication are intended solely for purposes of
example. Since there are many variables and requirements associated
with any particular installation, Allen-Bradley does not assume
responsibility or liability (to include intellectual property liability)
for actual use based upon the examples shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for
Application, Installation, and Maintenance of Solid-State Control
(available from your local Allen-Bradley office), describes some
important differences between solid-state equipment and
electromechanical devices that should be taken into consideration
when applying products such as those described in this publication.
Installation Instructions
See page
1
5
7
9
10
12
See page
13
14
17
18
Advertisement
Table of Contents
Summary of Contents for Rockwell 1771–P3
-
Page 1: Table Of Contents
Installation Instructions Power Supply Modules Cat. No. 1771–P3, –P4, –P5 and –P5E Contents Use this document as a guide when installing the catalog number 1771-P3, -P4, -P5 or -P5E power supplies. See page Important User Information Preinstallation Considerations Connecting Input Power Setting the Power Loss Time Delay (1771 P5E only) 8 Installing the Power Supply Making Input Power Connections... - Page 2 Power Supply Modules Reproduction of the contents of this copyrighted publication, in whole or part, without written permission of Rockwell Automation, is prohibited. Throughout this publication, notes may be used to make you aware of safety considerations. The following annotations and their accompanying statements help you to identify a potential hazard.
- Page 3 Power Supply Modules Environment and Enclosure ATTENTION This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664–1), at altitudes up to 2000 meters without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
- Page 4 Power Supply Modules Preventing Electrostatic Discharge ATTENTION This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: Touch a grounded object to discharge potential static. Wear an approved grounding wriststrap. Do not touch connectors or pins on component boards.
-
Page 5: Preinstallation Considerations
Power Supply Modules Preinstallation Chassis Compatibility Considerations The 1771-P3 power supply is a single-slot module, and the 1771-P4, -P5 and -P5E power supplies are 2-slot modules. These power supply modules can be used in both series A and B 1771 I/O chassis, as shown below. - Page 6 Power Supply Modules Processor Compatibility Compatibility of power supplies with selected processors is shown below. Processors with an integrated power supply as shown below can support only one additional ac power supply. Table B Power Supply and Processor Compatibility 1772 LSP 1771 AL 1772 LN1, 1772 LS...
-
Page 7: Connecting Input Power
Power Supply Modules The 1771–P5 and –P5E are designed to operate in ATTENTION parallel with another 1771–P5 or –P5E. Do not parallel 1771–P5 or –P5E with other ac power supplies. Limit adjacent slot module power dissipation for all supplies to 10W maximum. Power supply modules have a controlled ATTENTION “soft-start”... -
Page 8: Setting The Power Loss Time Delay (1771 P5E Only)
Power Supply Modules Setting the Power Loss Time Delay (1771 P5E only) Power loss time delay is the time period from when the power supply input voltage drops below 20.5V dc to when the power supply resets the processor enable signal on the I/O backplane. When this signal is reset, the resident PLC processor or adapter module stops processing data to/from the modules in the I/O chassis. -
Page 9: Installing The Power Supply
Power Supply Modules Figure 1 Features of the Power Supply Modules Cat. No. 1771 P5 and P5E Cat. No. 1771 P3 Status Indicator - Keeps you informed of module operating ACTIVE ACTIVE conditions. P/S Parallel - Makes paralleling connections between 2 power supplies easy. -
Page 10: Making Input Power Connections
Power Supply Modules Turn the power supply off before inserting into the ATTENTION chassis. Turn off power to the I/O chassis before inserting into the chassis. Failure to remove power from the backplane could cause module damage, degradation of performance, or injury. Failure to remove power from the backplane could cause injury or equipment damage due to possible unexpected operation. - Page 11 Power Supply Modules 120V Line Neutral Ground Bus Equipment Grounding Ground Electrode 1771 P3 and -P4 Conductor Connecting the 1771-P5 and -P5E Power Supplies 1. Remove the protective cover from the terminal block by squeezing the prongs and lifting the protective cover. 2.
-
Page 12: Paralleling Power Supplies
Power Supply Modules Paralleling Power Supplies The power supply modules are designed to operate in parallel with: another 1771-P3, -P4, -P5 or -P5E power supply (Note: The 1771-P5 and -P5E power supplies are designed to operate in parallel only with another 1771-P5.) (Refer to Table A and Table C.) a 1772-LSP, -LWP or -LXP processor (Refer to Table B.) Note: Paralleling 2 modules, even when using different power... -
Page 13: Status Indicators
Power Supply Modules 3. Turn on both power supplies simultaneously. To avoid driving the first of two paralleled power ATTENTION supplies into an overcurrent condition that would shutdown the module, you must simultaneously turn on both power supplies. Module Indicators The power supply module has a green indicator light (labeled P/S ACTIVE). -
Page 14: Troubleshooting
Power Supply Modules Troubleshooting Follow the procedure below to isolate and correct possible faults. 1. Turn the power supply off and wait at least 15 seconds (-P3 and -P4) or 45 seconds (-P5 and -P5E) before you turn it on again. 2. - Page 15 Power Supply Modules 8. If you have only one power supply in your chassis and it passed step 7 (the P/S ACTIVE light turned on), verify that the power supply is not overloaded by performing steps 9 through 11. 9. Turn the power supply off and wait 15 seconds (-P3 and -P4) or 45 seconds (-P5 and -P5E).
- Page 16 Power Supply Modules 6. Perform steps 7 through 9 to test for an open circuit in the paralleling cable. 7. Turn both power supply modules off. Connect the paralleling cable to each supply. 8. Turn one power supply module on. The P/S ACTIVE indicators on both supplies should not turn on.
-
Page 17: Safety Approvals
Power Supply Modules Safety Approvals The following information applies when operating this equipment in hazardous locations: Products marked CL I, DIV 2, GP A, B, C, D" are suitable for use in Class I Division 2 Groups A, B, C, and D Hazardous Locations and nonhazardous locations only. Each product is supplied with markings on the rating nameplate indicating the hazardous location temperature code. -
Page 18: Specifications
Power Supply Modules Specifications 1771 P3 1771 P4 1771 P5 1771 P5E Module Location 1 slot in a 1771 2 adjacent slots in a 1771 I/O chassis I/O chassis Nominal Input Voltage/Current 0.42A, 120V ac 0.88A, 120V ac 3.0A, 24V dc Input Voltage Range 97 to 132V ac rms 20.5 to 30V dc... -
Page 19: Publication 1771 In073A-En-P - March
Power Supply Modules Agency UL UL Listed Industrial UL UL Listed Industrial UL UL Listed Industrial UL UL Listed Industrial Control Certification Control Equipment Control Equipment Control Equipment Equipment (when product is CSA CSA Certified CSA CSA Certified CSA CSA Certified Process CSA CSA Certified Process Control marked) Process Control... - Page 20 90 years. We design, manufacture and support a broad range of automation products worldwide. They include logic processors, power and motion control devices, operator interfaces, sensors and a variety of software. Rockwell is one of the world's leading technology companies.
