QUICK INSTALLATION GUIDE
Powerline AV
Package Contents
•
Powerline AV 4-Port Network Adapter
(model number: PLS300)
•
Powerline AV Network Adapter
(model number: PLE300)
•
User Guide on CD-ROM
•
2 Ethernet Network Cables
•
2 Power Cords
•
2 Stands
•
Quick Installation Guide
Network Kit
PLK300
Model:
Advertisement
Related Manuals for Linksys PLK300
Summary of Contents for Linksys PLK300
-
Page 1: Quick Installation Guide
QUICK INSTALLATION GUIDE Powerline AV Network Kit PLK300 Model: Package Contents • Powerline AV 4-Port Network Adapter (model number: PLS300) • Powerline AV Network Adapter (model number: PLE300) • User Guide on CD-ROM • 2 Ethernet Network Cables • 2 Power Cords •... - Page 2 Overview To create your powerline network, you must connect each network device to a Powerline Adapter. In the first section, you will connect the Powerline AV Network Adapter (model number: PLE300) to your router. In the next section, you will connect the Powerline AV 4-Port Network Adapter (model number: PLS300) to your computers or other network devices.
- Page 3 Plug Power into Outlet NOTE: Because the Adapter sends data over the power lines of your home, Linksys recommends that you plug the Adapter directly into an electrical outlet. The Adapter has its own power filter to help protect against surges.
- Page 4 Install the Second Adapter Connect one end of an Ethernet network cable to an Ethernet port on the Powerline AV 4-Port Network Adapter (model number: PLS300). Connect Ethernet Network Cable Connect the other end of the cable to the computer or other device that you want to add to the network.
- Page 5 Plug Power into Outlet NOTE: Because the 4-Port Adapter sends data over the power lines of your home, Linksys recommends that you plug it directly into an electrical outlet. The 4-Port Adapter has its own power filter to help protect against surges.
-
Page 6: More Information
800-546-5797 (800-LINKSYS) Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
