InWall Subwoofer System
SA-350 Mono Subwoofer Amplifier
SA-700 Dual Mono Subwoofer Amplifier
For use with Atlantic Technology IWTS-8 SUB Woofer Module Only
SA-700 pictured
This manual covers installation and operation of SA-350 Mono and SA-700
Dual Mono Subwoofer Amplifiers. Installation of the 8 SUB Woofer Module
is covered separately by an instruction sheet included with the woofer.
I
H
T
N N O V A T I V E
O M E
H E A T E R
Advertisement
Table of Contents
Related Manuals for Atlantic Technology SA-350 Mono
Summary of Contents for Atlantic Technology SA-350 Mono
- Page 1 For use with Atlantic Technology IWTS-8 SUB Woofer Module Only SA-700 pictured This manual covers installation and operation of SA-350 Mono and SA-700 Dual Mono Subwoofer Amplifiers. Installation of the 8 SUB Woofer Module is covered separately by an instruction sheet included with the woofer.
-
Page 2: For Future Reference
Record your speaker and amplifier serial numbers and date of pur- chase here: Model Number Serial Number Date of Purchase The serial number is found on the back of the speaker near the con- necting terminals. Features 8 SUB Woofer Ultra-long-throw 8" Coated Composite Molded Graphite polymer cone drivers with vented 8 pound motor structure and 1-3/4"... -
Page 3: Table Of Contents
Program EQ Setting Curves Copyright © 2001 Atlantic Technology International. Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. THX and THX Ultra are registered trademarks of Lucasfilm, Ltd. Dolby Digital, AC-3, Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation. -
Page 4: Inwall Subwoofer Systems
InWall Subwoofer Systems InWall Subwoofer Systems Congratulations on your purchase of an Atlantic Technology InWall Subwoofer System. This unique “invisible subwoofer” will enhance your listening pleasure dramatically, by providing the bass founda- tion upon which most music and special effects are built. In addi-... -
Page 5: Amplifier Front Panel
Instruction Manual Amplifier Front Panel Figure 5 NOTE: Items in gray area are found on SA-700 amplifier only LEVEL TRIM display window Indicates level of trim adjustment applied above or below the reference volume setting of your subwoofer. (page 14) FREQUENCY EQ control Selects the frequency to be adjusted by the parametric equalizer. -
Page 6: Amplifier Back Panel
SA-700 or to another device. (page 7) High Level Inputs Use the HI IN binding posts to connect a high level (speaker) output from your processor/amplifier. (page 7) Subwoofer Outputs Use the SPEAKER OUTPUT binding posts to connect the amplifier to the 8 SUB Module(s). -
Page 7: Remote Control
1dB increments. (page 14) Connecting Your Subwoofer The Atlantic Technology InWall Subwoofer System is simple to hook up, offering several connection methods for maximum flexibility. Study the system diagrams starting on Page 8. Once you have found the example which most closely matches your system, hook up your subwoofer(s) as shown in that diagram. -
Page 8: Sa-350 Low Level Connections
Connecting Your Subwoofer InWall Subwoofer System SA-350 Low Level Connections Figure 8 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE / NE PAS OUVRIR... -
Page 9: Sa-700 Low Level Connections With One
Connecting Your Subwoofer Instruction Manual SA-700 Low Level Connections with one SubOut/LFE Output Figure 9 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE / NE PAS OUVRIR... -
Page 10: Sa-700 Low Level Connections With Two
Connecting Your Subwoofer InWall Subwoofer System SA-700 Low Level Connections with two SubOut/LFE Outputs Figure 10 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE / NE PAS OUVRIR... -
Page 11: Sa-700 High Level Connections
Connecting Your Subwoofer Instruction Manual SA-700 High Level Connections Figure 11 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE / NE PAS OUVRIR... -
Page 12: Power Connection
“Wide” (full frequency range) and “Normal” (restricted low frequency) mode for the center channel speaker. Atlantic Technology recommends that the center channel be operated in the Normal mode when using a powered subwoofer. The center channel speaker will sound more dynamic and the intelligibility of the system will generally be improved when in the Normal mode. -
Page 13: Parametric Room Equalizer (Eq)
They are designed specifically to remove (turn down) un- wanted peaks in the bass. The procedure is fairly simple: the in- cluded Atlantic Technology/Sencore Test and Training CD is used along with a meter to define the single largest bass peak at the prime listening position and then reduce it with the Parametric EQ. -
Page 14: Setting The Subwoofer Level Without An Spl Meter
BASS LEVEL control to make this adjustment. Level Setting Without an SPL Meter If you decide not to use an SPL meter try to set all the speaker levels the same using the Test Tones. Of course, this will be much more difficult without the meter, especially for the subwoofer. -
Page 15: Care And Feeding Of Your Subwoofer
If the problem persists, please contact your local autho- rized Atlantic Technology dealer. Possible Cause AC power cord unplugged or plugged into a non-working outlet. -
Page 16: Program Eq Setting Curves
Program EQ Setting Curves REF/THX (flat) 343 Vanderbilt Avenue Norwood, MA 02062 (781) 762-6300 www.atlantictechnology.com Note: These graphs represent the response of the amplifier withour crossovers. In actual use, the system is not designed to respond be- yond 200Hz. N N O V A T I V E O M E H E A T E R 010-1700...
